1223
|
Defines the symbol used to indicate repeated captions, providing a clear visual cue for identical entries (ditto mark)
local var_Items as IItems
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:HeaderAppearance := Etched
oDCOCX_Exontrol1:HeaderHeight := 24
oDCOCX_Exontrol1:DrawGridLines := exRowLines
IColumn{oDCOCX_Exontrol1:Columns:Add("Country")}:ShowIdem := "<fgcolor gray>〃"
var_Items := oDCOCX_Exontrol1:Items
var_Items:AddItem("Spain")
var_Items:AddItem("Spain")
var_Items:AddItem("Spain")
var_Items:AddItem("Spain")
var_Items:AddItem("Germany")
var_Items:AddItem("Germany")
var_Items:AddItem("Germany")
var_Items:AddItem("Germany")
oDCOCX_Exontrol1:EndUpdate()
|
|
1222
|
Defines the symbol used to indicate repeated captions, providing a clear visual cue for identical entries (space)
local var_Items as IItems
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:HeaderAppearance := Etched
oDCOCX_Exontrol1:HeaderHeight := 24
oDCOCX_Exontrol1:DrawGridLines := exRowLines
IColumn{oDCOCX_Exontrol1:Columns:Add("Country")}:ShowIdem := " "
var_Items := oDCOCX_Exontrol1:Items
var_Items:AddItem("Spain")
var_Items:AddItem("Spain")
var_Items:AddItem("Spain")
var_Items:AddItem("Spain")
var_Items:AddItem("Germany")
var_Items:AddItem("Germany")
var_Items:AddItem("Germany")
var_Items:AddItem("Germany")
oDCOCX_Exontrol1:EndUpdate()
|
|
1221
|
Displays a glitch funnel for drop-down filter buttons (empty or active)
local var_Appearance as IAppearance
local var_Column as IColumn
local var_Items as IItems
oDCOCX_Exontrol1:BeginUpdate()
var_Appearance := oDCOCX_Exontrol1:VisualAppearance
var_Appearance:RenderType := -1
var_Appearance:Add(1,"gBFLBCJwBAEHhEJAAEhABa8IQAAYAQGKIYBkAKBQAGaAoDDUNQxQwAAxwfBMKgBBCLIxhEYobgmGIXRpFMbxCKQahLEiTIhGUYJHgmK4tRiAUgxVDkBxrECZYqjcBZOiwLQ2TxDM7DNKUCBnIoABhGOaYDh+IQNQjUFKwTRFGRxK4EIRKAyTDLQdRyGSMMbjdQpBCbMiMRqhESKRq2UwYRYCFS1NalaztO6BUAvK67YrWez/YBfF+SfwGeqDYReWAPfgWERnQrGMLxbD8KwZAKTRjkGJ4XhuB41TbQMqufL9ByXHKSSDpGjaXjeO5VVjYNAvS69UzXNq3bhtQAOXCMEwCgI=")
var_Appearance:Add(2,"CP:1 -2 0 0 0")
oDCOCX_Exontrol1:DrawGridLines := exAllLines
oDCOCX_Exontrol1:GridLineStyle := exGridLinesGeometric
oDCOCX_Exontrol1:ShowFocusRect := false
oDCOCX_Exontrol1:[Background,exHeaderFilterBarButton] := 0x2000000
oDCOCX_Exontrol1:[Background,exHeaderFilterBarActive] := 0x2000001
oDCOCX_Exontrol1:HeaderAppearance := Etched
oDCOCX_Exontrol1:BackColorHeader := RGB(255,255,255)
oDCOCX_Exontrol1:HeaderHeight := 24
oDCOCX_Exontrol1:HeaderVisible := true
var_Column := IColumn{oDCOCX_Exontrol1:Columns:Add("1st col")}
var_Column:DisplayFilterButton := true
var_Column:DisplayFilterPattern := false
var_Column:Filter := "Item B"
var_Column:FilterType := exFilter
oDCOCX_Exontrol1:Columns:Add("2nd col")
var_Items := oDCOCX_Exontrol1:Items
var_Items:AddItem("Item A")
var_Items:AddItem("Item B")
var_Items:AddItem("Item C")
oDCOCX_Exontrol1:ApplyFilter()
oDCOCX_Exontrol1:EndUpdate()
|
|
1220
|
How can I store any extra data associated with a cell
METHOD OCX_Exontrol1ButtonClick(Item,ColIndex,Key) CLASS MainDialog
// ButtonClick event - Occurs when user clicks on the cell's button.
OutputDebugString(String2Psz( AsString(oDCOCX_Exontrol1:Items:[CellData,Item,ColIndex]) ))
RETURN NIL
local var_Editor as IEditor
local var_Items as IItems
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:HeaderAppearance := Etched
var_Editor := IColumn{oDCOCX_Exontrol1:Columns:Add("Def")}:Editor
var_Editor:EditType := ButtonType
var_Editor:Locked := true
var_Items := oDCOCX_Exontrol1:Items
var_Items:[CellData,var_Items:AddItem("Cell 1"),0] := "your extra data for cell 1"
var_Items:[CellData,var_Items:AddItem("Cell 2"),0] := "your extra data for cell 2"
oDCOCX_Exontrol1:EndUpdate()
|
|
1219
|
How can I replace or add an icon at runtime
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:ReplaceIcon("gAAAABgYACEHgUJFEEAAWhUJCEJEEJggEhMCYEXjUbjkJQECj8gj8hAEjkshYEpk8kf8ClsulsvAExmcvf83js5nU7nkCeEcn8boMaocXosCB9Hn09pkzcEuoL/fE+OkYB0gB9YhIHrddgVcr9aktZADAD8+P8CgIA==",nil)
oDCOCX_Exontrol1:ReplaceIcon("C:\images\favicon.ico",0)
IColumn{oDCOCX_Exontrol1:Columns:Add("Items")}:[Def,exCellValueFormat] := 1
oDCOCX_Exontrol1:Items:AddItem("Item <img>1</img>")
oDCOCX_Exontrol1:EndUpdate()
|
|
1218
|
How can I save the changes, such as column's width, order
METHOD OCX_Exontrol1Click() CLASS MainDialog
// Click event - Occurs when the user presses and then releases the left mouse button over the grid control.
oDCOCX_Exontrol1:Layout := "Select=" + CHR(34) + "0" + CHR(34) + ";SingleSort=" + CHR(34) + "C0:2" + CHR(34) + ";Columns=1"
RETURN NIL
local var_Items as IItems
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:Columns:Add("Column")
var_Items := oDCOCX_Exontrol1:Items
var_Items:AddItem("Item 1")
var_Items:AddItem("Item 2")
var_Items:AddItem("Item 3")
oDCOCX_Exontrol1:EndUpdate()
|
|
1217
|
How can I add totals to groups without having to go through the AddGroupItem grid function
local var_Column,var_Column1,var_Column2 as IColumn
local var_Columns as IColumns
local var_ConditionalFormat,var_ConditionalFormat1,var_ConditionalFormat2 as IConditionalFormat
local var_ConditionalFormats as IConditionalFormats
local var_Items as IItems
local g1,g2,h,r as USUAL
oDCOCX_Exontrol1:FreezeEvents(true)
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:HeaderAppearance := Etched
oDCOCX_Exontrol1:HeaderHeight := 24
oDCOCX_Exontrol1:LinesAtRoot := exLinesAtRoot
var_ConditionalFormats := oDCOCX_Exontrol1:ConditionalFormats
var_ConditionalFormat := var_ConditionalFormats:Add("%CT1",nil)
var_ConditionalFormat:ForeColor := RGB(128,128,128)
var_ConditionalFormat:ApplyTo := 0x1 |
var_ConditionalFormat1 := var_ConditionalFormats:Add("%CT2",nil)
var_ConditionalFormat1:ForeColor := RGB(128,128,128)
var_ConditionalFormat1:ApplyTo := 0x2 |
var_ConditionalFormat2 := var_ConditionalFormats:Add("%CT3",nil)
var_ConditionalFormat2:ForeColor := RGB(128,128,128)
var_ConditionalFormat2:ApplyTo := 0x3 |
var_Columns := oDCOCX_Exontrol1:Columns
var_Columns:Add("Description")
var_Column := IColumn{var_Columns:Add("Qty")}
var_Column:Editor:EditType := SpinType
var_Column:[Def,exTotalColumn] := "sum(current,rec,%1)"
var_Column1 := IColumn{var_Columns:Add("Price")}
var_Column1:[Def,exTotalColumn] := "avg(current,rec,%2)"
var_Column1:Editor:EditType := SpinType
var_Column2 := IColumn{var_Columns:Add("Amount")}
var_Column2:ComputedField := "%1 * %2"
var_Column2:[Def,exTotalColumn] := "sum(current,rec,%3)"
var_Items := oDCOCX_Exontrol1:Items
r := var_Items:AddItem("Root")
g1 := var_Items:InsertItem(r,nil,"Group 1")
h := var_Items:InsertItem(g1,nil,"Item 1")
var_Items:[CellValue,h,1] := 1
var_Items:[CellValue,h,2] := 10
h := var_Items:InsertItem(g1,nil,"Item 2")
var_Items:[CellValue,h,1] := 2
var_Items:[CellValue,h,2] := 11
g2 := var_Items:InsertItem(r,nil,"Group 2")
h := var_Items:InsertItem(g2,nil,"Item 1")
var_Items:[CellValue,h,1] := 3
var_Items:[CellValue,h,2] := 12
h := var_Items:InsertItem(g2,nil,"Item 2")
var_Items:[CellValue,h,1] := 4
var_Items:[CellValue,h,2] := 13
var_Items:[ExpandItem,0] := true
oDCOCX_Exontrol1:EndUpdate()
oDCOCX_Exontrol1:FreezeEvents(false)
|
|
1216
|
How can I configure the filters in the text columns to search by content
local var_Items as IItems
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:FilterBarPromptVisible := exFilterBarPromptVisible
oDCOCX_Exontrol1:HeaderAppearance := None2
oDCOCX_Exontrol1:FilterBarPromptType := exFilterPromptContainsAll
oDCOCX_Exontrol1:Columns:Add("Names")
var_Items := oDCOCX_Exontrol1:Items
var_Items:AddItem("Mantel")
var_Items:AddItem("Mechanik")
var_Items:AddItem("Motor")
var_Items:AddItem("Murks")
var_Items:AddItem("Märchen")
var_Items:AddItem("Möhren")
var_Items:AddItem("Mühle")
var_Items:AddItem("Sérigraphie")
oDCOCX_Exontrol1:FilterBarPromptPattern := "a"
oDCOCX_Exontrol1:EndUpdate()
|
|
1215
|
How can I display the control's captions in Spanish
local var_Column as IColumn
local var_Items as IItems
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:FilterBarPromptVisible := exFilterBarPromptVisible
oDCOCX_Exontrol1:HeaderAppearance := None2
oDCOCX_Exontrol1:[Description,exFilterBarAll] := "(todo) "
oDCOCX_Exontrol1:[Description,exFilterBarFilterForCaption] := "filtrar por..."
oDCOCX_Exontrol1:FilterBarPrompt := "<i><fgcolor=808080>iniciar filtro...</fgcolor></i>"
var_Column := IColumn{oDCOCX_Exontrol1:Columns:Add("Names")}
var_Column:DisplayFilterButton := true
var_Column:FilterType := exPattern
var_Items := oDCOCX_Exontrol1:Items
var_Items:AddItem("Mantel")
var_Items:AddItem("Mechanik")
var_Items:AddItem("Motor")
var_Items:AddItem("Murks")
var_Items:AddItem("Märchen")
var_Items:AddItem("Möhren")
var_Items:AddItem("Mühle")
var_Items:AddItem("Sérigraphie")
oDCOCX_Exontrol1:EndUpdate()
|
|
1214
|
How can I zoom in the control
local var_Column as IColumn
local var_Items as IItems
local s1,s2 as USUAL
oDCOCX_Exontrol1:BeginUpdate()
s1 := 16
s2 := oDCOCX_Exontrol1:FormatABC("2 * value",s1,nil,nil)
oDCOCX_Exontrol1:ImageSize := s2
oDCOCX_Exontrol1:DefaultItemHeight := s2
oDCOCX_Exontrol1:HeaderHeight := s2
oDCOCX_Exontrol1:SortBarHeight := s2
oDCOCX_Exontrol1:Indent := s2
oDCOCX_Exontrol1:Font:Size := s1
oDCOCX_Exontrol1:FilterBarFont:Size := s1
oDCOCX_Exontrol1:ToolTipFont:Size := s1
oDCOCX_Exontrol1:FilterBarPromptVisible := exFilterBarPromptVisible
oDCOCX_Exontrol1:HeaderAppearance := None2
var_Column := IColumn{oDCOCX_Exontrol1:Columns:Add("Names")}
var_Column:DisplayFilterButton := true
var_Column:FilterType := exPattern
var_Items := oDCOCX_Exontrol1:Items
var_Items:AddItem("Mantel")
var_Items:AddItem("Mechanik")
var_Items:AddItem("Motor")
var_Items:AddItem("Murks")
var_Items:AddItem("Märchen")
var_Items:AddItem("Möhren")
var_Items:AddItem("Mühle")
var_Items:AddItem("Sérigraphie")
oDCOCX_Exontrol1:EndUpdate()
|
|
1213
|
Can I set a filter that automatically adds a * before and after the word, so the user can just search for 'cat' and it becomes '*cat*' automatically
local var_Column as IColumn
local var_Items as IItems
local h as USUAL
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:HeaderAppearance := Etched
oDCOCX_Exontrol1:HeaderHeight := 24
oDCOCX_Exontrol1:LinesAtRoot := exLinesAtRoot
var_Column := IColumn{oDCOCX_Exontrol1:Columns:Add("Items")}
var_Column:DisplayFilterButton := true
var_Column:DisplayFilterPattern := true
var_Column:[Def,exFilterPatternTemplate] := "*<%filter%>*"
var_Column:FilterType := exPattern
var_Column:Filter := "1"
var_Items := oDCOCX_Exontrol1:Items
h := var_Items:AddItem("Root 1")
var_Items:InsertItem(h,nil,"Child 1")
var_Items:InsertItem(h,nil,"Child 2")
var_Items:[ExpandItem,h] := true
h := var_Items:AddItem("Root 2")
var_Items:InsertItem(h,nil,"Child 1")
var_Items:InsertItem(h,nil,"Child 2")
oDCOCX_Exontrol1:ApplyFilter()
oDCOCX_Exontrol1:EndUpdate()
|
|
1212
|
The fine dotted lines in the control appear much thicker than the standard ones we've been using. How can we fix this
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:HeaderAppearance := Etched
oDCOCX_Exontrol1:HeaderHeight := 24
oDCOCX_Exontrol1:DrawGridLines := exAllLines
oDCOCX_Exontrol1:GridLineStyle := exGridLinesGeometric
oDCOCX_Exontrol1:ColumnAutoResize := false
oDCOCX_Exontrol1:Columns:Add("Column 1")
oDCOCX_Exontrol1:Columns:Add("Column 2")
oDCOCX_Exontrol1:Columns:Add("Column 3")
oDCOCX_Exontrol1:Columns:Add("Column 4")
oDCOCX_Exontrol1:EndUpdate()
|
|
1211
|
Load data as a tree using a parent-id relationship
local rs as _Recordset
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:ColumnAutoResize := false
oDCOCX_Exontrol1:HeaderAppearance := Etched
oDCOCX_Exontrol1:HeaderHeight := 24
oDCOCX_Exontrol1:DrawGridLines := exVLines
oDCOCX_Exontrol1:LinesAtRoot := exLinesAtRoot
// Generate Source for 'Microsoft ActiveX Data Objects 6.1 Library(msado15.dll)' server from Tools\Automation Server...
rs := _Recordset{"ADODB.Recordset"}
rs:Open("Select * FROM Employees WHERE 1=0","Provider=Microsoft.ACE.OLEDB.12.0;Data Source=C:\Program Files\Exontrol\ExGrid\Sample\Access\misc.mdb",3,3,0)
oDCOCX_Exontrol1:DataSource := _Recordset{rs}
oDCOCX_Exontrol1:Columns:[Item,0]:Width := 128
rs := _Recordset{"ADODB.Recordset"}
rs:Open("Employees","Provider=Microsoft.ACE.OLEDB.12.0;Data Source=C:\Program Files\Exontrol\ExGrid\Sample\Access\misc.mdb",3,3,0)
oDCOCX_Exontrol1:PutItems(rs:GetRows(0,nil,nil),";0;17")
oDCOCX_Exontrol1:Items:[ExpandItem,0] := true
oDCOCX_Exontrol1:EndUpdate()
|
|
1210
|
Is there a way to change the contents of the drop down editor based on a value in another column
METHOD OCX_Exontrol1AddItem(Item) CLASS MainDialog
// AddItem event - Occurs after a new Item has been inserted to Items collection.
oDCOCX_Exontrol1:Items:[CellEditorVisible,Item,0] := exEditorVisible
oDCOCX_Exontrol1:Items:[CellEditorVisible,Item,1] := exEditorVisible
RETURN NIL
METHOD OCX_Exontrol1EditOpen() CLASS MainDialog
// EditOpen event - Occurs when the edit operation starts.
local var_Editor as IEditor
local var_Items as IItems
local c,v as USUAL
var_Items := oDCOCX_Exontrol1:Items
v := var_Items:[CellValue,var_Items:FocusItem,0]
c := var_Items:[CellCaption,var_Items:FocusItem,0]
var_Editor := oDCOCX_Exontrol1:Columns:[Item,1]:Editor
var_Editor:ClearItems()
var_Editor:AddItem(v,AsString(c),nil)
RETURN NIL
local var_Column as IColumn
local var_Editor as IEditor
local var_Items as IItems
local h as USUAL
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:HeaderAppearance := Etched
oDCOCX_Exontrol1:HeaderHeight := 24
oDCOCX_Exontrol1:GridLineStyle := exGridLinesGeometric
var_Column := IColumn{oDCOCX_Exontrol1:Columns:Add("DropDownList")}
var_Editor := var_Column:Editor
var_Editor:EditType := DropDownListType
var_Editor:AddItem(1,"First",nil)
var_Editor:AddItem(2,"Second",nil)
var_Editor:AddItem(3,"Third",nil)
oDCOCX_Exontrol1:DrawGridLines := exAllLines
IColumn{oDCOCX_Exontrol1:Columns:Add("DropDownList-Related")}:Editor:EditType := DropDownListType
var_Items := oDCOCX_Exontrol1:Items
var_Items:[CellValue,var_Items:AddItem(1),1] := -1
var_Items:[CellValue,var_Items:AddItem(2),1] := -1
var_Items:[CellValue,var_Items:AddItem(3),1] := -1
var_Items:[LockedItemCount,exBottom] := 1
h := var_Items:[LockedItem,exBottom,0]
var_Items:[ItemDivider,h] := 0
var_Items:[ItemDividerLineAlignment,h] := DividerTop
var_Items:[CellEditorVisible,h,0] := exEditorHidden
var_Items:[CellSingleLine,h,0] := exCaptionWordWrap
var_Items:[CellValueFormat,h,0] := exHTML
var_Items:[CellValue,h,0] := "The drop down editor in the second column is filled during the <b>EditOpen event</b>, and the values are based on the selection on the first column."
oDCOCX_Exontrol1:EndUpdate()
|
|
1209
|
Highlight the editable fields
METHOD OCX_Exontrol1Change(Item,ColIndex,NewValue) CLASS MainDialog
// Change event - Occurs when the user changes the cell's content.
oDCOCX_Exontrol1:Refresh()
RETURN NIL
local var_Column,var_Column1,var_Column2 as IColumn
local var_Columns as IColumns
local var_ConditionalFormat,var_ConditionalFormat1,var_ConditionalFormat2 as IConditionalFormat
local var_ConditionalFormats as IConditionalFormats
local var_Items as IItems
local g1,g2,h,r as USUAL
oDCOCX_Exontrol1:FreezeEvents(true)
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:HeaderAppearance := Etched
oDCOCX_Exontrol1:HeaderHeight := 24
oDCOCX_Exontrol1:LinesAtRoot := exLinesAtRoot
var_ConditionalFormats := oDCOCX_Exontrol1:ConditionalFormats
var_ConditionalFormat := var_ConditionalFormats:Add("%CE1",nil)
var_ConditionalFormat:Bold := true
var_ConditionalFormat:BackColor := RGB(245,245,245)
var_ConditionalFormat:ApplyTo := 0x1 |
var_ConditionalFormat1 := var_ConditionalFormats:Add("%CE2",nil)
var_ConditionalFormat1:Bold := true
var_ConditionalFormat1:BackColor := RGB(245,245,245)
var_ConditionalFormat1:ApplyTo := 0x2 |
var_ConditionalFormat2 := var_ConditionalFormats:Add("%CE3",nil)
var_ConditionalFormat2:Bold := true
var_ConditionalFormat2:BackColor := RGB(245,245,245)
var_ConditionalFormat2:ApplyTo := 0x3 |
var_Columns := oDCOCX_Exontrol1:Columns
var_Columns:Add("Description")
var_Column := IColumn{var_Columns:Add("Qty")}
var_Column:Editor:EditType := SpinType
var_Column:[Def,exTotalColumn] := "sum(current,rec,%1)"
var_Column1 := IColumn{var_Columns:Add("Price")}
var_Column1:[Def,exTotalColumn] := "avg(current,rec,%2)"
var_Column1:Editor:EditType := SpinType
var_Column2 := IColumn{var_Columns:Add("Amount")}
var_Column2:ComputedField := "%1 * %2"
var_Column2:[Def,exTotalColumn] := "sum(current,rec,%3)"
var_Items := oDCOCX_Exontrol1:Items
r := var_Items:AddItem("Root")
g1 := var_Items:InsertItem(r,nil,"Group 1")
h := var_Items:InsertItem(g1,nil,"Item 1")
var_Items:[CellValue,h,1] := 1
var_Items:[CellValue,h,2] := 10
h := var_Items:InsertItem(g1,nil,"Item 2")
var_Items:[CellValue,h,1] := 2
var_Items:[CellValue,h,2] := 11
g2 := var_Items:InsertItem(r,nil,"Group 2")
h := var_Items:InsertItem(g2,nil,"Item 1")
var_Items:[CellValue,h,1] := 3
var_Items:[CellValue,h,2] := 12
h := var_Items:InsertItem(g2,nil,"Item 2")
var_Items:[CellValue,h,1] := 4
var_Items:[CellValue,h,2] := 13
var_Items:[ExpandItem,0] := true
oDCOCX_Exontrol1:EndUpdate()
oDCOCX_Exontrol1:FreezeEvents(false)
|
|
1208
|
Highlight the total fields
METHOD OCX_Exontrol1Change(Item,ColIndex,NewValue) CLASS MainDialog
// Change event - Occurs when the user changes the cell's content.
oDCOCX_Exontrol1:Refresh()
RETURN NIL
local var_Column,var_Column1,var_Column2 as IColumn
local var_Columns as IColumns
local var_ConditionalFormat,var_ConditionalFormat1,var_ConditionalFormat2 as IConditionalFormat
local var_ConditionalFormats as IConditionalFormats
local var_Items as IItems
local g1,g2,h,r as USUAL
oDCOCX_Exontrol1:FreezeEvents(true)
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:HeaderAppearance := Etched
oDCOCX_Exontrol1:HeaderHeight := 24
oDCOCX_Exontrol1:LinesAtRoot := exLinesAtRoot
var_ConditionalFormats := oDCOCX_Exontrol1:ConditionalFormats
var_ConditionalFormat := var_ConditionalFormats:Add("%CT1",nil)
var_ConditionalFormat:ForeColor := RGB(128,128,128)
var_ConditionalFormat:ApplyTo := 0x1 |
var_ConditionalFormat1 := var_ConditionalFormats:Add("%CT2",nil)
var_ConditionalFormat1:ForeColor := RGB(128,128,128)
var_ConditionalFormat1:ApplyTo := 0x2 |
var_ConditionalFormat2 := var_ConditionalFormats:Add("%CT3",nil)
var_ConditionalFormat2:ForeColor := RGB(128,128,128)
var_ConditionalFormat2:ApplyTo := 0x3 |
var_Columns := oDCOCX_Exontrol1:Columns
var_Columns:Add("Description")
var_Column := IColumn{var_Columns:Add("Qty")}
var_Column:Editor:EditType := SpinType
var_Column:[Def,exTotalColumn] := "sum(current,rec,%1)"
var_Column1 := IColumn{var_Columns:Add("Price")}
var_Column1:[Def,exTotalColumn] := "avg(current,rec,%2)"
var_Column1:Editor:EditType := SpinType
var_Column2 := IColumn{var_Columns:Add("Amount")}
var_Column2:ComputedField := "%1 * %2"
var_Column2:[Def,exTotalColumn] := "sum(current,rec,%3)"
var_Items := oDCOCX_Exontrol1:Items
r := var_Items:AddItem("Root")
g1 := var_Items:InsertItem(r,nil,"Group 1")
h := var_Items:InsertItem(g1,nil,"Item 1")
var_Items:[CellValue,h,1] := 1
var_Items:[CellValue,h,2] := 10
h := var_Items:InsertItem(g1,nil,"Item 2")
var_Items:[CellValue,h,1] := 2
var_Items:[CellValue,h,2] := 11
g2 := var_Items:InsertItem(r,nil,"Group 2")
h := var_Items:InsertItem(g2,nil,"Item 1")
var_Items:[CellValue,h,1] := 3
var_Items:[CellValue,h,2] := 12
h := var_Items:InsertItem(g2,nil,"Item 2")
var_Items:[CellValue,h,1] := 4
var_Items:[CellValue,h,2] := 13
var_Items:[ExpandItem,0] := true
oDCOCX_Exontrol1:EndUpdate()
oDCOCX_Exontrol1:FreezeEvents(false)
|
|
1207
|
Highlight the leaf items
local var_Columns as IColumns
local var_Items as IItems
local h,hR as USUAL
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:ConditionalFormats:Add("%CC0=0",nil):ForeColor := RGB(128,128,128)
oDCOCX_Exontrol1:HeaderAppearance := Etched
oDCOCX_Exontrol1:HeaderHeight := 24
oDCOCX_Exontrol1:LinesAtRoot := exLinesAtRoot
var_Columns := oDCOCX_Exontrol1:Columns
IColumn{var_Columns:Add("Item")}:Width := 16
var_Columns:Add("Desc")
var_Items := oDCOCX_Exontrol1:Items
hR := var_Items:AddItem("Root")
var_Items:[CellValue,hR,1] := "The root directory /"
var_Items:[ExpandItem,hR] := true
h := var_Items:InsertItem(hR,nil,"Home")
var_Items:[CellValue,h,1] := "The home directory with user directories Alice and Bob"
var_Items:InsertItem(h,nil,"Alice")
var_Items:InsertItem(h,nil,"Bob")
var_Items:[ExpandItem,h] := true
h := var_Items:InsertItem(hR,nil,"Etc")
var_Items:[CellValue,h,1] := "The etc directory with one configuration file"
h := var_Items:InsertItem(h,nil,"nginx.conf")
var_Items:[CellValue,var_Items:InsertItem(hR,nil,"Var"),1] := "The var directory"
oDCOCX_Exontrol1:EndUpdate()
|
|
1206
|
Highlight the parent items
local var_Columns as IColumns
local var_Items as IItems
local h,hR as USUAL
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:ConditionalFormats:Add("%CC0",nil):ForeColor := RGB(255,0,0)
oDCOCX_Exontrol1:HeaderAppearance := Etched
oDCOCX_Exontrol1:HeaderHeight := 24
oDCOCX_Exontrol1:LinesAtRoot := exLinesAtRoot
var_Columns := oDCOCX_Exontrol1:Columns
IColumn{var_Columns:Add("Item")}:Width := 16
var_Columns:Add("Desc")
var_Items := oDCOCX_Exontrol1:Items
hR := var_Items:AddItem("Root")
var_Items:[CellValue,hR,1] := "The root directory /"
var_Items:[ExpandItem,hR] := true
h := var_Items:InsertItem(hR,nil,"Home")
var_Items:[CellValue,h,1] := "The home directory with user directories Alice and Bob"
var_Items:InsertItem(h,nil,"Alice")
var_Items:InsertItem(h,nil,"Bob")
var_Items:[ExpandItem,h] := true
h := var_Items:InsertItem(hR,nil,"Etc")
var_Items:[CellValue,h,1] := "The etc directory with one configuration file"
h := var_Items:InsertItem(h,nil,"nginx.conf")
var_Items:[CellValue,var_Items:InsertItem(hR,nil,"Var"),1] := "The var directory"
oDCOCX_Exontrol1:EndUpdate()
|
|
1205
|
Highlight the item being expanded or collapsed
local var_Columns as IColumns
local var_Items as IItems
local h,hR as USUAL
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:ConditionalFormats:Add("%CX0",nil):Bold := true
oDCOCX_Exontrol1:HeaderAppearance := Etched
oDCOCX_Exontrol1:HeaderHeight := 24
oDCOCX_Exontrol1:LinesAtRoot := exLinesAtRoot
var_Columns := oDCOCX_Exontrol1:Columns
IColumn{var_Columns:Add("Item")}:Width := 16
var_Columns:Add("Desc")
var_Items := oDCOCX_Exontrol1:Items
hR := var_Items:AddItem("Root")
var_Items:[CellValue,hR,1] := "The root directory /"
var_Items:[ExpandItem,hR] := true
h := var_Items:InsertItem(hR,nil,"Home")
var_Items:[CellValue,h,1] := "The home directory with user directories Alice and Bob"
var_Items:InsertItem(h,nil,"Alice")
var_Items:InsertItem(h,nil,"Bob")
var_Items:[ExpandItem,h] := true
h := var_Items:InsertItem(hR,nil,"Etc")
var_Items:[CellValue,h,1] := "The etc directory with one configuration file"
h := var_Items:InsertItem(h,nil,"nginx.conf")
var_Items:[CellValue,var_Items:InsertItem(hR,nil,"Var"),1] := "The var directory"
oDCOCX_Exontrol1:EndUpdate()
|
|
1204
|
I am using exTotalColumn. Is there an option to exclude specific cells to display the total
METHOD OCX_Exontrol1Change(Item,ColIndex,NewValue) CLASS MainDialog
// Change event - Occurs when the user changes the cell's content.
oDCOCX_Exontrol1:Refresh()
RETURN NIL
local var_Column,var_Column1,var_Column2 as IColumn
local var_Columns as IColumns
local var_Items as IItems
local g1,g2,h,r as USUAL
oDCOCX_Exontrol1:FreezeEvents(true)
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:HeaderAppearance := Etched
oDCOCX_Exontrol1:HeaderHeight := 24
oDCOCX_Exontrol1:LinesAtRoot := exLinesAtRoot
var_Columns := oDCOCX_Exontrol1:Columns
var_Columns:Add("Description")
var_Column := IColumn{var_Columns:Add("Qty")}
var_Column:Editor:EditType := SpinType
var_Column:[Def,exTotalColumn] := "sum(current,rec,%1)"
var_Column1 := IColumn{var_Columns:Add("Price")}
var_Column1:[Def,exTotalColumn] := "avg(current,rec,%2)"
var_Column1:Editor:EditType := SpinType
var_Column2 := IColumn{var_Columns:Add("Amount")}
var_Column2:ComputedField := "%1 * %2"
var_Column2:[Def,exTotalColumn] := "sum(current,rec,%3)"
var_Items := oDCOCX_Exontrol1:Items
r := var_Items:AddItem("Root")
g1 := var_Items:InsertItem(r,nil,"Group 1")
var_Items:[FormatCell,g1,2] := "`<average missing>`"
var_Items:[CellEditorVisible,g1,2] := exEditorHidden
var_Items:[CellBold,g1,2] := true
var_Items:[CellForeColor,g1,2] := RGB(255,0,0)
h := var_Items:InsertItem(g1,nil,"Item 1")
var_Items:[CellValue,h,1] := 1
var_Items:[CellValue,h,2] := 10
h := var_Items:InsertItem(g1,nil,"Item 2")
var_Items:[CellValue,h,1] := 2
var_Items:[CellValue,h,2] := 11
g2 := var_Items:InsertItem(r,nil,"Group 2")
h := var_Items:InsertItem(g2,nil,"Item 1")
var_Items:[CellValue,h,1] := 3
var_Items:[CellValue,h,2] := 12
h := var_Items:InsertItem(g2,nil,"Item 2")
var_Items:[CellValue,h,1] := 4
var_Items:[CellValue,h,2] := 13
var_Items:[ExpandItem,0] := true
oDCOCX_Exontrol1:EndUpdate()
oDCOCX_Exontrol1:FreezeEvents(false)
|
|
1203
|
How can I add a total column
METHOD OCX_Exontrol1Change(Item,ColIndex,NewValue) CLASS MainDialog
// Change event - Occurs when the user changes the cell's content.
oDCOCX_Exontrol1:Refresh()
RETURN NIL
local var_Column,var_Column1,var_Column2 as IColumn
local var_Columns as IColumns
local var_Items as IItems
local g1,g2,h,r as USUAL
oDCOCX_Exontrol1:FreezeEvents(true)
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:HeaderAppearance := Etched
oDCOCX_Exontrol1:HeaderHeight := 24
oDCOCX_Exontrol1:LinesAtRoot := exLinesAtRoot
var_Columns := oDCOCX_Exontrol1:Columns
var_Columns:Add("Description")
var_Column := IColumn{var_Columns:Add("Qty")}
var_Column:Editor:EditType := SpinType
var_Column:[Def,exTotalColumn] := "sum(current,rec,%1)"
var_Column1 := IColumn{var_Columns:Add("Price")}
var_Column1:[Def,exTotalColumn] := "avg(current,rec,%2)"
var_Column1:Editor:EditType := SpinType
var_Column2 := IColumn{var_Columns:Add("Amount")}
var_Column2:ComputedField := "%1 * %2"
var_Column2:[Def,exTotalColumn] := "sum(current,rec,%3)"
var_Items := oDCOCX_Exontrol1:Items
r := var_Items:AddItem("Root")
g1 := var_Items:InsertItem(r,nil,"Group 1")
h := var_Items:InsertItem(g1,nil,"Item 1")
var_Items:[CellValue,h,1] := 1
var_Items:[CellValue,h,2] := 10
h := var_Items:InsertItem(g1,nil,"Item 2")
var_Items:[CellValue,h,1] := 2
var_Items:[CellValue,h,2] := 11
g2 := var_Items:InsertItem(r,nil,"Group 2")
h := var_Items:InsertItem(g2,nil,"Item 1")
var_Items:[CellValue,h,1] := 3
var_Items:[CellValue,h,2] := 12
h := var_Items:InsertItem(g2,nil,"Item 2")
var_Items:[CellValue,h,1] := 4
var_Items:[CellValue,h,2] := 13
var_Items:[ExpandItem,0] := true
oDCOCX_Exontrol1:EndUpdate()
oDCOCX_Exontrol1:FreezeEvents(false)
|
|
1202
|
Is it possible to disable sizing(size) the column
local var_Column as IColumn
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:HeaderAppearance := Etched
oDCOCX_Exontrol1:DrawGridLines := exVLines
var_Column := IColumn{oDCOCX_Exontrol1:Columns:Add("32px")}
var_Column:Width := 32
var_Column:AllowSizing := false
oDCOCX_Exontrol1:Columns:Add("Rest")
oDCOCX_Exontrol1:ColumnAutoResize := true
oDCOCX_Exontrol1:EndUpdate()
|
|
1201
|
How can I add two columns of 25% and the third of 50%
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:HeaderAppearance := Etched
oDCOCX_Exontrol1:DrawGridLines := exVLines
IColumn{oDCOCX_Exontrol1:Columns:Add("25%")}:Width := 25
IColumn{oDCOCX_Exontrol1:Columns:Add("25%")}:Width := 25
IColumn{oDCOCX_Exontrol1:Columns:Add("50%")}:Width := 50
oDCOCX_Exontrol1:ColumnAutoResize := true
oDCOCX_Exontrol1:EndUpdate()
|
|
1200
|
I add two columns but I see a third column
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:HeaderAppearance := Etched
oDCOCX_Exontrol1:DrawGridLines := exVLines
oDCOCX_Exontrol1:Columns:Add("C1")
oDCOCX_Exontrol1:Columns:Add("C2")
oDCOCX_Exontrol1:ColumnAutoResize := true
oDCOCX_Exontrol1:EndUpdate()
|
|
1199
|
I lose the hierarchy, all items are on the same 1st level, while I use PutItems
local var_Items as IItems
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:LinesAtRoot := exLinesAtRoot
oDCOCX_Exontrol1:Columns:Add("C1")
oDCOCX_Exontrol1:Columns:Add("C2")
var_Items := oDCOCX_Exontrol1:Items
var_Items:[CellValue,var_Items:AddItem("Emily"),1] := "William"
var_Items:[CellValue,var_Items:AddItem("Sophia"),1] := "Alexander"
oDCOCX_Exontrol1:PutItems(oDCOCX_Exontrol1:GetItems(""),oDCOCX_Exontrol1:Items:[ItemByIndex,0])
oDCOCX_Exontrol1:PutItems(oDCOCX_Exontrol1:GetItems(""),oDCOCX_Exontrol1:Items:[ItemByIndex,1])
oDCOCX_Exontrol1:PutItems(oDCOCX_Exontrol1:GetItems(""),oDCOCX_Exontrol1:Items:[ItemByIndex,6])
oDCOCX_Exontrol1:Items:[ExpandItem,0] := true
oDCOCX_Exontrol1:EndUpdate()
|
|
1198
|
Column width set by code is ignored or it seems that does not work
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:ColumnAutoResize := false
oDCOCX_Exontrol1:HeaderAppearance := Etched
oDCOCX_Exontrol1:DrawGridLines := exVLines
IColumn{oDCOCX_Exontrol1:Columns:Add("C1")}:Width := 32
IColumn{oDCOCX_Exontrol1:Columns:Add("C2")}:Width := 132
IColumn{oDCOCX_Exontrol1:Columns:Add("C3")}:Width := 264
oDCOCX_Exontrol1:EndUpdate()
|
|
1197
|
I want to display this computed value in a TextBox outside the grid and get it updated with any change of its value. How can this be done
METHOD OCX_Exontrol1Change(Item,ColIndex,NewValue) CLASS MainDialog
// Change event - Occurs when the user changes the cell's content.
local var_Items as IItems
oDCOCX_Exontrol1:Refresh()
var_Items := oDCOCX_Exontrol1:Items
OutputDebugString(String2Psz( "Total: " ))
OutputDebugString(String2Psz( var_Items:[CellCaption,var_Items:[LockedItem,exTop,0],0] ))
RETURN NIL
local var_Column as IColumn
local var_Editor as IEditor
local var_Items,var_Items1 as IItems
local h as USUAL
oDCOCX_Exontrol1:BeginUpdate()
var_Column := IColumn{oDCOCX_Exontrol1:Columns:Add("Numbers")}
var_Editor := var_Column:Editor
var_Editor:Numeric := exInteger
var_Editor:EditType := SpinType
var_Column:SortType := SortNumeric
var_Items := oDCOCX_Exontrol1:Items
var_Items:[LockedItemCount,exTop] := 1
h := var_Items:[LockedItem,exTop,0]
var_Items:[ItemBackColor,h] := RGB(240,240,240)
var_Items:[CellValue,h,0] := "sum(all,dir,dbl(%0))"
var_Items:[CellValueFormat,h,0] := exTotalField
var_Items:[CellHAlignment,h,0] := RightAlignment
var_Items:[FormatCell,h,0] := "'Total: '+value"
var_Items1 := oDCOCX_Exontrol1:Items
var_Items1:AddItem(10)
var_Items1:AddItem(25)
var_Items1:AddItem(31)
var_Items1:AddItem(48)
oDCOCX_Exontrol1:EndUpdate()
|
|
1196
|
Disable temporarily the column's sort, resize and drag and drop
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:SortBarVisible := true
oDCOCX_Exontrol1:SortBarCaption := "<fgcolor 808080><c>the header and the sort-bar are disabled (no drag and drop is allowed)"
oDCOCX_Exontrol1:AllowGroupBy := true
oDCOCX_Exontrol1:HeaderEnabled := false
oDCOCX_Exontrol1:HeaderAppearance := Etched
IColumn{oDCOCX_Exontrol1:Columns:Add("Index")}:FormatColumn := "1 index ``"
IColumn{oDCOCX_Exontrol1:Columns:Add("Pos")}:FormatColumn := "1 apos ``"
IColumn{oDCOCX_Exontrol1:Columns:Add("Edit")}:Editor:EditType := EditType
oDCOCX_Exontrol1:GridLineStyle := exGridLinesGeometric
oDCOCX_Exontrol1:DrawGridLines := exVLines
oDCOCX_Exontrol1:GridLineColor := RGB(224,224,224)
oDCOCX_Exontrol1:EndUpdate()
|
|
1195
|
I wonder if it’s possible to highlight/select a column like Excel
METHOD OCX_Exontrol1ColumnClick(Column) CLASS MainDialog
// ColumnClick event - Fired after the user clicks on column's header.
// Column.Selected = True
// FocusColumnIndex = Column.Index
oDCOCX_Exontrol1:Columns:[Item,0]:Selected := false
oDCOCX_Exontrol1:Columns:[Item,1]:Selected := false
oDCOCX_Exontrol1:Columns:[Item,2]:Selected := false
oDCOCX_Exontrol1:Items:SelectAll()
RETURN NIL
local var_Items as IItems
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:[Background,exCursorHoverColumn] := -1
oDCOCX_Exontrol1:HeaderAppearance := Etched
oDCOCX_Exontrol1:MarkSearchColumn := false
oDCOCX_Exontrol1:SingleSel := false
oDCOCX_Exontrol1:FullRowSelect := exRectSel
oDCOCX_Exontrol1:SortOnClick := exNoSort
oDCOCX_Exontrol1:Columns:Add("Column1")
oDCOCX_Exontrol1:Columns:Add("Column2")
oDCOCX_Exontrol1:Columns:Add("Column3")
var_Items := oDCOCX_Exontrol1:Items
var_Items:DefaultItem := var_Items:AddItem(0)
var_Items:[CellValue,0,1] := 1
var_Items:[CellValue,0,2] := 2
var_Items:DefaultItem := var_Items:AddItem(3)
var_Items:[CellValue,0,1] := 4
var_Items:[CellValue,0,2] := 5
var_Items:DefaultItem := var_Items:AddItem(6)
var_Items:[CellValue,0,1] := 7
var_Items:[CellValue,0,2] := 8
oDCOCX_Exontrol1:EndUpdate()
|
|
1194
|
Is it possible to change the color of the border
local var_Items as IItems
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:VisualAppearance:Add(1,"gBFLBCJwBAEHhEJAAEhABc8IQAAYAQGKIcBiAKBQAGaAoDDMMwyQwAAxDMK8EwsACEIrjKCRShyCYZRhGcTALBIBQSHAZZKgOJIRDENg2SANACRfIUaw1DqBZwkGZoWhGKgAShIEDwSKkQBlECeJpnKaqIomJYnDLQUw0NL9HQ3JaaKqnWLBVCWEQyVzEIyjBT0EzHMqtKrjaA6NpaP4oT7LEIydKFCRJNi0bSnGqaOj6UJSURRVq3TTFcTyAC3ahuOo4cpXB4SWrOd41fYNOTQACzbCsSIcPxCe6GXjiNwjPKMWhnIq+M5wXIrJyKCYUaTcejzfgdU5XWqeMoyewMXxmZqbXw/fBYRrEL5vTqNXTzSA4BEB")
oDCOCX_Exontrol1:Appearance := 0x100ff00 |
oDCOCX_Exontrol1:ColumnAutoResize := true
oDCOCX_Exontrol1:HeaderAppearance := Etched
oDCOCX_Exontrol1:TreeColumnIndex := -1
oDCOCX_Exontrol1:DrawGridLines := exAllLines
oDCOCX_Exontrol1:GridLineStyle := exGridLinesGeometric
oDCOCX_Exontrol1:Columns:Add("Default")
var_Items := oDCOCX_Exontrol1:Items
var_Items:AddItem("before item")
var_Items:AddItem("item")
var_Items:AddItem("after item")
oDCOCX_Exontrol1:EndUpdate()
|
|
1193
|
Expandable-caption
METHOD OCX_Exontrol1AnchorClick(AnchorID,Options) CLASS MainDialog
// AnchorClick event - Occurs when an anchor element is clicked.
OutputDebugString(String2Psz( AsString(AnchorID) ))
RETURN NIL
local var_Items as IItems
local h as USUAL
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:ColumnAutoResize := true
oDCOCX_Exontrol1:TreeColumnIndex := -1
oDCOCX_Exontrol1:DrawGridLines := exAllLines
oDCOCX_Exontrol1:GridLineStyle := exGridLinesGeometric
oDCOCX_Exontrol1:BackColorAlternate := RGB(240,240,240)
oDCOCX_Exontrol1:ShowFocusRect := false
oDCOCX_Exontrol1:Columns:Add("Default")
var_Items := oDCOCX_Exontrol1:Items
var_Items:AddItem("before item")
h := var_Items:AddItem("<solidline> <c><b>Bank Account</b></solidline><br>+ owner: String <r><a 1;e64=gA8ABzABvABsABpABkg8JABuABlAA+AAgAECMcTi4AMwAM4AjMGhEGOUVAA4AAwk8plcqihwAElg0wiUlOkOiUEgQvgcFhsKhkIhUQiUUnccj0gn0jmMagUlowAMNOpEfkMNkkmlEqrctjQmAAjAA5AA2sssHcbnkdq1Ln1QtVSjQAAEBA==>▲</a><br><solidline>+ balance: Currency = 0</solidline><br>+ deposit(amount: Currency)<r><a 2;e64=gA8ABjAA+AECMwAM8DABvABshoAOQAEAAHAAGEWjEajMGNoAMoAOgANERMgAOcHAAvAEJhcEh0Qh0Tg0CmkqMMFlUuhkxiMTisXjNCjk6EwAEYAHIAG1MjY7lUsnkwh8/nUClk5gwAAEBA==>▲</a><br>+ withdraw(amount: Currency)")
var_Items:[CellValueFormat,h,0] := exHTML
var_Items:[CellSingleLine,h,0] := exCaptionWordWrap
var_Items:AddItem("after item")
oDCOCX_Exontrol1:EndUpdate()
|
|
1192
|
Expandable-caption
local var_Items as IItems
local h as USUAL
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:ColumnAutoResize := true
oDCOCX_Exontrol1:TreeColumnIndex := -1
oDCOCX_Exontrol1:DrawGridLines := exAllLines
oDCOCX_Exontrol1:GridLineStyle := exGridLinesGeometric
oDCOCX_Exontrol1:BackColorAlternate := RGB(240,240,240)
oDCOCX_Exontrol1:ShowFocusRect := false
oDCOCX_Exontrol1:Columns:Add("Default")
var_Items := oDCOCX_Exontrol1:Items
var_Items:AddItem("before item")
h := var_Items:AddItem("<solidline><b>Header</b></solidline><br>Line1<r><a ;exp=show lines>+</a><br>Line2<br>Line3")
var_Items:[CellValueFormat,h,0] := exHTML
var_Items:[CellSingleLine,h,0] := exCaptionWordWrap
var_Items:AddItem("after item")
oDCOCX_Exontrol1:EndUpdate()
|
|
1191
|
Force hover-all feature
oDCOCX_Exontrol1:[Background,exScrollHoverAll] := -1
|
|
1190
|
Disable hover-all feature (Windows 11 or greater)
oDCOCX_Exontrol1:[Background,exScrollHoverAll] := RGB(1,0,0)
|
|
1189
|
Display a custom tooltip
METHOD OCX_Exontrol1MouseMove(Button,Shift,X,Y) CLASS MainDialog
// MouseMove event - Occurs when the user moves the mouse.
oDCOCX_Exontrol1:ShowToolTip("new content","",nil,"+8","+8")
RETURN NIL
|
|
1188
|
Shows the tooltip of the object moved relative to its default position
METHOD OCX_Exontrol1MouseMove(Button,Shift,X,Y) CLASS MainDialog
// MouseMove event - Occurs when the user moves the mouse.
oDCOCX_Exontrol1:ShowToolTip("<null>","<null>",nil,"+8","+8")
RETURN NIL
oDCOCX_Exontrol1:ColumnAutoResize := false
IColumn{oDCOCX_Exontrol1:Columns:Add("tootip")}:ToolTip := "this is a tooltip assigned to a column"
|
|
1187
|
Delete all records
METHOD OCX_Exontrol1ButtonClick(Item,ColIndex,Key) CLASS MainDialog
// ButtonClick event - Occurs when user clicks on the cell's button.
local cmd as _Command
// Generate Source for 'Microsoft ActiveX Data Objects 6.1 Library(msado15.dll)' server from Tools\Automation Server...
cmd := _Command{"ADODB.Command"}
cmd:ActiveConnection := _Connection{oDCOCX_Exontrol1_Recordset{:DataSource}:ActiveConnection}
cmd:CommandText := "Delete * from ORDERS"
cmd:CommandType := 1
cmd:Execute(nil,nil,0)
_Recordset{oDCOCX_Exontrol1:DataSource}:Requery(0)
RETURN NIL
METHOD OCX_Exontrol1Error(Error,Description) CLASS MainDialog
// Error event - Fired when an internal error occurs.
OutputDebugString(String2Psz( AsString(Description) ))
RETURN NIL
local var_Items as IItems
local h as USUAL
local rs as _Recordset
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:HeaderAppearance := Etched
oDCOCX_Exontrol1:ColumnAutoResize := false
rs := _Recordset{"ADODB.Recordset"}
rs:Open("Select * From Orders","Provider=Microsoft.ACE.OLEDB.12.0;Data Source=C:\Program Files\Exontrol\ExGrid\Sample\Access\misc.accdb",1,3,0)
oDCOCX_Exontrol1:DataSource := _Recordset{rs}
oDCOCX_Exontrol1:ConditionalFormats:Add("%1=12345",nil):BackColor := RGB(240,240,240)
var_Items := oDCOCX_Exontrol1:Items
var_Items:[LockedItemCount,exTop] := 1
h := var_Items:[LockedItem,exTop,0]
var_Items:[ItemDivider,h] := 0
var_Items:[CellHasButton,h,0] := true
var_Items:[CellValue,h,0] := "Requery (delete all records, using ADODB.Command)"
var_Items:[CellHAlignment,h,0] := CenterAlignment
oDCOCX_Exontrol1:EndUpdate()
|
|
1186
|
How can I get a cell that shows the sum of a column of minutes in hours + minutes format
local var_Column as IColumn
local var_Editor as IEditor
local var_Items as IItems
local h as USUAL
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:HeaderAppearance := Etched
var_Column := IColumn{oDCOCX_Exontrol1:Columns:Add("Minutes")}
var_Column:SortType := SortNumeric
var_Editor := var_Column:Editor
var_Editor:EditType := EditType
var_Editor:Numeric := exInteger
var_Items := oDCOCX_Exontrol1:Items
var_Items:AddItem(10)
var_Items:AddItem(20)
var_Items:AddItem(30)
var_Items:AddItem(40)
var_Items:AddItem(50)
h := var_Items:AddItem("sum(all,dir,dbl(%0))")
var_Items:[SelectableItem,h] := false
var_Items:[SortableItem,h] := false
var_Items:[CellValueFormat,h,0] := exTotalField | exHTML
var_Items:[CellHAlignment,h,0] := RightAlignment
var_Items:[FormatCell,h,0] := "'<b>HH:NN</b>: '+ (int(value/60) lpad '00') + ':' + ((value mod 60) lpad '00')"
oDCOCX_Exontrol1:EndUpdate()
|
|
1185
|
Highlight the match once the filter is applied
METHOD OCX_Exontrol1FilterChange() CLASS MainDialog
// FilterChange event - Occurs when filter was changed.
local format as USUAL
format := oDCOCX_Exontrol1:FormatABC("`lower(value) replace lower('` + value + `') with '<bgcolor 000000><fgcolor FFFFFF>` + value + `</fgcolor></bgcolor>'`",oDCOCX_Exontrol1:FilterBarPromptPattern,nil,nil)
oDCOCX_Exontrol1:Columns:[Item,0]:FormatColumn := AsString(format)
oDCOCX_Exontrol1:Columns:[Item,1]:FormatColumn := AsString(format)
oDCOCX_Exontrol1:Columns:[Item,2]:FormatColumn := AsString(format)
RETURN NIL
local var_Column,var_Column1,var_Column2 as IColumn
local var_Columns as IColumns
local var_Items as IItems
local h0 as USUAL
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:SelBackColor := oDCOCX_Exontrol1:BackColor
oDCOCX_Exontrol1:SelForeColor := oDCOCX_Exontrol1:ForeColor
oDCOCX_Exontrol1:ColumnAutoResize := true
oDCOCX_Exontrol1:ContinueColumnScroll := false
oDCOCX_Exontrol1:MarkSearchColumn := false
oDCOCX_Exontrol1:SearchColumnIndex := 1
oDCOCX_Exontrol1:HeaderAppearance := Etched
oDCOCX_Exontrol1:HeaderHeight := 23
oDCOCX_Exontrol1:BackColorLevelHeader := oDCOCX_Exontrol1:BackColor
oDCOCX_Exontrol1:FilterBarCaption := "`<b>` + value + `</b><r><fgcolor=808080>` + ( matchitemcount < 0 ? abs(matchitemcount + 1) + ` result(s)` : ``)"
oDCOCX_Exontrol1:FilterBarPromptVisible := exFilterBarCompact | exFilterBarCaptionVisible | exFilterBarVisible | exFilterBarPromptVisible
oDCOCX_Exontrol1:FilterBarBackColor := oDCOCX_Exontrol1:BackColor
oDCOCX_Exontrol1:FilterBarPromptPattern := "and"
var_Columns := oDCOCX_Exontrol1:Columns
var_Column := IColumn{var_Columns:Add("Name")}
var_Column:[Def,exCellValueFormat] := 1
var_Column:FormatColumn := "lower(value)"
var_Column1 := IColumn{var_Columns:Add("Title")}
var_Column1:[Def,exCellValueFormat] := 1
var_Column1:FormatColumn := "lower(value)"
var_Column2 := IColumn{var_Columns:Add("City")}
var_Column2:[Def,exCellValueFormat] := 1
var_Column2:FormatColumn := "lower(value)"
var_Items := oDCOCX_Exontrol1:Items
h0 := var_Items:AddItem("Nancy Davolio")
var_Items:[CellValue,h0,1] := "Sales Representative"
var_Items:[CellValue,h0,2] := "Seattle"
h0 := var_Items:AddItem("Andrew Fuller")
var_Items:[CellValue,h0,1] := "Vice President, Sales"
var_Items:[CellValue,h0,2] := "Tacoma"
var_Items:[SelectItem,h0] := true
h0 := var_Items:AddItem("Janet Leverling")
var_Items:[CellValue,h0,1] := "Sales Representative"
var_Items:[CellValue,h0,2] := "Kirkland"
h0 := var_Items:AddItem("Margaret Peacock")
var_Items:[CellValue,h0,1] := "Sales Representative"
var_Items:[CellValue,h0,2] := "Redmond"
h0 := var_Items:AddItem("Steven Buchanan")
var_Items:[CellValue,h0,1] := "Sales Manager"
var_Items:[CellValue,h0,2] := "London"
h0 := var_Items:AddItem("Michael Suyama")
var_Items:[CellValue,h0,1] := "Sales Representative"
var_Items:[CellValue,h0,2] := "London"
h0 := var_Items:AddItem("Robert King")
var_Items:[CellValue,h0,1] := "Sales Representative"
var_Items:[CellValue,h0,2] := "London"
h0 := var_Items:AddItem("Laura Callahan")
var_Items:[CellValue,h0,1] := "Inside Sales Coordinator"
var_Items:[CellValue,h0,2] := "Seattle"
h0 := var_Items:AddItem("Anne Dodsworth")
var_Items:[CellValue,h0,1] := "Sales Representative"
var_Items:[CellValue,h0,2] := "London"
oDCOCX_Exontrol1:EndUpdate()
|
|
1184
|
The count of filtered items includes the group-parents. How can I exclude them from count
local var_Items as IItems
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:DrawGridLines := exVLines
oDCOCX_Exontrol1:HeaderAppearance := Flat
oDCOCX_Exontrol1:HeaderHeight := 24
oDCOCX_Exontrol1:SortBarHeight := 28
oDCOCX_Exontrol1:SortBarVisible := true
oDCOCX_Exontrol1:AllowGroupBy := true
oDCOCX_Exontrol1:Columns:Add("Col 1")
oDCOCX_Exontrol1:Columns:Add("Col 2")
var_Items := oDCOCX_Exontrol1:Items
var_Items:[CellValue,var_Items:AddItem("219 Smith"),1] := "Ignacio 1234"
var_Items:[CellValue,var_Items:AddItem("1666 County Road 309A"),1] := "897 Manassa"
var_Items:[CellValue,var_Items:AddItem("38 Lone Pine"),1] := "Durango 11"
var_Items:[CellValue,var_Items:AddItem("612 Jachim Street"),1] := "Lamar 222"
oDCOCX_Exontrol1:Layout := "MultipleSort=" + CHR(34) + "C1:1" + CHR(34) + ""
oDCOCX_Exontrol1:FilterBarCaption := "`<b>` + value + `</b><r><fgcolor=808080>` + ( matchitemcount < 0 ? leafitemcount + ` result(s)` : ``)"
oDCOCX_Exontrol1:FilterBarPromptVisible := exFilterBarCompact | exFilterBarCaptionVisible | exFilterBarVisible | exFilterBarPromptVisible
oDCOCX_Exontrol1:FilterBarPromptType := exFilterPromptCaseSensitive | exFilterPromptContainsAll
oDCOCX_Exontrol1:FilterBarPromptPattern := "12"
oDCOCX_Exontrol1:FilterBarBackColor := oDCOCX_Exontrol1:BackColor
oDCOCX_Exontrol1:EndUpdate()
|
|
1183
|
Is it possible to display the count of filtered items
local var_Items as IItems
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:DrawGridLines := exVLines
oDCOCX_Exontrol1:HeaderAppearance := Etched
oDCOCX_Exontrol1:HeaderHeight := 24
oDCOCX_Exontrol1:Columns:Add("Col 1")
oDCOCX_Exontrol1:Columns:Add("Col 2")
var_Items := oDCOCX_Exontrol1:Items
var_Items:[CellValue,var_Items:AddItem("219 Smith"),1] := "Ignacio 1234"
var_Items:[CellValue,var_Items:AddItem("1666 County Road 309A"),1] := "897 Manassa"
var_Items:[CellValue,var_Items:AddItem("38 Lone Pine"),1] := "Durango 11"
var_Items:[CellValue,var_Items:AddItem("612 Jachim Street"),1] := "Lamar 222"
oDCOCX_Exontrol1:FilterBarCaption := "`<b>` + value + `</b><r><fgcolor=808080>` + ( matchitemcount < 0 ? abs(matchitemcount + 1) + ` result(s)` : ``)"
oDCOCX_Exontrol1:FilterBarPromptVisible := exFilterBarCompact | exFilterBarCaptionVisible | exFilterBarVisible | exFilterBarPromptVisible
oDCOCX_Exontrol1:FilterBarPromptType := exFilterPromptCaseSensitive | exFilterPromptContainsAll
oDCOCX_Exontrol1:FilterBarPromptPattern := "12"
oDCOCX_Exontrol1:FilterBarBackColor := oDCOCX_Exontrol1:BackColor
oDCOCX_Exontrol1:EndUpdate()
|
|
1182
|
GroupBy code
local rs as _Recordset
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:ColumnAutoResize := false
oDCOCX_Exontrol1:ContinueColumnScroll := false
oDCOCX_Exontrol1:CountLockedColumns := 1
oDCOCX_Exontrol1:BackColorLock := RGB(248,248,248)
oDCOCX_Exontrol1:HasLines := exSolidLine
oDCOCX_Exontrol1:LinesAtRoot := exGroupLinesOutside
// Generate Source for 'Microsoft ActiveX Data Objects 6.1 Library(msado15.dll)' server from Tools\Automation Server...
rs := _Recordset{"ADOR.Recordset"}
rs:Open("Orders","Provider=Microsoft.ACE.OLEDB.12.0;Data Source=C:\Program Files\Exontrol\ExGrid\Sample\Access\misc.accdb",3,3,0)
oDCOCX_Exontrol1:DataSource := _Recordset{rs}
oDCOCX_Exontrol1:SortBarVisible := true
oDCOCX_Exontrol1:SingleSort := false
oDCOCX_Exontrol1:AllowGroupBy := true
oDCOCX_Exontrol1:Columns:[Item,0]:Width := 128
oDCOCX_Exontrol1:Layout := "MultipleSort = " + CHR(34) + "C12:1 C1:2" + CHR(34) + ""
oDCOCX_Exontrol1:EndUpdate()
|
|
1181
|
ADOR, MDB (JET)
local rs as _Recordset
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:ColumnAutoResize := false
// Generate Source for 'Microsoft ActiveX Data Objects 6.1 Library(msado15.dll)' server from Tools\Automation Server...
rs := _Recordset{"ADOR.Recordset"}
rs:Open("Orders","Provider=Microsoft.Jet.OLEDB.4.0;Data Source=C:\Program Files\Exontrol\ExGrid\Sample\Access\misc.mdb",3,3,0)
oDCOCX_Exontrol1:DataSource := _Recordset{rs}
oDCOCX_Exontrol1:EndUpdate()
|
|
1180
|
Editors (ImageSize = 32)
local var_Appearance as IAppearance
local var_ComboBox as IComboBox
local var_Editor,var_Editor1,var_Editor10,var_Editor11,var_Editor12,var_Editor2,var_Editor3,var_Editor4,var_Editor5,var_Editor6,var_Editor7,var_Editor8,var_Editor9 as IEditor
local var_Items as IItems
local h as USUAL
local rs as _Recordset
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:ImageSize := 32
oDCOCX_Exontrol1:DefaultItemHeight := 36
oDCOCX_Exontrol1:HeaderHeight := oDCOCX_Exontrol1:DefaultItemHeight
oDCOCX_Exontrol1:SortBarHeight := oDCOCX_Exontrol1:DefaultItemHeight
oDCOCX_Exontrol1:Font:Size := 16
oDCOCX_Exontrol1:FilterBarFont:Size := oDCOCX_Exontrol1:Font:Size
oDCOCX_Exontrol1:ToolTipFont:Size := oDCOCX_Exontrol1:Font:Size
oDCOCX_Exontrol1:Indent := 26
oDCOCX_Exontrol1:Images("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")
var_Appearance := oDCOCX_Exontrol1:VisualAppearance
var_Appearance:Add(1,"gBFLBCJwBAEHhEJAAEhABfICg6AADACAxRDgMQBQKAAzQFAYbhkGCGAAGMZxRgmFgAQhFcZQSKUOQTDKMIziaQAGgkNQwCSLIwjNIsBxPFKVQChEYxSjKA40SJNUgyj6CCY+QLIE5PfQgAL9I6eJABCCSQKkYx0HScRiwPBIbAZAYhCZqaKhWgkKI/WBQIABRDVLx5ESiLRtKy7Mq2bpvXBcNxXHalaztO68LxvKyqHb5fJ/PpgL4YHgmC4NQ7EMRwF6rfbyfZ7Xg/ORPTijZ4sdzMHTzJyscx3HqfaBoOaZU5eMLceTUMofHIndxCcasPbsOatVqjG5sYjcGC3La9cz3Pq/bpuDCbMxuaK1TrYXr1TTrcofBDldAxXRKDxRDWVhLnYOw9i6XxzjuXprCaOoKB6EwbiCZZCGOdZYlcT4xHmbhMnwNxtn+G5bmqdZ7n4Pw/i+X5zm+dQ9g4CAFjsfAJheOI8HsDoWDWTB/lwSAQkmA5PEgRYoDyDwYFYFoFmGCBmBqBphDgRJ0gOTIYBGRB/lyRh0iSCZbjYWJzgWDwIjYLoLmMCJGDKDJjBgWgqG6YhyhGHRzA2aJ1mCABOAiOJvhCZBJBYRoRmSCQmEqEQimkAZgg8TZnDCV4UkmCUmBKZYJGYWoWCUUhiFMNZckNUh2GENoaGaGZmgmJhqhqZpGGIEx2GYIxSGGGJdggWJth2Z4JmYeoemeSZ2H6H4hGmQhihyTRHGYLg7CiCgmgqIpokoNoOiOaJ4jqAochqaZGgaCxpAoZoaiaaJqEmWIcGgShcnCJwqEqFoR3YOoFlgchflqNouiuawHmWSYqGkWZQhcatzmaOoumuSp2j6L5bBaKo0GQKRnGGCxqiyCwmkqMpsksNpOGUGI7A0ew1G0Rxlg0PptgsZuDG2Sx2l6N5tnYNZZjUDRXDCVo5l2FoymqOpukuNpujubwLjmWY5k0ZwxkaFxYlWdp6j6b5Lnafo/nABQdg2FxcUsY5BkmXAkmeQpckwNRrkKTh8CSHZBk4NwyC4KxxgMDwakOMZDn8GgwnGAo2C4cwthMcwmCcMoHBMHRehwTIghySYNksZwcH4HBMEsHx5hyPItiweYxnwSZEH4Mozn0fR+DMAo7EYJ50gkdZelKdNql2UgJn0GIukwH4HicQRai2GI4mSVpNl0dZGledgNgcYpYDWUx3FsOQi5YV5anaTY3G6W53A2RxylydxFjiaxEFCCgBBAQ==")
var_Appearance:Add(2,"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")
var_Appearance:Add(3,"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")
var_Appearance:Add(4,"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")
oDCOCX_Exontrol1:BackColorHeader := 0x4c6c6c6
oDCOCX_Exontrol1:SelBackColor := 0x4000000
oDCOCX_Exontrol1:SelForeColor := RGB(0,0,1)
oDCOCX_Exontrol1:ShowFocusRect := false
oDCOCX_Exontrol1:[CheckImage,Unchecked] := 16777216
oDCOCX_Exontrol1:[CheckImage,Checked] := 33554432
oDCOCX_Exontrol1:[CheckImage,PartialChecked] := 50331648
IColumn{oDCOCX_Exontrol1:Columns:Add("Editors")}:[Def,exCellValueFormat] := 1
var_Items := oDCOCX_Exontrol1:Items
var_Items:[CellEditor,var_Items:AddItem("(ReadOnly)"),0]:EditType := ReadOnly
var_Items:[CellEditor,var_Items:AddItem("(EditType)"),0]:EditType := EditType
h := var_Items:AddItem("Value 1")
var_Editor := var_Items:[CellEditor,h,0]
var_Editor:EditType := DropDownType
var_Editor:AddItem(1,"Value 1",1)
var_Editor:AddItem(2,"Value 2",2)
var_Editor:AddItem(3,"Value 3",3)
var_Items:[FormatCell,h,0] := "value + ' (DropDownType)'"
h := var_Items:AddItem(1)
var_Editor1 := var_Items:[CellEditor,h,0]
var_Editor1:EditType := DropDownListType
var_Editor1:DropDownAutoWidth := exDropDownEditorWidth
var_Editor1:AddItem(1,"Nancy Davolio",1)
var_Editor1:AddItem(2,"Andrew Fuller",2)
var_Editor1:AddItem(3,"Janet Leverling",3)
var_Editor1:AddItem(4,"Peacock Margaret",3)
var_Editor1:AddItem(5,"Steven Buchanan",2)
var_Editor1:AddItem(6,"Michael Suyama",1)
var_Editor1:AddItem(7,"Robert King",2)
var_Editor1:AddItem(8,"Laura Callahan",3)
var_Editor1:AddItem(9,"Anne Dodsworth",2)
var_Items:[FormatCell,h,0] := "value + ' (DropDownList - single column list)'"
h := var_Items:AddItem(1)
var_Editor2 := var_Items:[CellEditor,h,0]
var_Editor2:EditType := DropDownListType
var_Editor2:DropDownAutoWidth := exDropDownEditorWidth
var_Editor2:AddItem(1,"Nancy Davolio",1)
var_Editor2:AddItem(2,"Andrew Fuller",2)
var_Editor2:InsertItem(3,"Janet Leverling",3,2)
var_Editor2:InsertItem(4,"Peacock Margaret",3,2)
var_Editor2:InsertItem(5,"Steven Buchanan",2,2)
var_Editor2:InsertItem(6,"Michael Suyama",1,5)
var_Editor2:InsertItem(7,"Robert King",2,2)
var_Editor2:InsertItem(8,"Laura Callahan",3,2)
var_Editor2:InsertItem(9,"Anne Dodsworth",2,5)
var_Editor2:ExpandAll()
var_Items:[FormatCell,h,0] := "value + ' (DropDownList - single column tree)'"
h := var_Items:AddItem(1)
var_Editor3 := var_Items:[CellEditor,h,0]
var_Editor3:EditType := DropDownListType
var_Editor3:DropDownAutoWidth := exDropDownEditorWidth
var_Editor3:[Option,exDropDownColumnCaption] := "Name¦Title¦City¦Phone"
var_Editor3:[Option,exDropDownColumnWidth] := "312¦¦¦96"
var_Editor3:AddItem(1,"Nancy Davolio¦Sales Representative¦Seattle¦(206) 555-9857",1)
var_Editor3:AddItem(2,"Andrew Fuller¦<b>Vice President</b>, Sales¦Tacoma¦(206) 555-9482",2)
var_Editor3:AddItem(3,"Janet Leverling¦Sales Representative¦Kirkland¦(206) 555-3412",3)
var_Editor3:AddItem(4,"Peacock Margaret¦Sales Representative¦Redmond¦(206) 555-8122",3)
var_Editor3:AddItem(5,"Steven Buchanan¦Sales Manager¦London¦(71) 555-4848",2)
var_Editor3:AddItem(6,"Michael Suyama¦Sales Representative¦London¦(71) 555-7773",1)
var_Editor3:AddItem(7,"Robert King¦Sales Representative¦Kirkland¦(71) 555-5598",2)
var_Editor3:AddItem(8,"Laura Callahan¦Inside Sales Coordinator¦Seattle¦(206) 555-1189",3)
var_Editor3:AddItem(9,"Anne Dodsworth¦Sales Representative¦London¦(71) 555-4444",2)
var_Items:[FormatCell,h,0] := "value + ' (DropDownList - multiple columns list)'"
h := var_Items:AddItem(1)
var_Editor4 := var_Items:[CellEditor,h,0]
var_Editor4:EditType := DropDownListType
var_Editor4:DropDownAutoWidth := exDropDownEditorWidth
var_Editor4:[Option,exDropDownColumnCaption] := "Name¦Title¦City¦Phone"
var_Editor4:[Option,exDropDownColumnWidth] := "312¦¦¦96"
var_Editor4:AddItem(1,"Nancy Davolio¦Sales Representative¦Seattle¦(206) 555-9857",1)
var_Editor4:AddItem(2,"Andrew Fuller¦<b>Vice President</b>, Sales¦Tacoma¦(206) 555-9482",2)
var_Editor4:InsertItem(3,"Janet Leverling¦Sales Representative¦Kirkland¦(206) 555-3412",3,2)
var_Editor4:InsertItem(4,"Peacock Margaret¦Sales Representative¦Redmond¦(206) 555-8122",3,2)
var_Editor4:InsertItem(5,"Steven Buchanan¦Sales Manager¦London¦(71) 555-4848",2,2)
var_Editor4:InsertItem(6,"Michael Suyama¦Sales Representative¦London¦(71) 555-7773",1,5)
var_Editor4:InsertItem(7,"Robert King¦Sales Representative¦Kirkland¦(71) 555-5598",2,2)
var_Editor4:InsertItem(8,"Laura Callahan¦Inside Sales Coordinator¦Seattle¦(206) 555-1189",3,2)
var_Editor4:InsertItem(9,"Anne Dodsworth¦Sales Representative¦London¦(71) 555-4444",2,5)
var_Editor4:ExpandAll()
var_Items:[FormatCell,h,0] := "value + ' (DropDownList - multiple columns tree)'"
h := var_Items:AddItem(100)
var_Items:[CellEditor,h,0]:EditType := SpinType
var_Items:[FormatCell,h,0] := "value + ' (SpinType)'"
var_Items:[CellEditor,var_Items:AddItem("(MemoType)"),0]:EditType := MemoType
h := var_Items:AddItem(3)
var_Editor5 := var_Items:[CellEditor,h,0]
var_Editor5:EditType := CheckListType
var_Editor5:AddItem(1,"Border",1)
var_Editor5:AddItem(2,"Single",2)
var_Editor5:AddItem(4,"Frame",3)
var_Items:[FormatCell,h,0] := "value + ' (CheckListType)'"
h := var_Items:AddItem("193.226.40.161")
var_Editor6 := var_Items:[CellEditor,h,0]
var_Editor6:Mask := "{0,255}.{0,255}.{0,255}.{0,255}"
var_Editor6:EditType := MaskType
var_Items:[FormatCell,h,0] := "value + ' (MaskType)'"
h := var_Items:AddItem(65280)
var_Editor7 := var_Items:[CellEditor,h,0]
var_Editor7:EditType := ColorType
var_Editor7:Mask := "`RGB(`{0,255}\,{0,255}\,{0,255}`)`;;0"
var_Items:[FormatCell,h,0] := "value + ' (ColorType)'"
h := var_Items:AddItem("Tahoma")
var_Items:[CellEditor,h,0]:EditType := FontType
var_Items:[FormatCell,h,0] := "value + ' (FontType)'"
h := var_Items:AddItem("gBHJJGHA5MIwAEIe4AAAFhwbiAliQwig7ixFjBQjRbjhljxwkB7kSFkiQkyblCllSwli7lzFmDQmTbmjlmzwnD7nQBnk9n0/oFBoVDolFo1HpFJpVLplNp1PqFRqVTqlVq1XrFZrVbrldr1YhgAEL5AgBhj/AAssMJthABFof4JDhIWCgYKDBATFT8M6hUIFAQAEQCCDwYF/QoWDZCRBgOKgIYHCQXMisKBAEQAAgOBZaSgQhjERANKQiZhIWamYyIBQ6FzcNKxQLJT4ADA4RjwObAAidBYdHwABQgUxMQYZEI0cD4OgnYKaKyzIRFNQx2YCKoFHScYD0ADXQwUAgwLoLQDqaCWBJoNQ9NBxFJTVQORgiarqSABbamGwtDAwBUWhQmqYALnOFQvGYPA4m6AwKhkZxKj2PBWC0SZCgmVY6CwIJgieBAniubRKHgaYgiwQwGiCfxGDWbBRmGZYIi2VwGnAexxGUSwUFiaR+hQPbBgOCoLCIHh4DAARCmQG4AlgNxuhwWgpFAEQUhuOxOk0NrhAaQoBmgPYdFSIZPjYGYbn+HhgEoAA7HMBIOjUM51AoPojHkEwVlET5slgWZtAEUBdjeSoeF6X5/rQRRSi+QB6GychsEAfZshKYABGQZorlAOgMBqEgAjYHB2jqSoigmYBLk+QZnBqGhggAEwImgbojgoIwSE+MxUHiS4REQCQWluD48B+JJoL+YQikuaI9AALgLmsJQfnSdAvDkCJEhIIIBgOegLEiPBqCyCAAjcCwgAAIJBhQBQkHGL4gDaNBokkZQMiwUAuioJQiCAQYsHMcwwEIeoigAYIogsGIwFKIYICIWguEoPgQhsawBASGgwCuJwLH8K4LigAIaDwbxMAOKxbisPwfASQATFASoagIEYwgcSoKGiAA/mEdIuiGPxCmObIlhMIJNHONxFH8EpPCGeB+noEpBBSSRjCsPZEiyKhgjAH5whSdLEjwDxjC8TxVEMFRzFWJJZBUSI0gQEQLBOM4VHkIg1D0CAJDQNg/p4AAdoC")
var_Items:[CellEditor,h,0]:EditType := PictureType
var_Items:[FormatCell,h,0] := "value + ' (PictureType)'"
var_Items:[CellEditor,var_Items:AddItem("(ButtonType)"),0]:EditType := ButtonType
h := var_Items:AddItem(25)
var_Items:[CellEditor,h,0]:EditType := ProgressBarType
var_Items:[FormatCell,h,0] := "value + ' (ProgressBarType)'"
h := var_Items:AddItem("Value 1")
var_Editor8 := var_Items:[CellEditor,h,0]
var_Editor8:EditType := PickEditType
var_Editor8:AddItem(1,"Value 1",1)
var_Editor8:AddItem(2,"Value 2",2)
var_Editor8:AddItem(3,"Value 3",3)
var_Items:[FormatCell,h,0] := "value + ' (PickEditType)'"
var_Items:[CellEditor,var_Items:AddItem("(LinkEditType)"),0]:EditType := LinkEditType
var_Editor9 := var_Items:[CellEditor,var_Items:AddItem("(UserEditorType)"),0]
var_Editor9:EditType := UserEditorType
var_Editor9:UserEditor("Exontrol.ComboBox","")
// Generate Source for 'ExComboBox 1.0 Control Library(ExComboBox.dll)' server from Tools\Automation Server...
var_ComboBox := IComboBox{var_Editor9:UserEditorObject}
var_ComboBox:BeginUpdate()
var_ComboBox:LabelHeight := oDCOCX_Exontrol1:DefaultItemHeight
var_ComboBox:Style := 2
var_ComboBox:ColumnAutoResize := false
// Generate Source for 'Microsoft ActiveX Data Objects 6.1 Library(msado15.dll)' server from Tools\Automation Server...
rs := _Recordset{"ADOR.Recordset"}
rs:Open("Orders","Provider=Microsoft.ACE.OLEDB.12.0;Data Source=C:\Program Files\Exontrol\ExGrid\Sample\Access\misc.accdb",3,3,0)
var_ComboBox:DataSource := _Recordset{rs}
var_ComboBox:MinHeightList := 128
var_ComboBox:SearchColumnIndex := 0
var_ComboBox:UseTabKey := false
var_ComboBox:EndUpdate()
h := var_Items:AddItem(255)
var_Editor10 := var_Items:[CellEditor,h,0]
var_Editor10:EditType := ColorListType
var_Editor10:[Option,exColorListShowName] := true
var_Items:[FormatCell,h,0] := "value + ' (ColorListType)'"
var_Items:[CellEditor,var_Items:AddItem(65280),0]:EditType := ColorListType
var_Items:[CellEditor,var_Items:AddItem("(MemoDropDownType)"),0]:EditType := MemoDropDownType
var_Editor11 := var_Items:[CellEditor,var_Items:AddItem(-1),0]
var_Editor11:EditType := CheckValueType
var_Editor11:[Option,exCheckValue2] := 1
h := var_Items:AddItem(50)
var_Editor12 := var_Items:[CellEditor,h,0]
var_Editor12:EditType := SliderType
var_Editor12:[Option,exSliderWidth] := -60
var_Editor12:[Option,exSliderTickFrequency] := 10
var_Editor12:[Option,exSliderTickStyle] := 2
var_Items:[FormatCell,h,0] := "value + ' (SliderType)'"
h := var_Items:AddItem(100)
var_Items:[CellEditor,h,0]:EditType := CalculatorType
var_Items:[FormatCell,h,0] := "value + ' (CalculatorType)'"
var_Items:EnsureVisibleItem(h)
oDCOCX_Exontrol1:EndUpdate()
|
|
1179
|
Editors (ImageSize = 16, default)
local var_Appearance as IAppearance
local var_ComboBox as IComboBox
local var_Editor,var_Editor1,var_Editor10,var_Editor11,var_Editor12,var_Editor2,var_Editor3,var_Editor4,var_Editor5,var_Editor6,var_Editor7,var_Editor8,var_Editor9 as IEditor
local var_Items as IItems
local h as USUAL
local rs as _Recordset
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:ImageSize := 16
oDCOCX_Exontrol1:Images("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")
var_Appearance := oDCOCX_Exontrol1:VisualAppearance
var_Appearance:Add(4,"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")
IColumn{oDCOCX_Exontrol1:Columns:Add("Editors")}:[Def,exCellValueFormat] := 1
oDCOCX_Exontrol1:BackColorHeader := 0x4c6c6c6
var_Items := oDCOCX_Exontrol1:Items
var_Items:[CellEditor,var_Items:AddItem("(ReadOnly)"),0]:EditType := ReadOnly
var_Items:[CellEditor,var_Items:AddItem("(EditType)"),0]:EditType := EditType
h := var_Items:AddItem("Value 1")
var_Editor := var_Items:[CellEditor,h,0]
var_Editor:EditType := DropDownType
var_Editor:AddItem(1,"Value 1",1)
var_Editor:AddItem(2,"Value 2",2)
var_Editor:AddItem(3,"Value 3",3)
var_Items:[FormatCell,h,0] := "value + ' (DropDownType)'"
h := var_Items:AddItem(1)
var_Editor1 := var_Items:[CellEditor,h,0]
var_Editor1:EditType := DropDownListType
var_Editor1:DropDownAutoWidth := exDropDownEditorWidth
var_Editor1:AddItem(1,"Nancy Davolio",1)
var_Editor1:AddItem(2,"Andrew Fuller",2)
var_Editor1:AddItem(3,"Janet Leverling",3)
var_Editor1:AddItem(4,"Peacock Margaret",3)
var_Editor1:AddItem(5,"Steven Buchanan",2)
var_Editor1:AddItem(6,"Michael Suyama",1)
var_Editor1:AddItem(7,"Robert King",2)
var_Editor1:AddItem(8,"Laura Callahan",3)
var_Editor1:AddItem(9,"Anne Dodsworth",2)
var_Items:[FormatCell,h,0] := "value + ' (DropDownList - single column list)'"
h := var_Items:AddItem(1)
var_Editor2 := var_Items:[CellEditor,h,0]
var_Editor2:EditType := DropDownListType
var_Editor2:DropDownAutoWidth := exDropDownEditorWidth
var_Editor2:AddItem(1,"Nancy Davolio",1)
var_Editor2:AddItem(2,"Andrew Fuller",2)
var_Editor2:InsertItem(3,"Janet Leverling",3,2)
var_Editor2:InsertItem(4,"Peacock Margaret",3,2)
var_Editor2:InsertItem(5,"Steven Buchanan",2,2)
var_Editor2:InsertItem(6,"Michael Suyama",1,5)
var_Editor2:InsertItem(7,"Robert King",2,2)
var_Editor2:InsertItem(8,"Laura Callahan",3,2)
var_Editor2:InsertItem(9,"Anne Dodsworth",2,5)
var_Editor2:ExpandAll()
var_Items:[FormatCell,h,0] := "value + ' (DropDownList - single column tree)'"
h := var_Items:AddItem(1)
var_Editor3 := var_Items:[CellEditor,h,0]
var_Editor3:EditType := DropDownListType
var_Editor3:DropDownAutoWidth := exDropDownEditorWidth
var_Editor3:[Option,exDropDownColumnCaption] := "Name¦Title¦City¦Phone"
var_Editor3:[Option,exDropDownColumnWidth] := "312¦¦¦96"
var_Editor3:AddItem(1,"Nancy Davolio¦Sales Representative¦Seattle¦(206) 555-9857",1)
var_Editor3:AddItem(2,"Andrew Fuller¦<b>Vice President</b>, Sales¦Tacoma¦(206) 555-9482",2)
var_Editor3:AddItem(3,"Janet Leverling¦Sales Representative¦Kirkland¦(206) 555-3412",3)
var_Editor3:AddItem(4,"Peacock Margaret¦Sales Representative¦Redmond¦(206) 555-8122",3)
var_Editor3:AddItem(5,"Steven Buchanan¦Sales Manager¦London¦(71) 555-4848",2)
var_Editor3:AddItem(6,"Michael Suyama¦Sales Representative¦London¦(71) 555-7773",1)
var_Editor3:AddItem(7,"Robert King¦Sales Representative¦Kirkland¦(71) 555-5598",2)
var_Editor3:AddItem(8,"Laura Callahan¦Inside Sales Coordinator¦Seattle¦(206) 555-1189",3)
var_Editor3:AddItem(9,"Anne Dodsworth¦Sales Representative¦London¦(71) 555-4444",2)
var_Items:[FormatCell,h,0] := "value + ' (DropDownList - multiple columns list)'"
h := var_Items:AddItem(1)
var_Editor4 := var_Items:[CellEditor,h,0]
var_Editor4:EditType := DropDownListType
var_Editor4:DropDownAutoWidth := exDropDownEditorWidth
var_Editor4:[Option,exDropDownColumnCaption] := "Name¦Title¦City¦Phone"
var_Editor4:[Option,exDropDownColumnWidth] := "312¦¦¦96"
var_Editor4:AddItem(1,"Nancy Davolio¦Sales Representative¦Seattle¦(206) 555-9857",1)
var_Editor4:AddItem(2,"Andrew Fuller¦<b>Vice President</b>, Sales¦Tacoma¦(206) 555-9482",2)
var_Editor4:InsertItem(3,"Janet Leverling¦Sales Representative¦Kirkland¦(206) 555-3412",3,2)
var_Editor4:InsertItem(4,"Peacock Margaret¦Sales Representative¦Redmond¦(206) 555-8122",3,2)
var_Editor4:InsertItem(5,"Steven Buchanan¦Sales Manager¦London¦(71) 555-4848",2,2)
var_Editor4:InsertItem(6,"Michael Suyama¦Sales Representative¦London¦(71) 555-7773",1,5)
var_Editor4:InsertItem(7,"Robert King¦Sales Representative¦Kirkland¦(71) 555-5598",2,2)
var_Editor4:InsertItem(8,"Laura Callahan¦Inside Sales Coordinator¦Seattle¦(206) 555-1189",3,2)
var_Editor4:InsertItem(9,"Anne Dodsworth¦Sales Representative¦London¦(71) 555-4444",2,5)
var_Editor4:ExpandAll()
var_Items:[FormatCell,h,0] := "value + ' (DropDownList - multiple columns tree)'"
h := var_Items:AddItem(100)
var_Items:[CellEditor,h,0]:EditType := SpinType
var_Items:[FormatCell,h,0] := "value + ' (SpinType)'"
var_Items:[CellEditor,var_Items:AddItem("(MemoType)"),0]:EditType := MemoType
h := var_Items:AddItem(3)
var_Editor5 := var_Items:[CellEditor,h,0]
var_Editor5:EditType := CheckListType
var_Editor5:AddItem(1,"Border",1)
var_Editor5:AddItem(2,"Single",2)
var_Editor5:AddItem(4,"Frame",3)
var_Items:[FormatCell,h,0] := "value + ' (CheckListType)'"
h := var_Items:AddItem("193.226.40.161")
var_Editor6 := var_Items:[CellEditor,h,0]
var_Editor6:Mask := "{0,255}.{0,255}.{0,255}.{0,255}"
var_Editor6:EditType := MaskType
var_Items:[FormatCell,h,0] := "value + ' (MaskType)'"
h := var_Items:AddItem(65280)
var_Editor7 := var_Items:[CellEditor,h,0]
var_Editor7:EditType := ColorType
var_Editor7:Mask := "`RGB(`{0,255}\,{0,255}\,{0,255}`)`;;0"
var_Items:[FormatCell,h,0] := "value + ' (ColorType)'"
h := var_Items:AddItem("Tahoma")
var_Items:[CellEditor,h,0]:EditType := FontType
var_Items:[FormatCell,h,0] := "value + ' (FontType)'"
h := var_Items:AddItem("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")
var_Items:[CellEditor,h,0]:EditType := PictureType
var_Items:[FormatCell,h,0] := "value + ' (PictureType)'"
var_Items:[CellEditor,var_Items:AddItem("(ButtonType)"),0]:EditType := ButtonType
h := var_Items:AddItem(25)
var_Items:[CellEditor,h,0]:EditType := ProgressBarType
var_Items:[FormatCell,h,0] := "value + ' (ProgressBarType)'"
h := var_Items:AddItem("Value 1")
var_Editor8 := var_Items:[CellEditor,h,0]
var_Editor8:EditType := PickEditType
var_Editor8:AddItem(1,"Value 1",1)
var_Editor8:AddItem(2,"Value 2",2)
var_Editor8:AddItem(3,"Value 3",3)
var_Items:[FormatCell,h,0] := "value + ' (PickEditType)'"
var_Items:[CellEditor,var_Items:AddItem("(LinkEditType)"),0]:EditType := LinkEditType
var_Editor9 := var_Items:[CellEditor,var_Items:AddItem("(UserEditorType)"),0]
var_Editor9:EditType := UserEditorType
var_Editor9:UserEditor("Exontrol.ComboBox","")
// Generate Source for 'ExComboBox 1.0 Control Library(ExComboBox.dll)' server from Tools\Automation Server...
var_ComboBox := IComboBox{var_Editor9:UserEditorObject}
var_ComboBox:BeginUpdate()
var_ComboBox:LabelHeight := oDCOCX_Exontrol1:DefaultItemHeight
var_ComboBox:Style := 2
var_ComboBox:ColumnAutoResize := false
// Generate Source for 'Microsoft ActiveX Data Objects 6.1 Library(msado15.dll)' server from Tools\Automation Server...
rs := _Recordset{"ADOR.Recordset"}
rs:Open("Orders","Provider=Microsoft.ACE.OLEDB.12.0;Data Source=C:\Program Files\Exontrol\ExGrid\Sample\Access\misc.accdb",3,3,0)
var_ComboBox:DataSource := _Recordset{rs}
var_ComboBox:MinHeightList := 128
var_ComboBox:SearchColumnIndex := 0
var_ComboBox:UseTabKey := false
var_ComboBox:EndUpdate()
h := var_Items:AddItem(255)
var_Editor10 := var_Items:[CellEditor,h,0]
var_Editor10:EditType := ColorListType
var_Editor10:[Option,exColorListShowName] := true
var_Items:[FormatCell,h,0] := "value + ' (ColorListType)'"
var_Items:[CellEditor,var_Items:AddItem(65280),0]:EditType := ColorListType
var_Items:[CellEditor,var_Items:AddItem("(MemoDropDownType)"),0]:EditType := MemoDropDownType
var_Editor11 := var_Items:[CellEditor,var_Items:AddItem(-1),0]
var_Editor11:EditType := CheckValueType
var_Editor11:[Option,exCheckValue2] := 1
h := var_Items:AddItem(50)
var_Editor12 := var_Items:[CellEditor,h,0]
var_Editor12:EditType := SliderType
var_Editor12:[Option,exSliderWidth] := -60
var_Editor12:[Option,exSliderTickFrequency] := 10
var_Editor12:[Option,exSliderTickStyle] := 2
var_Items:[FormatCell,h,0] := "value + ' (SliderType)'"
h := var_Items:AddItem(100)
var_Items:[CellEditor,h,0]:EditType := CalculatorType
var_Items:[FormatCell,h,0] := "value + ' (CalculatorType)'"
var_Items:EnsureVisibleItem(h)
oDCOCX_Exontrol1:EndUpdate()
|
|
1178
|
Re-order the cell's caption, icons and images/pictures
local var_Column,var_Column1 as IColumn
local var_Items as IItems
local h as USUAL
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:Images("gBJJgBAICAADAAEAAQhYAf8Pf4hh0QihCJo2AEZjQAjEZFEaIEahkZAIAEEbjMjlErlktl0vmExmUzmk1m03nE5nU7nk9n0/oFBoVDolFo1HpFJpVLplNp1PqFRqVTqlVq1XrFZrVbrlTiFdib/sNjr9gs1nldlrlqtFtt0stlguNvulyh91ud1vVVvNuvt7wFHr9/vl3luEwOJouIq+Dw2KyGRyWTymVy2XzGZzUuiw+lmej0gkUaksljaAnmDcD/cEbf7w1+ufD/fEbeB028bYAO3enB6AB++4EoA4A4sb4vHjXJ4nG5vKAHA4ca6XBjTAD/Y2x/eB/jcB")
var_Column := IColumn{oDCOCX_Exontrol1:Columns:Add("ToLeft")}
var_Column:[Def,exCellHasCheckBox] := true
var_Column1 := IColumn{oDCOCX_Exontrol1:Columns:Add("ToRight")}
var_Column1:[Def,exCellHasCheckBox] := true
var_Column1:[Def,exCellDrawPartsOrder] := "caption,picture,icons,icon,check"
oDCOCX_Exontrol1:DefaultItemHeight := 32
oDCOCX_Exontrol1:DrawGridLines := exVLines
oDCOCX_Exontrol1:HeaderAppearance := Etched
var_Items := oDCOCX_Exontrol1:Items
h := var_Items:AddItem("Caption")
var_Items:[CellImage,h,0] := 2
var_Items:[CellImages,h,0] := "1,2"
var_Items:[CellPicture,h,0] := oDCOCX_Exontrol1:ExecuteTemplate("loadpicture(`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`)")
var_Items:[CellValue,h,1] := var_Items:[CellValue,h,0]
var_Items:[CellHAlignment,h,1] := RightAlignment
var_Items:[CellImage,h,1] := var_Items:[CellImage,h,0]
var_Items:[CellImages,h,1] := "2,1"
var_Items:[CellPicture,h,1] := var_Items:[CellPicture,h,0]
h := var_Items:AddItem("<b>HTML</b> <off 4>Caption")
var_Items:[CellValueFormat,h,0] := exHTML
var_Items:[CellImage,h,0] := 2
var_Items:[CellImages,h,0] := "1,2"
var_Items:[CellPicture,h,0] := oDCOCX_Exontrol1:ExecuteTemplate("loadpicture(`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`)")
var_Items:[CellValue,h,1] := var_Items:[CellValue,h,0]
var_Items:[CellValueFormat,h,1] := exHTML
var_Items:[CellHAlignment,h,1] := RightAlignment
var_Items:[CellImage,h,1] := var_Items:[CellImage,h,0]
var_Items:[CellImages,h,1] := "2,1"
var_Items:[CellPicture,h,1] := var_Items:[CellPicture,h,0]
oDCOCX_Exontrol1:EndUpdate()
|
|
1177
|
ImageSize property on 32 (specifies the size of control' icons/images/check-boxes/radio-buttons)
METHOD OCX_Exontrol1AddColumn(Column) CLASS MainDialog
// AddColumn event - Fired after a new column has been added.
// Column.Def(48) = 2
// Column.Def(49) = 2
RETURN NIL
local var_Appearance as IAppearance
local var_Column,var_Column1,var_Column2,var_Column3 as IColumn
local var_Items as IItems
local h,hR as USUAL
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:ImageSize := 32
oDCOCX_Exontrol1:DefaultItemHeight := 36
oDCOCX_Exontrol1:HeaderHeight := oDCOCX_Exontrol1:DefaultItemHeight
oDCOCX_Exontrol1:SortBarHeight := oDCOCX_Exontrol1:DefaultItemHeight
oDCOCX_Exontrol1:Font:Size := 16
oDCOCX_Exontrol1:FilterBarFont:Size := oDCOCX_Exontrol1:Font:Size
oDCOCX_Exontrol1:ToolTipFont:Size := oDCOCX_Exontrol1:Font:Size
oDCOCX_Exontrol1:Indent := 26
oDCOCX_Exontrol1:Images("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")
var_Appearance := oDCOCX_Exontrol1:VisualAppearance
var_Appearance:Add(1,"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")
var_Appearance:Add(2,"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")
var_Appearance:Add(3,"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")
var_Appearance:Add(4,"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")
oDCOCX_Exontrol1:BackColorHeader := 0x4c6c6c6
oDCOCX_Exontrol1:SelBackColor := 0x4000000
oDCOCX_Exontrol1:SelForeColor := RGB(0,0,1)
oDCOCX_Exontrol1:[CheckImage,Unchecked] := 16777216
oDCOCX_Exontrol1:[CheckImage,Checked] := 33554432
oDCOCX_Exontrol1:[CheckImage,PartialChecked] := 50331648
oDCOCX_Exontrol1:[Background,exSelBackColorFilter] := oDCOCX_Exontrol1:SelBackColor
oDCOCX_Exontrol1:[Background,exSelForeColorFilter] := oDCOCX_Exontrol1:SelForeColor
oDCOCX_Exontrol1:[Background,exBackColorFilter] := oDCOCX_Exontrol1:BackColor
oDCOCX_Exontrol1:[Background,exForeColorFilter] := oDCOCX_Exontrol1:ForeColor
oDCOCX_Exontrol1:[Background,exCursorHoverColumn] := -1
oDCOCX_Exontrol1:[Background,exHeaderFilterBarButton] := 0x4000000
oDCOCX_Exontrol1:[Background,exHeaderFilterBarActive] := 0x4010101
oDCOCX_Exontrol1:[Background,exFooterFilterBarButton] := 0x40000ff
oDCOCX_Exontrol1:HeaderAppearance := Etched
oDCOCX_Exontrol1:ShowFocusRect := false
oDCOCX_Exontrol1:SortBarVisible := true
oDCOCX_Exontrol1:AllowGroupBy := true
oDCOCX_Exontrol1:BackColorSortBar := oDCOCX_Exontrol1:BackColor
oDCOCX_Exontrol1:BackColorLevelHeader := oDCOCX_Exontrol1:BackColor
oDCOCX_Exontrol1:FilterBarDropDownHeight := 1
var_Column := IColumn{oDCOCX_Exontrol1:Columns:Add("Check")}
var_Column:[Def,exCellHasCheckBox] := true
var_Column:PartialCheck := true
var_Column:Width := 128
var_Column:DisplayFilterButton := true
var_Column:FilterList := exShowCheckBox
var_Column1 := IColumn{oDCOCX_Exontrol1:Columns:Add("Pos")}
var_Column1:FormatColumn := "1 pos ``"
var_Column1:AllowSort := false
var_Column1:Width := 48
var_Column1:AllowSizing := false
var_Column1:Alignment := CenterAlignment
var_Column1:HeaderAlignment := CenterAlignment
var_Column2 := IColumn{oDCOCX_Exontrol1:Columns:Add("Image")}
var_Column2:DisplayFilterButton := true
var_Column2:FilterList := exShowExclude | exShowCheckBox | exSortItemsAsc
var_Column2:FilterType := exImage
var_Column2:DisplayExpandButton := true
var_Column2:ExpandColumns := "1,2,3"
var_Column2:Width := 128
var_Column2:HeaderImage := 1
var_Column3 := IColumn{oDCOCX_Exontrol1:Columns:Add("Images")}
var_Column3:[Def,exCellHasCheckBox] := true
var_Column3:Width := 196
var_Column3:HTMLCaption := "<img>1</img><img>2</img><img>3</img> Images"
oDCOCX_Exontrol1:Columns:[Item,"Pos"]:Position := 3
var_Items := oDCOCX_Exontrol1:Items
hR := var_Items:AddItem("Root")
var_Items:[ItemDivider,hR] := 0
var_Items:[ItemDividerLine,hR] := EmptyLine
h := var_Items:InsertItem(hR,nil,"Child A")
var_Items:[CellImage,h,2] := 1
var_Items:[CellImages,h,3] := "1,2,3"
var_Items:[CellValue,h,3] := "123"
h := var_Items:InsertItem(hR,nil,"Child B")
var_Items:[CellState,h,0] := 1
var_Items:[CellImage,h,2] := 3
var_Items:[CellImages,h,3] := "2,3,1"
var_Items:[CellValue,h,3] := "231"
var_Items:[SelectItem,h] := true
h := var_Items:InsertItem(hR,nil,"Child C")
var_Items:[CellImage,h,2] := 2
var_Items:[CellState,h,3] := 1
var_Items:[CellValue,h,3] := "312"
var_Items:[CellImages,h,3] := "3,1,2"
var_Items:[ExpandItem,hR] := true
oDCOCX_Exontrol1:EndUpdate()
|
|
1176
|
ImageSize property on 16 (default) (specifies the size of control' icons/images/check-boxes/radio-buttons)
METHOD OCX_Exontrol1AddColumn(Column) CLASS MainDialog
// AddColumn event - Fired after a new column has been added.
// Column.Def(48) = 2
// Column.Def(49) = 2
RETURN NIL
local var_Appearance as IAppearance
local var_Column,var_Column1,var_Column2,var_Column3 as IColumn
local var_Items as IItems
local h,hR as USUAL
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:ImageSize := 16
oDCOCX_Exontrol1:Images("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")
var_Appearance := oDCOCX_Exontrol1:VisualAppearance
var_Appearance:Add(4,"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")
oDCOCX_Exontrol1:BackColorHeader := 0x4c6c6c6
oDCOCX_Exontrol1:SelBackColor := 0x4000000
oDCOCX_Exontrol1:SelForeColor := RGB(0,0,1)
oDCOCX_Exontrol1:[Background,exSelBackColorFilter] := oDCOCX_Exontrol1:SelBackColor
oDCOCX_Exontrol1:[Background,exSelForeColorFilter] := oDCOCX_Exontrol1:SelForeColor
oDCOCX_Exontrol1:[Background,exBackColorFilter] := oDCOCX_Exontrol1:BackColor
oDCOCX_Exontrol1:[Background,exForeColorFilter] := oDCOCX_Exontrol1:ForeColor
oDCOCX_Exontrol1:[Background,exCursorHoverColumn] := -1
oDCOCX_Exontrol1:[Background,exHeaderFilterBarButton] := 0x4000000
oDCOCX_Exontrol1:[Background,exHeaderFilterBarActive] := 0x4010101
oDCOCX_Exontrol1:[Background,exFooterFilterBarButton] := 0x40000ff
oDCOCX_Exontrol1:HeaderAppearance := Etched
oDCOCX_Exontrol1:ShowFocusRect := false
oDCOCX_Exontrol1:SortBarVisible := true
oDCOCX_Exontrol1:AllowGroupBy := true
oDCOCX_Exontrol1:BackColorSortBar := oDCOCX_Exontrol1:BackColor
oDCOCX_Exontrol1:BackColorLevelHeader := oDCOCX_Exontrol1:BackColor
oDCOCX_Exontrol1:FilterBarDropDownHeight := 1
var_Column := IColumn{oDCOCX_Exontrol1:Columns:Add("Check")}
var_Column:[Def,exCellHasCheckBox] := true
var_Column:PartialCheck := true
var_Column:Width := 128
var_Column:DisplayFilterButton := true
var_Column:FilterList := exShowCheckBox
var_Column1 := IColumn{oDCOCX_Exontrol1:Columns:Add("Pos")}
var_Column1:FormatColumn := "1 pos ``"
var_Column1:AllowSort := false
var_Column1:Width := 48
var_Column1:AllowSizing := false
var_Column1:Alignment := CenterAlignment
var_Column1:HeaderAlignment := CenterAlignment
var_Column2 := IColumn{oDCOCX_Exontrol1:Columns:Add("Image")}
var_Column2:DisplayFilterButton := true
var_Column2:FilterList := exShowExclude | exShowCheckBox | exSortItemsAsc
var_Column2:FilterType := exImage
var_Column2:DisplayExpandButton := true
var_Column2:ExpandColumns := "1,2,3"
var_Column2:Width := 128
var_Column2:HeaderImage := 1
var_Column3 := IColumn{oDCOCX_Exontrol1:Columns:Add("Images")}
var_Column3:[Def,exCellHasCheckBox] := true
var_Column3:Width := 196
var_Column3:HTMLCaption := "<img>1</img><img>2</img><img>3</img> Images"
oDCOCX_Exontrol1:Columns:[Item,"Pos"]:Position := 3
var_Items := oDCOCX_Exontrol1:Items
hR := var_Items:AddItem("Root")
var_Items:[ItemDivider,hR] := 0
var_Items:[ItemDividerLine,hR] := EmptyLine
h := var_Items:InsertItem(hR,nil,"Child A")
var_Items:[CellImage,h,2] := 1
var_Items:[CellImages,h,3] := "1,2,3"
var_Items:[CellValue,h,3] := "123"
h := var_Items:InsertItem(hR,nil,"Child B")
var_Items:[CellState,h,0] := 1
var_Items:[CellImage,h,2] := 3
var_Items:[CellImages,h,3] := "2,3,1"
var_Items:[CellValue,h,3] := "231"
var_Items:[SelectItem,h] := true
h := var_Items:InsertItem(hR,nil,"Child C")
var_Items:[CellImage,h,2] := 2
var_Items:[CellState,h,3] := 1
var_Items:[CellValue,h,3] := "312"
var_Items:[CellImages,h,3] := "3,1,2"
var_Items:[ExpandItem,hR] := true
oDCOCX_Exontrol1:EndUpdate()
|
|
1175
|
The user clicks the drop-down filter, select a value and the control's list filters for the selected item(s). Is there a way for when the user then goes to the next column to add another filter and the drop down arrow is clicked for the list of values they can filter by to be limited to what is being displayed in the list due to the first filter they set
METHOD OCX_Exontrol1AddColumn(Column) CLASS MainDialog
// AddColumn event - Fired after a new column has been added.
RETURN NIL
local rs as _Recordset
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:ColumnAutoResize := false
// Generate Source for 'Microsoft ActiveX Data Objects 6.1 Library(msado15.dll)' server from Tools\Automation Server...
rs := _Recordset{"ADOR.Recordset"}
rs:Open("Orders","Provider=Microsoft.ACE.OLEDB.12.0;Data Source=C:\Program Files\Exontrol\ExGrid\Sample\Access\misc.accdb",3,3,0)
oDCOCX_Exontrol1:DataSource := _Recordset{rs}
oDCOCX_Exontrol1:Columns:[Item,"ShipVia"]:Position := 2
oDCOCX_Exontrol1:EndUpdate()
|
|
1174
|
Does the control display images from database (ADO)
local var_Column as IColumn
local rs as _Recordset
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:ColumnAutoResize := false
oDCOCX_Exontrol1:DrawGridLines := exAllLines
oDCOCX_Exontrol1:GridLineStyle := exGridLinesGeometric
oDCOCX_Exontrol1:DefaultItemHeight := 48
// Generate Source for 'Microsoft ActiveX Data Objects 6.1 Library(msado15.dll)' server from Tools\Automation Server...
rs := _Recordset{"ADODB.Recordset"}
rs:Open("Employees","Provider=Microsoft.ACE.OLEDB.12.0;Data Source=C:\Program Files\Exontrol\ExGrid\Sample\Access\misc.mdb",3,3,0)
oDCOCX_Exontrol1:DataSource := _Recordset{rs}
var_Column := oDCOCX_Exontrol1:Columns:[Item,"Photo"]
var_Column:Position := 1
var_Column:Width := 128
oDCOCX_Exontrol1:EndUpdate()
|
|
1173
|
Does the control display images from database (DAO)
local var_Column as IColumn
local rs as Recordset
local var_PrivDBEngine as _DBEngine
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:ColumnAutoResize := false
oDCOCX_Exontrol1:DrawGridLines := exAllLines
oDCOCX_Exontrol1:GridLineStyle := exGridLinesGeometric
oDCOCX_Exontrol1:DefaultItemHeight := 48
// Generate Source for 'Microsoft DAO 3.6 Object Library(dao360.dll)' server from Tools\Automation Server...
var_PrivDBEngine := _DBEngine{"DAO.DBEngine.36"}
rs := var_PrivDBEngine:OpenDatabase("C:\Program Files\Exontrol\ExGrid\Sample\Access\misc.mdb",nil,nil,nil):OpenRecordset("Employees",nil,nil,nil)
oDCOCX_Exontrol1:DataSource := Recordset{rs}
var_Column := oDCOCX_Exontrol1:Columns:[Item,"Photo"]
var_Column:Position := 1
var_Column:Width := 128
oDCOCX_Exontrol1:EndUpdate()
|
|
1172
|
Is it possible to set from code, a column sort without being inserted in the sortbar
local rs as _Recordset
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:ColumnAutoResize := false
// Generate Source for 'Microsoft ActiveX Data Objects 6.1 Library(msado15.dll)' server from Tools\Automation Server...
rs := _Recordset{"ADOR.Recordset"}
rs:Open("Orders","Provider=Microsoft.ACE.OLEDB.12.0;Data Source=C:\Program Files\Exontrol\ExGrid\Sample\Access\misc.accdb",3,3,0)
oDCOCX_Exontrol1:DataSource := _Recordset{rs}
oDCOCX_Exontrol1:SortBarVisible := true
oDCOCX_Exontrol1:Layout := "singlesort=" + CHR(34) + "C1:1" + CHR(34) + ""
oDCOCX_Exontrol1:EndUpdate()
|
|
1171
|
Is it possible to view all events the control fires
METHOD OCX_Exontrol1Event(EventID) CLASS MainDialog
// Event event - Notifies the application once the control fires an event.
OutputDebugString(String2Psz( AsString(oDCOCX_Exontrol1:[EventParam,-2]) ))
RETURN NIL
local var_Column as IColumn
local var_Items as IItems
local h,hChild as USUAL
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:LinesAtRoot := exLinesAtRoot
var_Column := IColumn{oDCOCX_Exontrol1:Columns:Add("Tasks")}
var_Column:[Def,exCellHasCheckBox] := true
var_Column:PartialCheck := true
var_Column:[Def,exCellValueFormat] := 1
var_Column:FormatColumn := "value + (%CS0 = 1 ? `<r><fgcolor=808080>(checked)` : ``)"
var_Column:Editor:EditType := EditType
oDCOCX_Exontrol1:HeaderVisible := true
var_Items := oDCOCX_Exontrol1:Items
h := var_Items:AddItem("Project")
hChild := var_Items:InsertItem(h,nil,"Task 1")
var_Items:[SelectItem,hChild] := true
hChild := var_Items:InsertItem(h,nil,"Task 2")
var_Items:[CellState,hChild,0] := 1
hChild := var_Items:InsertItem(h,nil,"Task 3")
var_Items:[CellState,hChild,0] := 1
var_Items:[ExpandItem,h] := true
oDCOCX_Exontrol1:EndUpdate()
|
|
1170
|
How can I find all occurences of the giving value, within a column
local var_Column,var_Column1 as IColumn
local var_Items as IItems
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:Columns:Add("Default")
var_Column := IColumn{oDCOCX_Exontrol1:Columns:Add("Pos")}
var_Column:FormatColumn := "1 pos 'A-Z'"
var_Column:Position := 0
var_Column:AllowSizing := false
var_Column:Width := 32
var_Column:Enabled := false
var_Column1 := IColumn{oDCOCX_Exontrol1:Columns:Add("Index")}
var_Column1:FormatColumn := "0 index ''"
var_Column1:AllowSizing := false
var_Column1:Width := 32
var_Column1:Enabled := false
var_Items := oDCOCX_Exontrol1:Items
var_Items:AddItem("A")
var_Items:AddItem("A")
var_Items:AddItem("A")
OutputDebugString(String2Psz( var_Items:[CellCaption,var_Items:[FindItem,"A",0,0],1] ))
OutputDebugString(String2Psz( var_Items:[CellCaption,var_Items:[FindItem,"A",0,1],1] ))
OutputDebugString(String2Psz( var_Items:[CellCaption,var_Items:[FindItem,"A",0,2],1] ))
oDCOCX_Exontrol1:EndUpdate()
|
|
1169
|
How can I prevent expanding/collapsing the child items
METHOD OCX_Exontrol1BeforeExpandItem(Item,Cancel) CLASS MainDialog
// BeforeExpandItem event - Fired before an item is about to be expanded (collapsed).
Cancel := oDCOCX_Exontrol1:Items:[ItemParent,Item]
RETURN NIL
local var_Items as IItems
local h as USUAL
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:SingleSel := false
oDCOCX_Exontrol1:Columns:Add("Default")
oDCOCX_Exontrol1:LinesAtRoot := exLinesAtRoot
var_Items := oDCOCX_Exontrol1:Items
h := var_Items:AddItem("Root 1")
var_Items:InsertItem(var_Items:InsertItem(h,nil,"Child 1.1"),nil,"Child")
var_Items:InsertItem(h,nil,"Child 1.2")
var_Items:[ExpandItem,h] := true
h := var_Items:AddItem("Root 2")
var_Items:InsertItem(var_Items:InsertItem(h,nil,"Child 2.1"),nil,"Child")
var_Items:InsertItem(h,nil,"Child 2.2")
var_Items:[ExpandItem,h] := true
oDCOCX_Exontrol1:EndUpdate()
|
|
1168
|
How can I display the EBN bigger or smaller (thumb)
local var_Appearance as IAppearance
local var_Items as IItems
oDCOCX_Exontrol1:BeginUpdate()
var_Appearance := oDCOCX_Exontrol1:VisualAppearance
var_Appearance:Add(1,"c:\exontrol\images\normal.ebn")
var_Appearance:Add(10,"CP:1 0 3 0 -3")
var_Appearance:Add(17,"CP:1 3 0 -3 0")
oDCOCX_Exontrol1:[Background,exHSThumb] := 0xa000000
oDCOCX_Exontrol1:[Background,exVSThumb] := 0x11000000
oDCOCX_Exontrol1:ScrollBars := exVScrollEmptySpace | exHScrollEmptySpace | exVScrollOnThumbRelease | exHScrollOnThumbRelease | exDisableBoth
oDCOCX_Exontrol1:ScrollBySingleLine := true
oDCOCX_Exontrol1:Columns:Add("Def")
var_Items := oDCOCX_Exontrol1:Items
var_Items:AddItem(1)
var_Items:AddItem(2)
var_Items:AddItem(3)
oDCOCX_Exontrol1:EndUpdate()
|
|
1167
|
I am using GroupBy feature to create a tree, but the top rows are aligned with the children, not indented. What could be wrong
METHOD OCX_Exontrol1AddGroupItem(Item) CLASS MainDialog
// AddGroupItem event - Occurs after a new Group Item has been inserted to Items collection.
// AddBar(Item,"Progress", #12/2/2017#,#12/2/2017#)
// DefineSummaryBars(Item,"", -3, "")
// Chart.ItemBackColor(Item) = color
local var_Items as IItems
local color as USUAL
color := 14474460
var_Items := oDCOCX_Exontrol1:Items
var_Items:[ItemDivider,Item] := -1
var_Items:[CellValue,Item,1] := var_Items:[CellCaption,Item,var_Items:[GroupItem,Item]]
var_Items:[ItemBold,Item] := true
var_Items:[ItemBackColor,Item] := color
RETURN NIL
METHOD OCX_Exontrol1AddItem(Item) CLASS MainDialog
// AddItem event - Occurs after a new Item has been inserted to Items collection.
// AddBar(Item,"Task",#12/4/2017#,#12/10/2017#)
// ItemBar(Item,"", 514) = ItemToIndex(Item)
local var_Items as IItems
var_Items := oDCOCX_Exontrol1:Items
RETURN NIL
local var_Columns as IColumns
local var_Items as IItems
local h as USUAL
oDCOCX_Exontrol1:BeginUpdate()
var_Columns := oDCOCX_Exontrol1:Columns
var_Columns:Add("C1")
var_Columns:Add("C2")
oDCOCX_Exontrol1:LinesAtRoot := exLinesAtRoot
oDCOCX_Exontrol1:SortBarVisible := true
oDCOCX_Exontrol1:SortBarCaption := "Drag a <b>column</b> header here to group by that column."
oDCOCX_Exontrol1:AllowGroupBy := true
var_Items := oDCOCX_Exontrol1:Items
h := var_Items:AddItem("Item A")
var_Items:[CellValue,h,1] := "SubItem A.1"
h := var_Items:AddItem("Item A")
var_Items:[CellValue,h,1] := "SubItem A.1"
h := var_Items:AddItem("Item A")
var_Items:[CellValue,h,1] := "SubItem A.1"
h := var_Items:AddItem("Item A")
var_Items:[CellValue,h,1] := "SubItem A.1"
h := var_Items:AddItem("Item B")
var_Items:[CellValue,h,1] := "SubItem B.1"
h := var_Items:AddItem("Item B")
var_Items:[CellValue,h,1] := "SubItem B.1"
oDCOCX_Exontrol1:Columns:[Item,0]:SortOrder := SortAscending
oDCOCX_Exontrol1:EndUpdate()
|
|
1166
|
How can I display an item of picture type
local var_Items as IItems
local h,h1 as USUAL
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:LinesAtRoot := exLinesAtRoot
oDCOCX_Exontrol1:ScrollBySingleLine := false
oDCOCX_Exontrol1:HeaderAppearance := Etched
oDCOCX_Exontrol1:HeaderHeight := 24
IColumn{oDCOCX_Exontrol1:Columns:Add("Artikel")}:HTMLCaption := "<u>Artikel"
IColumn{oDCOCX_Exontrol1:Columns:Add("Waarde")}:HTMLCaption := "<u>Waarde"
oDCOCX_Exontrol1:[HTMLPicture,"T22128"] := "c:\exontrol\images\zipdisk.gif"
var_Items := oDCOCX_Exontrol1:Items
h := var_Items:AddItem("T22128-28)2D")
h1 := var_Items:InsertItem(h,nil,"<img>T22128:128</img>")
var_Items:[CellValueFormat,h1,0] := exHTML
var_Items:[ItemHeight,h1] := 128
h1 := var_Items:InsertItem(h,nil,"werkvoorbereiding")
var_Items:[CellValue,h1,1] := "5.80"
var_Items:[CellBold,h1,1] := true
var_Items:[CellValue,var_Items:InsertItem(h1,nil,"Type"),1] := "Eenvoudig"
var_Items:[CellValue,var_Items:InsertItem(h1,nil,"Prijs p/uur"),1] := "60,00"
var_Items:[CellValue,var_Items:InsertItem(h1,nil,"Marhe"),1] := "15,00%"
var_Items:[CellValue,var_Items:InsertItem(h1,nil,"Insteltijd min."),1] := "5,00"
var_Items:[CellValue,var_Items:InsertItem(h1,nil,"Aantal"),1] := 1
var_Items:[CellValue,var_Items:InsertItem(h1,nil,"Kostprije"),1] := "5,00"
var_Items:[ExpandItem,h1] := true
h1 := var_Items:InsertItem(h,nil,"materiall")
var_Items:[CellValue,h1,1] := "14.82"
var_Items:[CellBold,h1,1] := true
var_Items:[ItemHasChildren,h1] := true
h1 := var_Items:InsertItem(h,nil,"snijden")
var_Items:[CellValue,h1,1] := "3.13"
var_Items:[CellBold,h1,1] := true
var_Items:[ItemHasChildren,h1] := true
var_Items:[ExpandItem,h] := true
oDCOCX_Exontrol1:EndUpdate()
|
|
1165
|
Dark mode
local back,fore as USUAL
oDCOCX_Exontrol1:BeginUpdate()
back := 65536
fore := 16777215
oDCOCX_Exontrol1:VisualAppearance:Add(1,"gBFLBCJwBAEHhEJAAEhABXUIQAAYAQGKIcBiAKBQAGYBIJDEMgzDDAUBjKKocQTC4AIQjCK4JDKHYJRpHEZyCA8EhqGASRAFUQBYiWE4oSpLABQaK0ZwIGyRIrkGQgQgmPYDSDNU4zVIEEglBI0TDNczhNDENgtGYaJqHIYpZBcM40TKkEZoSIITZcRrOEBiRL1S0RBhGcRUHZlWzdN64LhuK47UrWdD/XhdVzXRbjfz1Oq+bxve48Br7A5yYThdr4LhOFQ3RjIL4xbIcUwGe6VZhjOLZXjmO49T69HTtOCYBEBA")
oDCOCX_Exontrol1:VisualAppearance:Add(2,"gBFLBCJwBAEHhEJAAEhABPMIQAAYAQGKIcBiAKBQAGaAoDDcMgwQwAAxjIKUEwsACEIrjKCYVgOHYYQjGMZwHCMIhiGwcAChEZYHgkMYmDAMUhSE78axHG6PY7kKZ4biaKIqQLLEhSfJ0YyBECBZpfebIbjmIZMSLEIxDKItJSpCIaRgqWS6ahGO4JUbUFLQHT9IR4daIYRgEEBA")
oDCOCX_Exontrol1:VisualAppearance:Add(3,"gBFLBCJwBAEHhEJAAEhABUUIQAAYAQGKIcBiAKBQAGaAoDDcMgwQwAAxjIKUEwsACEIrjKCYVgOHYYQjGMZwGAsEwjAoYAChEaILgkMw2DBIQwgJIMEr/G6RZxjeL5CjmG4nDhKMpybAcXxjBIYZJgOQpXb+PobTrNNLzfRFAxVAaWJikcZ4HpIAJNVLFdQ0XYMNSBISsBqrKiKcpeIIDWBZMbRZT1ZABCIZBpEW6LahENQwXrCN74DYkNTdKaxbbuaaXLhGCYBgIA==")
oDCOCX_Exontrol1:HeaderAppearance := Bump
oDCOCX_Exontrol1:BackColor := back
oDCOCX_Exontrol1:BackColorHeader := back
oDCOCX_Exontrol1:BackColorLevelHeader := back
oDCOCX_Exontrol1:BackColorSortBar := back
oDCOCX_Exontrol1:BackColorSortBarCaption := back
oDCOCX_Exontrol1:FilterBarBackColor := back
oDCOCX_Exontrol1:FilterBarForeColor := fore
oDCOCX_Exontrol1:ForeColor := fore
oDCOCX_Exontrol1:ForeColorHeader := fore
oDCOCX_Exontrol1:ForeColorSortBar := fore
oDCOCX_Exontrol1:SelBackColor := fore
oDCOCX_Exontrol1:SelForeColor := back
oDCOCX_Exontrol1:[Background,exHeaderFilterBarButton] := 0x1000000
oDCOCX_Exontrol1:[Background,exCursorHoverColumn] := -1
oDCOCX_Exontrol1:[Background,exToolTipAppearance] := 0x3000000
oDCOCX_Exontrol1:[Background,exToolTipBackColor] := back
oDCOCX_Exontrol1:[Background,exToolTipForeColor] := fore
oDCOCX_Exontrol1:[Background,exSelBackColorFilter] := fore
oDCOCX_Exontrol1:[Background,exSelForeColorFilter] := back
oDCOCX_Exontrol1:[Background,exBackColorFilter] := back
oDCOCX_Exontrol1:[Background,exForeColorFilter] := fore
oDCOCX_Exontrol1:[Background,exSortBarLinkColor] := back
oDCOCX_Exontrol1:[Background,exScrollSizeGrip] := back
oDCOCX_Exontrol1:[Description,exFilterBarExclude] := "<bgcolor 0><fgcolor ffffff> Exclude </fgcolor></bgcolor>"
oDCOCX_Exontrol1:EndUpdate()
|
|
1164
|
I have changed the font, but the item's height remains the same. What I am doing wrong
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:ColumnAutoResize := false
oDCOCX_Exontrol1:LoadXML("http://www.exontrol.net/testing.xml")
oDCOCX_Exontrol1:Font:Size := 22
oDCOCX_Exontrol1:HeaderHeight := 42
oDCOCX_Exontrol1:DefaultItemHeight := 36
oDCOCX_Exontrol1:Items:[ItemHeight,0] := oDCOCX_Exontrol1:DefaultItemHeight
oDCOCX_Exontrol1:EndUpdate()
|
|
1163
|
How can I specify the cell's outline, border or lines around, when the cell gets selected
local var_Appearance as IAppearance
local var_Items as IItems
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:AttachTemplate("handle AddColumn(Column){Column{Def(48)=4;Def(49)=4;}}")
var_Appearance := oDCOCX_Exontrol1:VisualAppearance
var_Appearance:Add(1,"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")
var_Appearance:Add(2,"CP:1 -4 0 0 0")
oDCOCX_Exontrol1:SelBackColor := 0x2000000
oDCOCX_Exontrol1:SelForeColor := RGB(0,0,1)
oDCOCX_Exontrol1:FullRowSelect := exColumnSel
oDCOCX_Exontrol1:ShowFocusRect := false
oDCOCX_Exontrol1:DefaultItemHeight := 24
oDCOCX_Exontrol1:HeaderHeight := 24
oDCOCX_Exontrol1:DrawGridLines := exVLines
oDCOCX_Exontrol1:Columns:Add("C1")
oDCOCX_Exontrol1:Columns:Add("C2")
var_Items := oDCOCX_Exontrol1:Items
var_Items:[CellValue,var_Items:AddItem("Cell 1"),1] := "Cell 2"
var_Items:[CellValue,var_Items:AddItem("Cell 3"),1] := "Cell 4"
oDCOCX_Exontrol1:Items:SelectPos := 1
oDCOCX_Exontrol1:SelectColumnIndex := 1
oDCOCX_Exontrol1:EndUpdate()
|
|
1162
|
How can I specify the cell's outline, border or lines around, when the item gets selected
local var_Items as IItems
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:AttachTemplate("handle AddColumn(Column){Column{Def(48)=4;Def(49)=4;}}")
oDCOCX_Exontrol1:VisualAppearance:Add(1,"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")
oDCOCX_Exontrol1:SelBackColor := 0x1000000
oDCOCX_Exontrol1:SelForeColor := RGB(0,0,1)
oDCOCX_Exontrol1:ShowFocusRect := false
oDCOCX_Exontrol1:DefaultItemHeight := 24
oDCOCX_Exontrol1:HeaderHeight := 24
oDCOCX_Exontrol1:DrawGridLines := exVLines
oDCOCX_Exontrol1:Columns:Add("C1")
oDCOCX_Exontrol1:Columns:Add("C2")
var_Items := oDCOCX_Exontrol1:Items
var_Items:[CellValue,var_Items:AddItem("Cell 1"),1] := "Cell 2"
var_Items:[CellValue,var_Items:AddItem("Cell 3"),1] := "Cell 4"
var_Items:SelectPos := 1
oDCOCX_Exontrol1:EndUpdate()
|
|
1161
|
How can I specify the cell's outline, border or lines around
local var_Items as IItems
local h as USUAL
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:AttachTemplate("handle AddColumn(Column){Column{Def(48)=4;Def(49)=4;}}")
oDCOCX_Exontrol1:VisualAppearance:Add(1,"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")
oDCOCX_Exontrol1:SelBackMode := exTransparent
oDCOCX_Exontrol1:ShowFocusRect := false
oDCOCX_Exontrol1:DefaultItemHeight := 24
oDCOCX_Exontrol1:HeaderHeight := 24
oDCOCX_Exontrol1:DrawGridLines := exVLines
oDCOCX_Exontrol1:Columns:Add("C1")
oDCOCX_Exontrol1:Columns:Add("C2")
var_Items := oDCOCX_Exontrol1:Items
var_Items:[CellValue,var_Items:AddItem("Cell 1"),1] := "Cell 2"
h := var_Items:AddItem("Cell 2")
var_Items:[CellValue,h,1] := "Cell 3"
var_Items:[CellBackColor,h,1] := 0x1000000
oDCOCX_Exontrol1:EndUpdate()
|
|
1160
|
Is it possible to highligth the match while a filter is applied
METHOD OCX_Exontrol1AddColumn(Column) CLASS MainDialog
// AddColumn event - Fired after a new column has been added.
// Column.Def(17) = 1
RETURN NIL
METHOD OCX_Exontrol1FilterChange() CLASS MainDialog
// FilterChange event - Occurs when filter was changed.
local format as USUAL
format := oDCOCX_Exontrol1:FormatABC("`value replace '` + value + `' with '<bgcolor 000000><fgcolor FFFFFF>` + value + `</fgcolor></bgcolor>'`",oDCOCX_Exontrol1:FilterBarPromptPattern,nil,nil)
oDCOCX_Exontrol1:Columns:[Item,0]:FormatColumn := AsString(format)
oDCOCX_Exontrol1:Columns:[Item,1]:FormatColumn := AsString(format)
RETURN NIL
local var_Items as IItems
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:DrawGridLines := exVLines
oDCOCX_Exontrol1:HeaderAppearance := Etched
oDCOCX_Exontrol1:Columns:Add("Col 1")
oDCOCX_Exontrol1:Columns:Add("Col 2")
var_Items := oDCOCX_Exontrol1:Items
var_Items:[CellValue,var_Items:AddItem("219 Smith"),1] := "Ignacio 1234"
var_Items:[CellValue,var_Items:AddItem("1666 County Road 309A"),1] := "897 Manassa"
var_Items:[CellValue,var_Items:AddItem("38 Lone Pine"),1] := "Durango 11"
var_Items:[CellValue,var_Items:AddItem("612 Jachim Street"),1] := "Lamar 222"
oDCOCX_Exontrol1:FilterBarPromptPattern := "1"
oDCOCX_Exontrol1:FilterBarPromptVisible := exFilterBarCompact | exFilterBarSingleLine | exFilterBarVisible | exFilterBarPromptVisible
oDCOCX_Exontrol1:FilterBarPromptType := exFilterPromptCaseSensitive | exFilterPromptContainsAll
oDCOCX_Exontrol1:EndUpdate()
|
|
1159
|
How can I replace the cell's context menu ( while edit mode is running )
METHOD OCX_Exontrol1RClick() CLASS MainDialog
// RClick event - Fired when right mouse button is clicked
local var_ExContextMenu as IExContextMenu
OutputDebugString(String2Psz( "Edit Mode: " ))
OutputDebugString(String2Psz( AsString(oDCOCX_Exontrol1:Editing) ))
// Generate Source for 'ExContextMenu 1.0 Type Library(ExContextMenu.dll)' server from Tools\Automation Server...
var_ExContextMenu := IExContextMenu{"Exontrol.ContextMenu"}
var_ExContextMenu:Items:ToString := "Check[chk],[sep],Item 1,Item 2,Item 3,Popup(A,B,C)"
OutputDebugString(String2Psz( AsString(var_ExContextMenu:Select(nil,nil,nil)) ))
RETURN NIL
local var_Editor as IEditor
local var_Items as IItems
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:HeaderAppearance := Flat
var_Editor := IColumn{oDCOCX_Exontrol1:Columns:Add("Column")}:Editor
var_Editor:EditType := EditType
var_Editor:[Option,exEditAllowContextMenu] := false
var_Items := oDCOCX_Exontrol1:Items
var_Items:AddItem("Item 1")
var_Items:AddItem("Item 2")
oDCOCX_Exontrol1:EndUpdate()
|
|
1158
|
Is it possible to highlight the column's header once a filter is applied (sample 2)
local var_Appearance as IAppearance
local var_Column as IColumn
local var_Columns as IColumns
local var_Items as IItems
local h as USUAL
oDCOCX_Exontrol1:BeginUpdate()
var_Appearance := oDCOCX_Exontrol1:VisualAppearance
var_Appearance:Add(1,"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")
var_Appearance:Add(2,"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")
oDCOCX_Exontrol1:[Background,exHeaderFilterBarButton] := 0x1000000
oDCOCX_Exontrol1:[Background,exHeaderFilterBarActive] := 0x2000000
oDCOCX_Exontrol1:[Background,exCursorHoverColumn] := -1
oDCOCX_Exontrol1:HeaderHeight := 28
oDCOCX_Exontrol1:BackColorHeader := RGB(255,255,255)
oDCOCX_Exontrol1:DrawGridLines := exRowLines
oDCOCX_Exontrol1:HeaderVisible := true
var_Columns := oDCOCX_Exontrol1:Columns
IColumn{var_Columns:Add("C1")}:DisplayFilterButton := true
var_Column := IColumn{var_Columns:Add("C2")}
var_Column:DisplayFilterButton := true
var_Column:Filter := "Item 2"
var_Column:FilterType := exFilter
IColumn{var_Columns:Add("C3")}:DisplayFilterButton := true
var_Items := oDCOCX_Exontrol1:Items
h := var_Items:AddItem("Item 1")
var_Items:[CellValue,h,1] := "Item 2"
var_Items:[CellValue,h,2] := "Item 3"
h := var_Items:AddItem("Item 4")
var_Items:[CellValue,h,1] := "Item 5"
var_Items:[CellValue,h,2] := "Item 6"
oDCOCX_Exontrol1:ApplyFilter()
oDCOCX_Exontrol1:EndUpdate()
|
|
1157
|
How can I make the expand/collapse glyphs DPI aware
local var_Appearance as IAppearance
local var_Items as IItems
local h,size as USUAL
size := 2
oDCOCX_Exontrol1:BeginUpdate()
var_Appearance := oDCOCX_Exontrol1:VisualAppearance
var_Appearance:Add(3,"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")
var_Appearance:Add(4,"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")
var_Appearance:Add(1,oDCOCX_Exontrol1:FormatABC("`CP:3 -` + int(value*dpi) + ` -` + int(value*dpi) + ` ` + int(value*dpi) + ` ` + int(value*dpi)",size,nil,nil))
var_Appearance:Add(2,oDCOCX_Exontrol1:FormatABC("`CP:4 -` + int(value*dpi) + ` -` + int(value*dpi) + ` ` + int(value*dpi) + ` ` + int(value*dpi)",size,nil,nil))
oDCOCX_Exontrol1:LinesAtRoot := exGroupLinesAtRoot
oDCOCX_Exontrol1:HasButtons := exCustom
oDCOCX_Exontrol1:[HasButtonsCustom,false] := 16777216
oDCOCX_Exontrol1:[HasButtonsCustom,true] := 33554432
oDCOCX_Exontrol1:Columns:Add("Column")
var_Items := oDCOCX_Exontrol1:Items
h := var_Items:AddItem("Root 1")
var_Items:InsertItem(h,nil,"Child 1")
var_Items:InsertItem(h,nil,"Child 2")
var_Items:[ExpandItem,h] := true
h := var_Items:AddItem("Root 2")
var_Items:InsertItem(h,nil,"Child")
oDCOCX_Exontrol1:EndUpdate()
|
|
1156
|
Is it possible to highlight the column's header once a filter is applied (sample 1)
local var_Appearance as IAppearance
local var_Column as IColumn
local var_Columns as IColumns
local var_Items as IItems
local h as USUAL
oDCOCX_Exontrol1:BeginUpdate()
var_Appearance := oDCOCX_Exontrol1:VisualAppearance
var_Appearance:Add(2,"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")
var_Appearance:Add(1,"CP:2 -8 -4 2 4")
oDCOCX_Exontrol1:[Background,exHeaderFilterBarButton] := 0x1fefefe
oDCOCX_Exontrol1:[Background,exHeaderFilterBarActive] := 0x1010101
oDCOCX_Exontrol1:[Background,exCursorHoverColumn] := -1
oDCOCX_Exontrol1:HeaderHeight := 28
oDCOCX_Exontrol1:BackColorHeader := RGB(255,255,255)
oDCOCX_Exontrol1:DrawGridLines := exRowLines
oDCOCX_Exontrol1:HeaderVisible := true
var_Columns := oDCOCX_Exontrol1:Columns
IColumn{var_Columns:Add("C1")}:DisplayFilterButton := true
var_Column := IColumn{var_Columns:Add("C2")}
var_Column:DisplayFilterButton := true
var_Column:Filter := "Item 2"
var_Column:FilterType := exFilter
IColumn{var_Columns:Add("C3")}:DisplayFilterButton := true
var_Items := oDCOCX_Exontrol1:Items
h := var_Items:AddItem("Item 1")
var_Items:[CellValue,h,1] := "Item 2"
var_Items:[CellValue,h,2] := "Item 3"
h := var_Items:AddItem("Item 4")
var_Items:[CellValue,h,1] := "Item 5"
var_Items:[CellValue,h,2] := "Item 6"
oDCOCX_Exontrol1:ApplyFilter()
oDCOCX_Exontrol1:EndUpdate()
|
|
1155
|
How do I update itemcount and matchitemcount of the FilterBarCaption after I added the item using the AddItem method
METHOD OCX_Exontrol1Click() CLASS MainDialog
// Click event - Occurs when the user presses and then releases the left mouse button over the grid control.
oDCOCX_Exontrol1:Items:AddItem("new")
oDCOCX_Exontrol1:Refresh()
RETURN NIL
local var_Column,var_Column1 as IColumn
local var_Items as IItems
oDCOCX_Exontrol1:BeginUpdate()
var_Column := IColumn{oDCOCX_Exontrol1:Columns:Add("Item")}
var_Column:DisplayFilterButton := true
var_Column:FilterList := exShowExclude | exShowFocusItem | exShowCheckBox | exSortItemsAsc
var_Column1 := IColumn{oDCOCX_Exontrol1:Columns:Add("Pos")}
var_Column1:AllowSizing := false
var_Column1:AllowSort := false
var_Column1:Width := 32
var_Column1:FormatColumn := "1 apos ``"
var_Column1:Position := 0
var_Items := oDCOCX_Exontrol1:Items
var_Items:AddItem("Item A")
var_Items:AddItem("Item B")
var_Items:AddItem("Item C")
oDCOCX_Exontrol1:FilterBarCaption := "`<r>` + value + `</b><fgcolor=808080>` + ( matchitemcount < 0 ? ( ( len(value) ? `<br>` : `` ) + `<r>` + abs(matchitemcount + 1) + ` result(s)` ) : (`<fgcolor=808080>`+ itemcount + ` item(s)`) )"
oDCOCX_Exontrol1:FilterBarPromptVisible := exFilterBarCompact | exFilterBarShowCloseOnRight | exFilterBarShowCloseIfRequired | exFilterBarCaptionVisible | exFilterBarVisible | exFilterBarPromptVisible
oDCOCX_Exontrol1:EndUpdate()
|
|
1154
|
I can't get values in the column properly centered. What can be the problem
local var_Column as IColumn
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:TreeColumnIndex := -1
oDCOCX_Exontrol1:DrawGridLines := exRowLines
var_Column := IColumn{oDCOCX_Exontrol1:Columns:Add("Default")}
var_Column:Alignment := CenterAlignment
var_Column:FormatColumn := "ltrim(rtrim(value))"
oDCOCX_Exontrol1:Items:AddItem("item 1 ")
oDCOCX_Exontrol1:Items:AddItem(" item 2")
oDCOCX_Exontrol1:Items:AddItem(" item 3 ")
oDCOCX_Exontrol1:EndUpdate()
|
|
1153
|
The Edit method does not work while ReadOnly property is exLocked and the first column is hidden. Is there any fix
METHOD OCX_Exontrol1DblClick(Shift,X,Y) CLASS MainDialog
// DblClick event - Occurs when the user dblclk the left mouse button over an object.
local var_ItemFromPoint as USUAL
var_ItemFromPoint := oDCOCX_Exontrol1:[ItemFromPoint,-1,-1,c,hit]
oDCOCX_Exontrol1:FocusColumnIndex := c
oDCOCX_Exontrol1:Edit(nil)
RETURN NIL
local var_Column as IColumn
local var_Items as IItems
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:HeaderAppearance := Etched
oDCOCX_Exontrol1:AutoEdit := false
oDCOCX_Exontrol1:ReadOnly := exLocked
oDCOCX_Exontrol1:AutoSearch := true
IColumn{oDCOCX_Exontrol1:Columns:Add("")}:Visible := false
var_Column := IColumn{oDCOCX_Exontrol1:Columns:Add("Contains")}
var_Column:AutoSearch := exContains
var_Column:Editor:EditType := EditType
var_Items := oDCOCX_Exontrol1:Items
var_Items:[CellValue,var_Items:AddItem(nil),1] := "Tom Hanks"
var_Items:[CellValue,var_Items:AddItem(nil),1] := "Leonardo DiCaprio"
var_Items:[CellValue,var_Items:AddItem(nil),1] := "Will Smith"
var_Items:[CellValue,var_Items:AddItem(nil),1] := "Tom Cruise"
oDCOCX_Exontrol1:EndUpdate()
|
|
1152
|
How can I enable the Undo/Redo feature
local var_Column,var_Column1 as IColumn
local var_Items as IItems
local h as USUAL
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:AllowUndoRedo := true
oDCOCX_Exontrol1:LinesAtRoot := exLinesAtRoot
oDCOCX_Exontrol1:HeaderAppearance := Etched
var_Column := IColumn{oDCOCX_Exontrol1:Columns:Add("P1")}
var_Column:[Def,exCellHasCheckBox] := true
var_Column:PartialCheck := true
var_Column1 := IColumn{oDCOCX_Exontrol1:Columns:Add("P2")}
var_Column1:[Def,exCellHasCheckBox] := true
var_Column1:PartialCheck := true
var_Items := oDCOCX_Exontrol1:Items
h := var_Items:AddItem("Root")
var_Items:InsertItem(h,nil,"Child 1")
var_Items:InsertItem(h,nil,"Child 2")
var_Items:[ExpandItem,h] := true
var_Items:AddItem("Press CTRL + Z for Undo, and CTRL + Y for Redo")
oDCOCX_Exontrol1:EndUpdate()
|
|
1151
|
The incremental search feature is no working for columns with editor assigned. What can be done
METHOD OCX_Exontrol1DblClick(Shift,X,Y) CLASS MainDialog
// DblClick event - Occurs when the user dblclk the left mouse button over an object.
oDCOCX_Exontrol1:Edit(nil)
RETURN NIL
local var_Column as IColumn
local var_Items as IItems
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:HeaderAppearance := Etched
oDCOCX_Exontrol1:AutoEdit := false
oDCOCX_Exontrol1:AutoSearch := true
var_Column := IColumn{oDCOCX_Exontrol1:Columns:Add("Contains")}
var_Column:AutoSearch := exContains
var_Column:Editor:EditType := EditType
var_Items := oDCOCX_Exontrol1:Items
var_Items:AddItem("Tom Hanks")
var_Items:AddItem("Leonardo DiCaprio")
var_Items:AddItem("Will Smith")
var_Items:AddItem("Tom Cruise")
oDCOCX_Exontrol1:EndUpdate()
|
|
1150
|
Each item is representated by a key as string. Is it possible to have a drop down editor to display more information when using the item's key
local var_Editor as IEditor
local var_Items as IItems
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:HeaderAppearance := Etched
var_Editor := IColumn{oDCOCX_Exontrol1:Columns:Add("Multiple-Columns Tree DropDownListType")}:Editor
var_Editor:EditType := DropDownListType
var_Editor:AddItem(0,"KR|Korea, Republic of",nil)
var_Editor:AddItem(1,"MO|Macao",nil)
var_Editor:AddItem(2,"SA|Saudi Arabia",nil)
var_Editor:AddItem(3,"EG|Egypt",nil)
var_Editor:AddItem(4,"GB|United Kingdom",nil)
var_Editor:AddItem(5,"GT|Guatemala",nil)
var_Editor:AddItem(6,"SR|Suriname",nil)
var_Editor:AddItem(7,"BM|Bermuda",nil)
var_Items := oDCOCX_Exontrol1:Items
var_Items:AddItem("EG")
var_Items:AddItem("GB")
var_Items:AddItem("BM")
oDCOCX_Exontrol1:EndUpdate()
|
|
1149
|
My table includes codes/keys for items, can I display a drop down editor to include more information
local var_Editor as IEditor
local var_Items as IItems
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:HeaderAppearance := Etched
var_Editor := IColumn{oDCOCX_Exontrol1:Columns:Add("Multiple-Columns DropDownListType")}:Editor
var_Editor:EditType := DropDownListType
var_Editor:DropDownAutoWidth := exDropDownEditorWidth
var_Editor:[Option,exDropDownColumnCaption] := "City¦Coordinates¦State"
var_Editor:AddItem(0,"JV3|Jollyville¦3026N 09746W¦Texas",nil)
var_Editor:AddItem(1,"TMO|Altamont¦4021N 11017W¦Utah",nil)
var_Editor:AddItem(2,"IIM|Williamston¦4241N 08417W¦Michigan",nil)
var_Editor:AddItem(3,"IWN|Merrittstown¦3958N 07952W¦Pennsylvania",nil)
var_Editor:AddItem(4,"HOU|Houston¦2945N 09521W¦Texas",nil)
var_Editor:AddItem(5,"GSF|Gales Ferry¦4125N 07205W¦Connecticut",nil)
var_Items := oDCOCX_Exontrol1:Items
var_Items:AddItem("HOU")
var_Items:AddItem("IIM")
var_Items:AddItem("TMO")
oDCOCX_Exontrol1:EndUpdate()
|
|
1148
|
How can I display and select from a multiple-columns tree editor
local var_Editor as IEditor
local var_Items as IItems
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:Images("gBJJgBAIDAAGAAEAAQhYAf8Pf4hh0QihCJo2AEZjQAjEZFEaIEaEEaAIAkcbk0olUrlktl0vmExmUzmk1m03nE5nU7nk9n0/oFBoVDolFo1HpFJpVLplNp1PqFRqVTqlVq1XrFZrVbrldr1fsFhsVjslls1ntFptVrtltt1vuFxuVzul1u13vF5vV7vl9v1/wGBwWDwmFw2HxGJxWLxmNx0xiFdyOTh8Tf9ZymXx+QytcyNgz8r0OblWjyWds+m0ka1Vf1ta1+r1mos2xrG2xeZ0+a0W0qOx3GO4NV3WeyvD2XJ5XL5nN51aiw+lfSj0gkUkAEllHanHI5j/cHg8EZf7w8vl8j4f/qfEZeB09/vjLAB30+kZQAP/P5/H6/yNAOAEAwCjMBwFAEDwJBMDwLBYAP2/8Hv8/gAGAD8LQs9w/nhDY/oygIA=")
oDCOCX_Exontrol1:HeaderAppearance := Etched
var_Editor := IColumn{oDCOCX_Exontrol1:Columns:Add("Multiple-Columns Tree DropDownListType")}:Editor
var_Editor:EditType := DropDownListType
var_Editor:DropDownAutoWidth := exDropDownEditorWidth
var_Editor:[Option,exDropDownColumnCaption] := "Name¦Title¦City¦Phone"
var_Editor:[Option,exDropDownColumnWidth] := "224¦¦¦96"
var_Editor:AddItem(1,"Nancy Davolio¦Sales Representative¦Seattle¦(206) 555-9857",1)
var_Editor:AddItem(2,"Andrew Fuller¦<b>Vice President</b>, Sales¦Tacoma¦(206) 555-9482",2)
var_Editor:InsertItem(3,"Janet Leverling¦Sales Representative¦Kirkland¦(206) 555-3412",3,2)
var_Editor:InsertItem(4,"Peacock Margaret¦Sales Representative¦Redmond¦(206) 555-8122",3,2)
var_Editor:InsertItem(5,"Steven Buchanan¦Sales Manager¦London¦(71) 555-4848",2,2)
var_Editor:InsertItem(6,"Michael Suyama¦Sales Representative¦London¦(71) 555-7773",1,5)
var_Editor:InsertItem(7,"Robert King¦Sales Representative¦Kirkland¦(71) 555-5598",2,2)
var_Editor:InsertItem(8,"Laura Callahan¦Inside Sales Coordinator¦Seattle¦(206) 555-1189",3,2)
var_Editor:InsertItem(9,"Anne Dodsworth¦Sales Representative¦London¦(71) 555-4444",2,5)
var_Editor:ExpandAll()
var_Items := oDCOCX_Exontrol1:Items
var_Items:AddItem(1)
var_Items:AddItem(2)
var_Items:AddItem(4)
oDCOCX_Exontrol1:EndUpdate()
|
|
1147
|
Does you control support multiple-columns for a drop down editor
local var_Editor as IEditor
local var_Items as IItems
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:HeaderAppearance := Etched
var_Editor := IColumn{oDCOCX_Exontrol1:Columns:Add("Multiple-Columns DropDownListType")}:Editor
var_Editor:EditType := DropDownListType
var_Editor:DropDownAutoWidth := exDropDownEditorWidth
var_Editor:AddItem(0,"Jollyville¦JV3¦3026N 09746W¦TX",nil)
var_Editor:AddItem(1,"Altamont¦TMO¦4021N 11017W¦UT",nil)
var_Editor:AddItem(2,"Williamston¦IIM¦4241N 08417W¦MI",nil)
var_Editor:AddItem(3,"Merrittstown¦IWN¦3958N 07952W¦PA",nil)
var_Editor:AddItem(4,"Houston¦HOU¦2945N 09521W¦TX",nil)
var_Editor:AddItem(5,"Gales Ferry¦GSF¦4125N 07205W¦CT",nil)
var_Items := oDCOCX_Exontrol1:Items
var_Items:InsertItem(0,"",1)
var_Items:InsertItem(0,"",2)
var_Items:InsertItem(0,"",4)
oDCOCX_Exontrol1:EndUpdate()
|
|
1146
|
Is it possible to show the filterbar on top of the rows
local var_Column,var_Column1 as IColumn
local var_Items as IItems
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:FilterBarPromptVisible := exFilterBarTop
oDCOCX_Exontrol1:HeaderHeight := 24
oDCOCX_Exontrol1:FilterBarHeight := oDCOCX_Exontrol1:HeaderHeight
oDCOCX_Exontrol1:HeaderAppearance := Flat
oDCOCX_Exontrol1:DrawGridLines := exAllLines
oDCOCX_Exontrol1:GridLineStyle := exGridLinesGeometric
var_Column := IColumn{oDCOCX_Exontrol1:Columns:Add("Column")}
var_Column:DisplayFilterButton := true
var_Column:FilterType := exPattern
var_Column:Filter := "B*"
var_Column1 := IColumn{oDCOCX_Exontrol1:Columns:Add("Index")}
var_Column1:FormatColumn := "1 index ``"
var_Column1:Position := 0
var_Column1:Width := 48
var_Column1:AllowSizing := false
var_Column1:SortType := SortNumeric
var_Column1:[Def,exCellHasCheckBox] := true
var_Items := oDCOCX_Exontrol1:Items
var_Items:AddItem("A.1")
var_Items:AddItem("A.2")
var_Items:AddItem("B.1")
var_Items:AddItem("B.2")
var_Items:AddItem("B.3")
var_Items:AddItem("C")
oDCOCX_Exontrol1:ApplyFilter()
oDCOCX_Exontrol1:EndUpdate()
|
|
1145
|
DragDrop (with visual effect)
METHOD OCX_Exontrol1OLEDragDrop(Data,Effect,Button,Shift,X,Y) CLASS MainDialog
// OLEDragDrop event - Occurs when a source component is dropped onto a target component when the source component determines that a drop can occur.
// SelectItem(InsertItem(i,, Data.GetData(1))) = True
local var_Items as IItems
local i as USUAL
i := oDCOCX_Exontrol1:[ItemFromPoint,-1,-1,c,hit]
var_Items := oDCOCX_Exontrol1:Items
var_Items:[ExpandItem,i] := true
RETURN NIL
METHOD OCX_Exontrol1OLEStartDrag(Data,AllowedEffects) CLASS MainDialog
// OLEStartDrag event - Occurs when the OLEDrag method is called.
// Data.SetData(Me.Items.CellCaption(FocusItem, 0), 1)
AllowedEffects := 1
RETURN NIL
local var_Items as IItems
local h as USUAL
oDCOCX_Exontrol1:VisualAppearance:Add(1,"gBFLBCJwBAEHhEJAAEhABPUIQAAYAQGKIcBiAKBQAGaAoDgYN4MAANAwjJBMKgBBCLIxhEYobgmGIaRjEEQDCKYcxHCaIBiGcaIfDEBIeSBHcgRbAcOQHGSZZBhGRJGjuKIbSrLICzBDUcRnGwAKQoaaaEomHwyAZOYwDAIoWhpKKCKjqWJKNb+XgAAJTES0RRVRTNAZ1YghGAQgIA==")
oDCOCX_Exontrol1:[Background,exListOLEDropPosition] := 0x1000000
oDCOCX_Exontrol1:[Background,exDragDropBefore] := RGB(0,0,0)
oDCOCX_Exontrol1:[Background,exDragDropAfter] := RGB(255,255,255)
oDCOCX_Exontrol1:OLEDropMode := exOLEDropManual
oDCOCX_Exontrol1:AutoDrag := exAutoDragPositionAnyOnRight
oDCOCX_Exontrol1:LinesAtRoot := exLinesAtRoot
oDCOCX_Exontrol1:Indent := 16
oDCOCX_Exontrol1:SelBackMode := exTransparent
oDCOCX_Exontrol1:Columns:Add("Default")
var_Items := oDCOCX_Exontrol1:Items
h := var_Items:AddItem("Root")
var_Items:InsertItem(h,nil,"Child 1")
var_Items:InsertItem(h,nil,"Child 2")
var_Items:[ExpandItem,h] := true
OutputDebugString(String2Psz( "You can:" ))
OutputDebugString(String2Psz( "A) left-click to drag and drop items between controls (open a new exhelper and run the same sample)" ))
OutputDebugString(String2Psz( "B) right-click to re-arrange the item position inside the same control" ))
OutputDebugString(String2Psz( "This sample shows how you can insert the data being dropped as a child of the item being hovered." ))
|
|
1144
|
DragDrop (with no visual effect, hide item while drag and drop)
METHOD OCX_Exontrol1OLEDragDrop(Data,Effect,Button,Shift,X,Y) CLASS MainDialog
// OLEDragDrop event - Occurs when a source component is dropped onto a target component when the source component determines that a drop can occur.
// SelectItem(InsertItem(i,, Data.GetData(1))) = True
local var_Items as IItems
local i as USUAL
i := oDCOCX_Exontrol1:[ItemFromPoint,-1,-1,c,hit]
var_Items := oDCOCX_Exontrol1:Items
var_Items:[ExpandItem,i] := true
RETURN NIL
METHOD OCX_Exontrol1OLEStartDrag(Data,AllowedEffects) CLASS MainDialog
// OLEStartDrag event - Occurs when the OLEDrag method is called.
// Data.SetData(Me.Items.CellCaption(FocusItem, 0), 1)
AllowedEffects := 1
RETURN NIL
local var_Items as IItems
local h as USUAL
oDCOCX_Exontrol1:[Background,exDragDropBefore] := RGB(0,0,0)
oDCOCX_Exontrol1:[Background,exDragDropAfter] := RGB(255,255,255)
oDCOCX_Exontrol1:OLEDropMode := exOLEDropManual
oDCOCX_Exontrol1:AutoDrag := exAutoDragPositionAnyOnRight
oDCOCX_Exontrol1:LinesAtRoot := exLinesAtRoot
oDCOCX_Exontrol1:Indent := 16
oDCOCX_Exontrol1:SelBackMode := exTransparent
oDCOCX_Exontrol1:Columns:Add("Default")
var_Items := oDCOCX_Exontrol1:Items
h := var_Items:AddItem("Root")
var_Items:InsertItem(h,nil,"Child 1")
var_Items:InsertItem(h,nil,"Child 2")
var_Items:[ExpandItem,h] := true
OutputDebugString(String2Psz( "You can:" ))
OutputDebugString(String2Psz( "A) left-click to drag and drop items between controls (open a new exhelper and run the same sample)" ))
OutputDebugString(String2Psz( "B) right-click to re-arrange the item position inside the same control" ))
OutputDebugString(String2Psz( "This sample shows how you can insert the data being dropped as a child of the item being hovered." ))
|
|
1143
|
DragDrop
METHOD OCX_Exontrol1OLEDragDrop(Data,Effect,Button,Shift,X,Y) CLASS MainDialog
// OLEDragDrop event - Occurs when a source component is dropped onto a target component when the source component determines that a drop can occur.
// SelectItem(InsertItem(i,, Data.GetData(1))) = True
local var_Items as IItems
local i as USUAL
i := oDCOCX_Exontrol1:[ItemFromPoint,-1,-1,c,hit]
var_Items := oDCOCX_Exontrol1:Items
var_Items:[ExpandItem,i] := true
RETURN NIL
METHOD OCX_Exontrol1OLEStartDrag(Data,AllowedEffects) CLASS MainDialog
// OLEStartDrag event - Occurs when the OLEDrag method is called.
// Data.SetData(Me.Items.CellCaption(FocusItem, 0), 1)
AllowedEffects := 1
RETURN NIL
local var_Items as IItems
local h as USUAL
oDCOCX_Exontrol1:OLEDropMode := exOLEDropManual
oDCOCX_Exontrol1:AutoDrag := exAutoDragPositionAnyOnRight
oDCOCX_Exontrol1:LinesAtRoot := exLinesAtRoot
oDCOCX_Exontrol1:Indent := 16
oDCOCX_Exontrol1:SelBackMode := exTransparent
oDCOCX_Exontrol1:Columns:Add("Default")
var_Items := oDCOCX_Exontrol1:Items
h := var_Items:AddItem("Root")
var_Items:InsertItem(h,nil,"Child 1")
var_Items:InsertItem(h,nil,"Child 2")
var_Items:[ExpandItem,h] := true
OutputDebugString(String2Psz( "You can:" ))
OutputDebugString(String2Psz( "A) left-click to drag and drop items between controls (open a new exhelper and run the same sample)" ))
OutputDebugString(String2Psz( "B) right-click to re-arrange the item position inside the same control" ))
OutputDebugString(String2Psz( "This sample shows how you can insert the data being dropped as a child of the item being hovered." ))
|
|
1142
|
Is there anyway to stop the header changing colour when the mouse hovers/moves across the column header (non-clickable)
local var_Column as IColumn
local var_Columns as IColumns
local var_Items as IItems
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:HeaderAppearance := Etched
var_Columns := oDCOCX_Exontrol1:Columns
var_Columns:Add("Item")
var_Column := IColumn{var_Columns:Add("Pos")}
var_Column:Position := 0
var_Column:Width := 32
var_Column:AllowSizing := false
var_Column:FormatColumn := "1 index ``"
var_Column:AllowSort := false
var_Column:AllowDragging := false
var_Items := oDCOCX_Exontrol1:Items
var_Items:AddItem("Item A")
var_Items:AddItem("Item B")
var_Items:AddItem("Item C")
oDCOCX_Exontrol1:EndUpdate()
|
|
1141
|
Is there anyway to stop the header changing colour when the mouse hovers/moves across the column header
local var_Column as IColumn
local var_Columns as IColumns
local var_Items as IItems
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:HeaderAppearance := Etched
oDCOCX_Exontrol1:[Background,exCursorHoverColumn] := -1
var_Columns := oDCOCX_Exontrol1:Columns
var_Columns:Add("Item")
var_Column := IColumn{var_Columns:Add("Pos")}
var_Column:Position := 0
var_Column:Width := 32
var_Column:AllowSizing := false
var_Column:FormatColumn := "1 index ``"
var_Column:AllowSort := false
var_Column:AllowDragging := false
var_Items := oDCOCX_Exontrol1:Items
var_Items:AddItem("Item A")
var_Items:AddItem("Item B")
var_Items:AddItem("Item C")
oDCOCX_Exontrol1:EndUpdate()
|
|
1140
|
Is it possible to exclude the parent/child items when do the filtering, so to include only items that match the filter without any indentation
METHOD OCX_Exontrol1FilterChange() CLASS MainDialog
// FilterChange event - Occurs when filter was changed.
oDCOCX_Exontrol1:Indent := oDCOCX_Exontrol1:FormatABC("value > 0 ? 18 : 0",:Items:MatchItemCount,nil,nil)
RETURN NIL
local var_Column,var_Column1 as IColumn
local var_Columns as IColumns
local var_Items as IItems
local h,h2 as USUAL
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:LinesAtRoot := exLinesAtRoot
oDCOCX_Exontrol1:Indent := 18
oDCOCX_Exontrol1:FilterInclude := exMatchingItemsOnly
oDCOCX_Exontrol1:DrawGridLines := exVLines
oDCOCX_Exontrol1:HeaderAppearance := Flat
var_Columns := oDCOCX_Exontrol1:Columns
var_Column := IColumn{var_Columns:Add("Column")}
var_Column:DisplayFilterButton := true
var_Column:FilterType := exFilter
var_Column:FilterList := exShowCheckBox
var_Column:Filter := "C1"
var_Column1 := IColumn{var_Columns:Add("Pos")}
var_Column1:FormatColumn := "1 rindex ``"
var_Column1:Position := 0
var_Column1:AllowSizing := false
var_Column1:AllowDragging := false
var_Items := oDCOCX_Exontrol1:Items
h := var_Items:AddItem("R1")
h2 := var_Items:InsertItem(h,nil,"S")
var_Items:InsertItem(h2,nil,"C1")
var_Items:InsertItem(h2,nil,"C2")
var_Items:InsertItem(h,nil,"C1")
var_Items:InsertItem(h,nil,"C2")
var_Items:[ExpandItem,h] := true
h := var_Items:AddItem("R2")
var_Items:InsertItem(h,nil,"C1")
var_Items:InsertItem(h,nil,"C2")
oDCOCX_Exontrol1:ApplyFilter()
oDCOCX_Exontrol1:EndUpdate()
|
|
1139
|
How can I display the total/sum/aggregate in the same column, when the user groups by a column
METHOD OCX_Exontrol1AddColumn(Column) CLASS MainDialog
// AddColumn event - Fired after a new column has been added.
RETURN NIL
METHOD OCX_Exontrol1AddGroupItem(Item) CLASS MainDialog
// AddGroupItem event - Occurs after a new Group Item has been inserted to Items collection.
local var_Items as IItems
var_Items := oDCOCX_Exontrol1:Items
var_Items:[ItemDivider,Item] := -1
var_Items:[ItemBackColor,Item] := oDCOCX_Exontrol1:BackColorSortBar
var_Items:[ItemHeight,Item] := oDCOCX_Exontrol1:HeaderHeight
var_Items:[CellMerge,Item,0] := "1,2,3,4,5,7,8,9,10,11,12"
var_Items:[CellValue,Item,13] := "count(current,rec,1)"
var_Items:[CellValueFormat,Item,13] := exTotalField | exHTML
var_Items:[CellValue,Item,0] := var_Items:[CellCaption,Item,var_Items:[GroupItem,Item]]
var_Items:[FormatCell,Item,0] := "`<b>` + value + `</b> <font ;7><off 3><fgcolor=808080>(` + %13 + `)`"
var_Items:[CellValue,Item,6] := "sum(current,all,dbl(%6))"
var_Items:[CellValueFormat,Item,6] := exTotalField | exHTML
var_Items:[CellForeColor,Item,6] := RGB(102,102,102)
RETURN NIL
METHOD OCX_Exontrol1Change(Item,ColIndex,NewValue) CLASS MainDialog
// Change event - Occurs when the user changes the cell's content.
oDCOCX_Exontrol1:Refresh()
RETURN NIL
local var_Column,var_Column1 as IColumn
local var_Columns as IColumns
local var_Items as IItems
local hL as USUAL
local rs as _Recordset
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:LinesAtRoot := exGroupLinesOutside
oDCOCX_Exontrol1:Indent := 12
oDCOCX_Exontrol1:ColumnAutoResize := false
oDCOCX_Exontrol1:ScrollBySingleLine := true
oDCOCX_Exontrol1:BackColorSortBar := RGB(240,240,240)
oDCOCX_Exontrol1:AutoDrag := exAutoDragScroll
// Generate Source for 'Microsoft ActiveX Data Objects 6.1 Library(msado15.dll)' server from Tools\Automation Server...
rs := _Recordset{"ADOR.Recordset"}
rs:Open("Orders","Provider=Microsoft.ACE.OLEDB.12.0;Data Source=C:\Program Files\Exontrol\ExGrid\Sample\Access\misc.accdb",3,3,0)
oDCOCX_Exontrol1:DataSource := _Recordset{rs}
oDCOCX_Exontrol1:SingleSort := false
oDCOCX_Exontrol1:SortBarVisible := true
oDCOCX_Exontrol1:AllowGroupBy := true
oDCOCX_Exontrol1:HeaderHeight := 24
var_Columns := oDCOCX_Exontrol1:Columns
IColumn{var_Columns:Add("Count")}:Visible := false
var_Column := var_Columns:[Item,"Freight"]
var_Column:[Def,exCellBackColor] := oDCOCX_Exontrol1:BackColorSortBar
var_Column:[Def,exHeaderBackColor] := var_Column:[Def,exCellBackColor]
var_Column:[Def,exCellPaddingRight] := 4
var_Column:[Def,exCellPaddingLeft] := 4
var_Column:HeaderBold := true
var_Column:AllowGroupBy := false
var_Column:FormatColumn := "value format ``"
var_Column:Alignment := RightAlignment
var_Column1 := var_Columns:[Item,0]
var_Column1:AllowGroupBy := false
var_Column1:[Def,exCellValueFormat] := 1
var_Columns:[Item,"ShipCountry"]:SortOrder := SortAscending
oDCOCX_Exontrol1:ScrollBySingleLine := false
var_Items := oDCOCX_Exontrol1:Items
var_Items:[LockedItemCount,exBottom] := 1
hL := var_Items:[LockedItem,exBottom,0]
var_Items:[ItemHeight,hL] := 24
var_Items:[ItemBold,hL] := true
var_Items:[ItemBackColor,hL] := oDCOCX_Exontrol1:BackColorSortBar
var_Items:[CellValue,hL,6] := "sum(all,rec,dbl(%6))"
var_Items:[CellValueFormat,hL,6] := exTotalField | exHTML
var_Items:[CellHAlignment,hL,6] := RightAlignment
var_Items:[FormatCell,hL,6] := "value format ``"
oDCOCX_Exontrol1:EndUpdate()
|
|
1138
|
I would like to display a solid line between "root" items, and dotted lines (default) between child items. How can I do that
local var_Column,var_Column1 as IColumn
local var_ConditionalFormat as IConditionalFormat
local var_Items as IItems
local h as USUAL
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:LinesAtRoot := exLinesAtRoot
oDCOCX_Exontrol1:DrawGridLines := exHLines
oDCOCX_Exontrol1:GridLineStyle := exGridLinesGeometric
oDCOCX_Exontrol1:VisualAppearance:Add(1,"gBFLBCJwBAEHhEJAAEhABMsIQAAYAQGKIcBiAKBQAGaAoDgYN4MAANAwjJBMKgBBCLIxhEYobgmGIXRpFMbxAKQahLEiTIgGUYJHgmK4tQLHb7zGAABRDDSOIDnGQJXhaI4JQSMMQDGLAZxVFiPRhAWLpBh+PQATrOdLUfSjVwhBKAQEBA==")
var_Column := IColumn{oDCOCX_Exontrol1:Columns:Add("Default")}
var_Column:[Def,exCellHasCheckBox] := true
var_Column:PartialCheck := true
var_Column1 := IColumn{oDCOCX_Exontrol1:Columns:Add("Position")}
var_Column1:FormatColumn := "((1 rindex ``) contains `.`) = 0"
var_Column1:Visible := false
var_ConditionalFormat := oDCOCX_Exontrol1:ConditionalFormats:Add("%C1",nil)
var_ConditionalFormat:BackColor := 0x1e0e0e0
var_Items := oDCOCX_Exontrol1:Items
h := var_Items:AddItem("Root 1")
var_Items:InsertItem(h,nil,"Child 1")
var_Items:InsertItem(h,nil,"Child 2")
var_Items:InsertItem(h,nil,"Child 3")
var_Items:[ExpandItem,h] := true
h := var_Items:AddItem("Root 2")
var_Items:InsertItem(h,nil,"Child 1")
var_Items:InsertItem(h,nil,"Child 2")
h := var_Items:AddItem("Root 3")
var_Items:InsertItem(h,nil,"Child 1")
var_Items:InsertItem(h,nil,"Child 2")
oDCOCX_Exontrol1:EndUpdate()
|
|
1137
|
I can not center or align the cell's caption and icon, when it displays the hierarchy
local var_Column as IColumn
local var_Items as IItems
local h,hChild as USUAL
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:Images("gBJJgBAIDAAGAAEAAQhYAf8Pf4hh0QihCJo2AEZjQAjEZFEaIEaEEaAIAkcbk0olUrlktl0vmExmUzmk1m03nE5nU7nk9n0/oFBoVDolFo1HpFJpVLplNp1PqFRqVTqlVq1XrFZrVbrldr1fsFhsVjslls1ntFptVrtltt1vuFxuVzul1u13vF5vV7vl9v1/wGBwWDwmFw2HxGJxWLxmNx0xiFdyOTh8Tf9ZymXx+QytcyNgz8r0OblWjyWds+m0ka1Vf1ta1+r1mos2xrG2xeZ0+a0W0qOx3GO4NV3WeyvD2XJ5XL5nN51aiw+lfSj0gkUkAEllHanHI5j/cHg8EZf7w8vl8j4f/qfEZeB09/vjLAB30+kZQAP/P5/H6/yNAOAEAwCjMBwFAEDwJBMDwLBYAP2/8Hv8/gAGAD8LQs9w/nhDY/oygIA=")
var_Column := IColumn{oDCOCX_Exontrol1:Columns:Add("Tasks")}
var_Column:[Def,exCellValueFormat] := 1
oDCOCX_Exontrol1:HeaderVisible := true
var_Items := oDCOCX_Exontrol1:Items
h := var_Items:AddItem("Project")
hChild := var_Items:InsertItem(h,nil,"<img>1</img> Task (left)")
hChild := var_Items:InsertItem(h,nil,"<c><img>2</img> Task (center)")
hChild := var_Items:InsertItem(h,nil,"<r>Task (right) <img>3</img>")
var_Items:[ExpandItem,h] := true
oDCOCX_Exontrol1:EndUpdate()
|
|
1136
|
How do I mask for float/integer number
local var_Editor,var_Editor1,var_Editor2,var_Editor3,var_Editor4,var_Editor5,var_Editor6,var_Editor7,var_Editor8 as IEditor
local var_Items as IItems
local h as USUAL
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:ColumnAutoResize := true
IColumn{oDCOCX_Exontrol1:Columns:Add("Type")}:Width := 32
oDCOCX_Exontrol1:Columns:Add("Editor")
var_Items := oDCOCX_Exontrol1:Items
h := var_Items:AddItem("Integer")
var_Items:[CellValue,h,1] := "12"
var_Editor := var_Items:[CellEditor,h,1]
var_Editor:EditType := EditType
var_Editor:Numeric := exInteger
h := var_Items:AddItem("Integer (mask, group)")
var_Items:[CellValue,h,1] := "10002"
var_Items:[FormatCell,h,1] := "value format `0||`"
var_Editor1 := var_Items:[CellEditor,h,1]
var_Editor1:EditType := MaskType
var_Editor1:Mask := ";;;float,digits=0,invalid=empty,warning=invalid character"
h := var_Items:AddItem("Integer (mask, no group)")
var_Items:[CellValue,h,1] := "10002"
var_Items:[FormatCell,h,1] := "value format `0|0|`"
var_Editor2 := var_Items:[CellEditor,h,1]
var_Editor2:EditType := MaskType
var_Editor2:Mask := ";;;float,digits=0,grouping=,invalid=empty,warning=invalid character"
h := var_Items:AddItem("Float")
var_Items:[CellValue,h,1] := "+12.34E+2"
var_Editor3 := var_Items:[CellEditor,h,1]
var_Editor3:EditType := EditType
var_Editor3:Numeric := exFloat
h := var_Items:AddItem("Float (no signs)")
var_Items:[CellValue,h,1] := "12.34E-2"
var_Editor4 := var_Items:[CellEditor,h,1]
var_Editor4:EditType := EditType
var_Editor4:Numeric := exDisableSigns | exFloat
h := var_Items:AddItem("Float-Integer")
var_Items:[CellValue,h,1] := "+12.34"
var_Editor5 := var_Items:[CellEditor,h,1]
var_Editor5:EditType := EditType
var_Editor5:Numeric := exFloatInteger
h := var_Items:AddItem("Float-Integer (no signs)")
var_Items:[CellValue,h,1] := "12.34"
var_Editor6 := var_Items:[CellEditor,h,1]
var_Editor6:EditType := EditType
var_Editor6:Numeric := exDisableSigns | exFloatInteger
h := var_Items:AddItem("Float (mask,group)")
var_Items:[CellValue,h,1] := "10002.34"
var_Items:[FormatCell,h,1] := "value format `2`"
var_Editor7 := var_Items:[CellEditor,h,1]
var_Editor7:EditType := MaskType
var_Editor7:Mask := ";;;float,invalid=empty,warning=invalid character"
h := var_Items:AddItem("Float (mask, no group)")
var_Items:[CellValue,h,1] := "10002.34"
var_Items:[FormatCell,h,1] := "value format `2|0|`"
var_Editor8 := var_Items:[CellEditor,h,1]
var_Editor8:EditType := MaskType
var_Editor8:Mask := ";;;float,grouping=,invalid=empty,warning=invalid character"
oDCOCX_Exontrol1:EndUpdate()
|
|
1135
|
How do I set an extra data for each item
METHOD OCX_Exontrol1MouseMove(Button,Shift,X,Y) CLASS MainDialog
// MouseMove event - Occurs when the user moves the mouse.
local i as USUAL
i := oDCOCX_Exontrol1:[ItemFromPoint,-1,-1,c,hit]
OutputDebugString(String2Psz( AsString(i) ))
OutputDebugString(String2Psz( AsString(oDCOCX_Exontrol1:Items:[ItemData,i]) ))
RETURN NIL
local var_Items,var_Items1 as IItems
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:ColumnAutoResize := true
oDCOCX_Exontrol1:Columns:Add("Default")
var_Items := oDCOCX_Exontrol1:Items
var_Items:[ItemData,var_Items:AddItem("method 1")] := "your extra data of method 1"
var_Items:InsertItem(0,"your extra data of method 2","method 2")
var_Items1 := oDCOCX_Exontrol1:Items
var_Items1:DefaultItem := var_Items1:AddItem("method 3")
var_Items1:[ItemData,0] := "your extra data of method 3"
oDCOCX_Exontrol1:EndUpdate()
|
|
1134
|
I do not like to specify the item padding for every column I add. The question is how can I do it automatically
local var_Column as IColumn
local var_Columns as IColumns
local var_Items as IItems
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:AttachTemplate("handle AddColumn(Column){Column{Def(48)=8;Def(49)=8;AllowDragging=False;AllowSizing = True}}")
oDCOCX_Exontrol1:HeaderAppearance := Etched
oDCOCX_Exontrol1:DrawGridLines := exAllLines
oDCOCX_Exontrol1:GridLineStyle := exGridLinesVSolid
var_Columns := oDCOCX_Exontrol1:Columns
var_Columns:Add("Item")
var_Column := IColumn{var_Columns:Add("Pos")}
var_Column:Position := 0
var_Column:Width := 32
var_Column:AllowSizing := false
var_Column:FormatColumn := "1 index ``"
var_Items := oDCOCX_Exontrol1:Items
var_Items:AddItem("Item A")
var_Items:AddItem("Item B")
var_Items:AddItem("Item C")
oDCOCX_Exontrol1:EndUpdate()
|
|
1133
|
How can I change the Exclude field in the drop down filter window
local var_Column as IColumn
local var_Items as IItems
local h as USUAL
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:LinesAtRoot := exLinesAtRoot
oDCOCX_Exontrol1:[HTMLPicture,"exclude"] := "gCJKBOI4NBQaBQAhQNJJIIhShQACERCAEAcRdrdcUQhQDOZCJJUBEjbbhJ7giIJOBILJziJvl4BeKibhDiIZOhFLB0KZvMx0O5hORlAB3owuNJuNZzMZhOBlFxvORnTbuHgaiIeKBMKhFf9fDIcEoPCAVEAlGI4HhBBYMCARCQVGg4IhVMCAWC2XY1Q7WJ8RBB0KROKYAYDBbzicjndD6fA/VsRHRJIhBkRbMYIGwGAQjA2fRYOEBoYjBFBx1ATCgCGQ8M7OTjSaJMDRDKIwYu5DrIMBgSAADKJTqhBhyRApAA3FAucZPPilokRJJFJxEVxCMCCgIA=="
oDCOCX_Exontrol1:[Description,exFilterBarExclude] := "<img>exclude</img>"
var_Column := IColumn{oDCOCX_Exontrol1:Columns:Add("Items")}
var_Column:DisplayFilterButton := true
var_Column:DisplayFilterPattern := false
var_Column:FilterList := exShowExclude | exShowFocusItem | exShowCheckBox
var_Items := oDCOCX_Exontrol1:Items
h := var_Items:AddItem("Root 1")
var_Items:InsertItem(h,nil,"Child 1")
var_Items:InsertItem(h,nil,"Child 2")
var_Items:[ExpandItem,h] := true
h := var_Items:AddItem("Root 2")
var_Items:InsertItem(h,nil,"Child 1")
oDCOCX_Exontrol1:EndUpdate()
|
|
1132
|
How can I change the Exclude field in the drop down filter window
local var_Column as IColumn
local var_Items as IItems
local h as USUAL
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:LinesAtRoot := exLinesAtRoot
oDCOCX_Exontrol1:[Description,exFilterBarExclude] := "<bgcolor 0><fgcolor ffffff> Exclude </fgcolor></bgcolor>"
var_Column := IColumn{oDCOCX_Exontrol1:Columns:Add("Items")}
var_Column:DisplayFilterButton := true
var_Column:DisplayFilterPattern := false
var_Column:FilterList := exShowExclude | exShowFocusItem | exShowCheckBox
var_Items := oDCOCX_Exontrol1:Items
h := var_Items:AddItem("Root 1")
var_Items:InsertItem(h,nil,"Child 1")
var_Items:InsertItem(h,nil,"Child 2")
var_Items:[ExpandItem,h] := true
h := var_Items:AddItem("Root 2")
var_Items:InsertItem(h,nil,"Child 1")
oDCOCX_Exontrol1:EndUpdate()
|
|
1131
|
The grid lines looks different then before. What should I do
local var_Column as IColumn
local var_Items as IItems
local h,hChild as USUAL
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:LinesAtRoot := exLinesAtRoot
oDCOCX_Exontrol1:DrawGridLines := exAllLines
oDCOCX_Exontrol1:GridLineStyle := exGridLinesGeometric
var_Column := IColumn{oDCOCX_Exontrol1:Columns:Add("Tasks")}
var_Column:[Def,exCellHasCheckBox] := true
var_Column:PartialCheck := true
oDCOCX_Exontrol1:HeaderVisible := true
var_Items := oDCOCX_Exontrol1:Items
h := var_Items:AddItem("Project")
hChild := var_Items:InsertItem(h,nil,"Task 1")
var_Items:[SelectItem,hChild] := true
hChild := var_Items:InsertItem(h,nil,"Task 2")
var_Items:[CellState,hChild,0] := 1
hChild := var_Items:InsertItem(h,nil,"Task 3")
var_Items:[CellState,hChild,0] := 1
var_Items:[ExpandItem,h] := true
oDCOCX_Exontrol1:EndUpdate()
|
|
1130
|
Can I sort the column by check-state
local var_Column as IColumn
local var_Items as IItems
oDCOCX_Exontrol1:BeginUpdate()
var_Column := IColumn{oDCOCX_Exontrol1:Columns:Add("Check")}
var_Column:[Def,exCellHasCheckBox] := true
var_Column:SortType := exSortByState
var_Items := oDCOCX_Exontrol1:Items
var_Items:AddItem(nil)
var_Items:[CellState,var_Items:AddItem(nil),0] := 1
var_Items:[CellState,var_Items:AddItem(nil),0] := 1
var_Items:AddItem(nil)
oDCOCX_Exontrol1:Columns:[Item,0]:SortOrder := SortAscending
oDCOCX_Exontrol1:EndUpdate()
|
|
1129
|
Can I sort the column by image
local var_Column as IColumn
local var_Items as IItems
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:Images("gBJJgBAIDAAGAAEAAQhYAf8Pf4hh0QihCJo2AEZjQAjEZFEaIEaEEaAIAkcbk0olUrlktl0vmExmUzmk1m03nE5nU7nk9n0/oFBoVDolFo1HpFJpVLplNp1PqFRqVTqlVq1XrFZrVbrldr1fsFhsVjslls1ntFptVrtltt1vuFxuVzul1u13vF5vV7vl9v1/wGBwWDwmFw2HxGJxWLxmNx0xiFdyOTh8Tf9ZymXx+QytcyNgz8r0OblWjyWds+m0ka1Vf1ta1+r1mos2xrG2xeZ0+a0W0qOx3GO4NV3WeyvD2XJ5XL5nN51aiw+lfSj0gkUkAEllHanHI5j/cHg8EZf7w8vl8j4f/qfEZeB09/vjLAB30+kZQAP/P5/H6/yNAOAEAwCjMBwFAEDwJBMDwLBYAP2/8Hv8/gAGAD8LQs9w/nhDY/oygIA=")
var_Column := IColumn{oDCOCX_Exontrol1:Columns:Add("Image")}
var_Column:SortType := exSortByImage
var_Items := oDCOCX_Exontrol1:Items
var_Items:[CellImage,var_Items:AddItem(nil),0] := 3
var_Items:AddItem(nil)
var_Items:[CellImage,var_Items:AddItem(nil),0] := 1
var_Items:[CellImage,var_Items:AddItem(nil),0] := 2
oDCOCX_Exontrol1:Columns:[Item,0]:SortOrder := SortAscending
oDCOCX_Exontrol1:EndUpdate()
|
|
1128
|
Can I sort the column by value(numeric)
local var_Column as IColumn
local var_Items as IItems
oDCOCX_Exontrol1:BeginUpdate()
var_Column := IColumn{oDCOCX_Exontrol1:Columns:Add("Value")}
var_Column:[Def,exCellValueFormat] := 1
var_Column:FormatColumn := "`<fgcolor=808080><off 4><font ;6> ` + (1 index ``) + ` </font></off></fgcolor>` + value"
var_Column:SortType := exSortByValue | SortNumeric
var_Items := oDCOCX_Exontrol1:Items
var_Items:AddItem("1")
var_Items:AddItem("10")
var_Items:AddItem("2")
var_Items:AddItem("20")
oDCOCX_Exontrol1:Columns:[Item,0]:SortOrder := SortAscending
oDCOCX_Exontrol1:EndUpdate()
|
|
1127
|
Can I sort a column by cell's state (checked, unchecked) rather than caption
local var_Column as IColumn
local var_Editor as IEditor
local var_Items as IItems
oDCOCX_Exontrol1:BeginUpdate()
var_Column := IColumn{oDCOCX_Exontrol1:Columns:Add("Check")}
var_Editor := var_Column:Editor
var_Editor:EditType := CheckValueType
var_Editor:[Option,exCheckValue2] := 1
var_Column:SortType := SortNumeric
var_Items := oDCOCX_Exontrol1:Items
var_Items:AddItem(true)
var_Items:AddItem(false)
var_Items:AddItem(false)
var_Items:AddItem(true)
oDCOCX_Exontrol1:Columns:[Item,0]:SortOrder := SortAscending
oDCOCX_Exontrol1:EndUpdate()
|
|
1126
|
How do I get the item's auto-number, when using FormatColumn property, as CellValue gets empty
METHOD OCX_Exontrol1SelectionChanged() CLASS MainDialog
// SelectionChanged event - Fired after a new item has been selected.
local var_Items as IItems
var_Items := oDCOCX_Exontrol1:Items
OutputDebugString(String2Psz( "pos: " ))
OutputDebugString(String2Psz( var_Items:[CellCaption,var_Items:FocusItem,1] ))
OutputDebugString(String2Psz( "rpos(1): " ))
OutputDebugString(String2Psz( var_Items:[CellCaption,var_Items:FocusItem,2] ))
OutputDebugString(String2Psz( "rpos(2): " ))
OutputDebugString(String2Psz( var_Items:[CellCaption,var_Items:FocusItem,3] ))
OutputDebugString(String2Psz( "apos: " ))
OutputDebugString(String2Psz( var_Items:[CellCaption,var_Items:FocusItem,4] ))
OutputDebugString(String2Psz( "index: " ))
OutputDebugString(String2Psz( var_Items:[CellCaption,var_Items:FocusItem,5] ))
RETURN NIL
local var_Column,var_Column1,var_Column2,var_Column3,var_Column4 as IColumn
local var_Columns as IColumns
local var_Items as IItems
local h,hSel as USUAL
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:LinesAtRoot := exLinesAtRoot
oDCOCX_Exontrol1:DrawGridLines := exRowLines
oDCOCX_Exontrol1:HeaderAppearance := Etched
var_Columns := oDCOCX_Exontrol1:Columns
var_Columns:Add("Items")
var_Column := IColumn{var_Columns:Add("pos")}
var_Column:FormatColumn := "1 pos ``"
var_Column:Position := 0
var_Column:Width := 48
var_Column:AllowSizing := false
var_Column1 := IColumn{var_Columns:Add("rpos(1)")}
var_Column1:FormatColumn := "1 rpos ``"
var_Column1:Position := 1
var_Column1:Width := 48
var_Column1:AllowSizing := false
var_Column2 := IColumn{var_Columns:Add("rpos(2)")}
var_Column2:FormatColumn := "1 rpos `.||A-Z`"
var_Column2:Position := 2
var_Column2:Width := 48
var_Column2:AllowSizing := false
var_Column3 := IColumn{var_Columns:Add("apos")}
var_Column3:FormatColumn := "1 apos ``"
var_Column3:Position := 3
var_Column3:Width := 48
var_Column3:AllowSizing := false
var_Column4 := IColumn{var_Columns:Add("index")}
var_Column4:FormatColumn := "1 index ``"
var_Column4:Position := 4
var_Column4:Width := 48
var_Column4:AllowSizing := false
var_Items := oDCOCX_Exontrol1:Items
h := var_Items:AddItem("Item 1")
var_Items:InsertItem(h,nil,"Child 1")
hSel := var_Items:InsertItem(h,nil,"Child 2")
var_Items:[ExpandItem,h] := true
var_Items:AddItem("Item 2")
var_Items:AddItem("Item 3")
oDCOCX_Exontrol1:EndUpdate()
oDCOCX_Exontrol1:Items:[SelectItem,hSel] := true
|
|
1125
|
How can I display UNICODE characters
local var_Items as IItems
local var_StdFont as stdFont
oDCOCX_Exontrol1:BeginUpdate()
// Generate Source for 'OLE Automation(stdole2.tlb)' server from Tools\Automation Server... with the PREFIX std
var_StdFont := oDCOCX_Exontrol1:Font
var_StdFont:Name := "Arial Unicode"
var_StdFont:Size := 22
oDCOCX_Exontrol1:HeaderVisible := false
oDCOCX_Exontrol1:DefaultItemHeight := 48
IColumn{oDCOCX_Exontrol1:Columns:Add("")}:[Def,exCellValueFormat] := 1
var_Items := oDCOCX_Exontrol1:Items
var_Items:AddItem("Ӓӓ")
var_Items:AddItem("ᦜᦝ;ᦞ")
var_Items:AddItem("ɮɭ;ɯ")
var_Items:AddItem("勳勴勵勶")
var_Items:[FormatCell,var_Items:AddItem(oDCOCX_Exontrol1:Version),0] := "(value lfind `UNICODE`) < 0 ? `<fgcolor=FF0000><b>!UNICODE!</b> version</fgcolor> required: ` + value : `` "
oDCOCX_Exontrol1:EndUpdate()
|
|
1124
|
How do I display the position of the item with 0-padding
local var_Items as IItems
oDCOCX_Exontrol1:BeginUpdate()
IColumn{oDCOCX_Exontrol1:Columns:Add("Items")}:FormatColumn := "((1 apos ``) lpad `00`) + `. ` + value"
var_Items := oDCOCX_Exontrol1:Items
var_Items:AddItem("Item A")
var_Items:AddItem("Item B")
var_Items:AddItem("Item C")
var_Items:AddItem("Item D")
oDCOCX_Exontrol1:EndUpdate()
|
|
1123
|
Can't get the +/- to be displayed on a divider item. What else can I do
local var_Columns as IColumns
local var_Items as IItems
local h as USUAL
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:LinesAtRoot := exLinesAtRoot
oDCOCX_Exontrol1:DrawGridLines := exAllLines
oDCOCX_Exontrol1:TreeColumnIndex := 0
oDCOCX_Exontrol1:MarkSearchColumn := false
oDCOCX_Exontrol1:FullRowSelect := exColumnSel
oDCOCX_Exontrol1:HeaderAppearance := 0xfffffff8 | Bump | Sunken
var_Columns := oDCOCX_Exontrol1:Columns
IColumn{var_Columns:Add("C1")}:Width := 32
IColumn{var_Columns:Add("C2")}:FormatColumn := "1 index ``"
var_Items := oDCOCX_Exontrol1:Items
h := var_Items:AddItem("Cell 1")
var_Items:[CellSingleLine,h,1] := exCaptionWordWrap
h := var_Items:AddItem("This is bit of text merges all cells in the item (divider shows no +/-)")
var_Items:[ItemDivider,h] := 0
var_Items:[ItemBackColor,h] := RGB(240,240,240)
var_Items:[ItemDividerLine,h] := EmptyLine
var_Items:[CellHAlignment,h,0] := CenterAlignment
var_Items:InsertItem(h,nil,"Child 1")
var_Items:InsertItem(h,nil,"Child 2")
var_Items:[ExpandItem,h] := true
h := var_Items:AddItem("Cell 3")
h := var_Items:AddItem("This is bit of text merges all cells in the item (merge shows +/-)")
var_Items:[ItemBackColor,h] := RGB(240,240,240)
var_Items:[CellMerge,h,0] := 1
var_Items:InsertItem(h,nil,"Child 3")
var_Items:InsertItem(h,nil,"Child 4")
var_Items:[ExpandItem,h] := true
oDCOCX_Exontrol1:EndUpdate()
|
|
1122
|
How can I define a column of button type
METHOD OCX_Exontrol1ButtonClick(Item,ColIndex,Key) CLASS MainDialog
// ButtonClick event - Occurs when user clicks on the cell's button.
local var_Items as IItems
var_Items := oDCOCX_Exontrol1:Items
OutputDebugString(String2Psz( AsString(var_Items:[CellValue,Item,ColIndex]) ))
RETURN NIL
local var_Column as IColumn
local var_Items as IItems
oDCOCX_Exontrol1:BeginUpdate()
var_Column := IColumn{oDCOCX_Exontrol1:Columns:Add("Button")}
var_Column:[Def,exCellHasButton] := true
var_Column:[Def,exCellButtonAutoWidth] := false
var_Column:FormatColumn := "``"
var_Column:AllowSizing := false
var_Column:Width := 48
IColumn{oDCOCX_Exontrol1:Columns:Add("Second")}:FormatColumn := "` Item ` + 1 index ``"
var_Items := oDCOCX_Exontrol1:Items
var_Items:AddItem("Button 1")
var_Items:AddItem("Button 2")
var_Items:AddItem("Button 3 ")
oDCOCX_Exontrol1:EndUpdate()
|
|
1121
|
Is it possible to configure different colour/icon when there is a active filter
METHOD OCX_Exontrol1FilterChange() CLASS MainDialog
// FilterChange event - Occurs when filter was changed.
oDCOCX_Exontrol1:[Background,exHeaderFilterBarButton] := oDCOCX_Exontrol1:FormatABC("value = 0 ? 0x1000001 : 0x10000FF ",oDCOCX_Exontrol1:Columns:[Item,0]:FilterType,nil,nil)
RETURN NIL
local var_Appearance as IAppearance
local var_Column,var_Column1 as IColumn
local var_Items as IItems
oDCOCX_Exontrol1:BeginUpdate()
var_Appearance := oDCOCX_Exontrol1:VisualAppearance
var_Appearance:RenderType := -16777216
var_Appearance:Add(1,"gBFLBCJwBAEHhEJAAEhABXUIQAAYAQGKIcBiAKBQAGYBIJDEMgzDDAUBjKKocQTC4AIQjCK4JDKHYJRpHEZyCA8EhqGASRAFUQBYiWE4oSpLABQaK0ZwIGyRIrkGQgQgmPYDSDNU4zVIEEglBI0TDNczhNDENgtGYaJqHIYpZBcM40TKkEZoSIITZcRrOEBiRL1S0RBhGcRUHZlWzdN64LhuK47UrWdD/XhdVzXRbjfz1Oq+bxve48Br7A5yYThdr4LhOFQ3RjIL4xbIcUwGe6VZhjOLZXjmO49T69HTtOCYBEBA")
oDCOCX_Exontrol1:DrawGridLines := exAllLines
oDCOCX_Exontrol1:ShowFocusRect := false
oDCOCX_Exontrol1:[Background,exHeaderFilterBarButton] := 0x1000001
oDCOCX_Exontrol1:[Background,exCursorHoverColumn] := -1
oDCOCX_Exontrol1:HeaderAppearance := Etched
oDCOCX_Exontrol1:BackColorHeader := RGB(255,255,255)
oDCOCX_Exontrol1:HeaderVisible := true
var_Column := IColumn{oDCOCX_Exontrol1:Columns:Add("Filter")}
var_Column:DisplayFilterButton := true
var_Column:AllowSort := false
var_Column:AllowDragging := false
var_Column:FilterList := exShowCheckBox
var_Items := oDCOCX_Exontrol1:Items
var_Items:AddItem("Item A")
var_Items:AddItem("Item B")
var_Items:AddItem("Item C")
var_Column1 := oDCOCX_Exontrol1:Columns:[Item,0]
var_Column1:Filter := "Item B"
var_Column1:FilterType := exFilter
oDCOCX_Exontrol1:ApplyFilter()
oDCOCX_Exontrol1:EndUpdate()
|
|
1120
|
How can I display the type of the value the column display
local var_Column as IColumn
local var_Items as IItems
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:HeaderAppearance := Etched
oDCOCX_Exontrol1:DrawGridLines := exRowLines
var_Column := IColumn{oDCOCX_Exontrol1:Columns:Add("Values")}
var_Column:[Def,exCellValueFormat] := 1
var_Column:FormatColumn := "value + ` <off 4><fgcolor=808080>type(` + type(%0) + `)`"
var_Items := oDCOCX_Exontrol1:Items
var_Items:AddItem(nil)
var_Items:AddItem(-1)
var_Items:AddItem("string")
var_Items:AddItem(SToD("20010101"))
var_Items:AddItem(2)
var_Items:AddItem(true)
var_Items:AddItem(12.34)
oDCOCX_Exontrol1:EndUpdate()
|
|
1119
|
I want to create a conditional format for a column, verifying that the value of the cell is numeric, how can I do
local var_ConditionalFormat as IConditionalFormat
local var_Items as IItems
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:HeaderAppearance := Etched
oDCOCX_Exontrol1:DrawGridLines := exRowLines
oDCOCX_Exontrol1:Columns:Add("Values")
var_ConditionalFormat := oDCOCX_Exontrol1:ConditionalFormats:Add("type(%0) in (2,3,4,5,18,19,20,21)",nil)
var_ConditionalFormat:ForeColor := RGB(255,0,0)
var_ConditionalFormat:Bold := true
oDCOCX_Exontrol1:ConditionalFormats:Add("type(%0) = 11",nil):ForeColor := RGB(0,255,0)
oDCOCX_Exontrol1:ConditionalFormats:Add("type(%0) = 7",nil):ForeColor := RGB(0,0,255)
oDCOCX_Exontrol1:ConditionalFormats:Add("type(%0) in (0,1)",nil):BackColor := RGB(240,240,240)
var_Items := oDCOCX_Exontrol1:Items
var_Items:AddItem(nil)
var_Items:AddItem(-1)
var_Items:AddItem("string")
var_Items:AddItem(SToD("20010101"))
var_Items:AddItem(2)
var_Items:AddItem(true)
var_Items:AddItem(12.34)
oDCOCX_Exontrol1:EndUpdate()
|
|
1118
|
How can I assign a computed value on a different column based on other columns
METHOD OCX_Exontrol1Change(Item,ColIndex,NewValue) CLASS MainDialog
// Change event - Occurs when the user changes the cell's content.
local var_Items as IItems
oDCOCX_Exontrol1:FreezeEvents(true)
var_Items := oDCOCX_Exontrol1:Items
var_Items:[CellValue,Item,1] := oDCOCX_Exontrol1:FormatABC("int(255*sin(value/2))",NewValue,nil,nil)
var_Items:[CellValue,Item,2] := oDCOCX_Exontrol1:FormatABC("int(255*cos(value/2))",NewValue,nil,nil)
oDCOCX_Exontrol1:FreezeEvents(false)
RETURN NIL
local var_Column as IColumn
local var_Items as IItems
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:SelBackMode := exTransparent
oDCOCX_Exontrol1:HeaderAppearance := Etched
oDCOCX_Exontrol1:DrawGridLines := exRowLines
var_Column := IColumn{oDCOCX_Exontrol1:Columns:Add("Value")}
var_Column:Editor:EditType := SpinType
var_Column:Width := 64
var_Column:AllowSizing := false
IColumn{oDCOCX_Exontrol1:Columns:Add("Assign A")}:[Def,exCellBackColor] := 16448250
IColumn{oDCOCX_Exontrol1:Columns:Add("Assign B")}:[Def,exCellBackColor] := 16448250
var_Column := IColumn{oDCOCX_Exontrol1:Columns:Add("Computed")}
var_Column:[Def,exCellBackColor] := 16448250
var_Column:ComputedField := "%1 + %2"
var_Column:FormatColumn := "value format ``"
var_Column:Alignment := RightAlignment
var_Column:HeaderAlignment := var_Column:Alignment
oDCOCX_Exontrol1:ConditionalFormats:Add("%3 >= 0",nil):Bold := true
var_Items := oDCOCX_Exontrol1:Items
var_Items:AddItem(1989)
var_Items:AddItem(2001)
var_Items:AddItem(2017)
var_Items:AddItem(2018)
var_Items:AddItem(2019)
oDCOCX_Exontrol1:EndUpdate()
|
|
1117
|
How can I get computed a value on a different column
local var_Column as IColumn
local var_Items as IItems
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:HeaderAppearance := Etched
oDCOCX_Exontrol1:DrawGridLines := exRowLines
var_Column := IColumn{oDCOCX_Exontrol1:Columns:Add("Year")}
var_Column:Editor:EditType := SpinType
var_Column:Width := 64
var_Column:AllowSizing := false
IColumn{oDCOCX_Exontrol1:Columns:Add("Easter")}:FormatColumn := "date(dateS('3/1/' + %0) + ((1:=(((255 - 11 * (%0 mod 19)) - 21) mod 30) + 21) + (=:1 > 48 ? -1 : 0) + 6 - ((%0 + int(%0 / 4)) + =:1 + (=:1 > 48 ? -1 : 0) + 1) mod 7))"
var_Items := oDCOCX_Exontrol1:Items
var_Items:AddItem(1989)
var_Items:AddItem(2001)
var_Items:AddItem(2017)
var_Items:AddItem(2018)
var_Items:AddItem(2019)
oDCOCX_Exontrol1:EndUpdate()
|
|
1116
|
How can I prevent applying ConditionalFormats on a specified cell, for instance I am displaying a Total field, and I will like to have formatted in a different way (method 2)
METHOD OCX_Exontrol1Change(Item,ColIndex,NewValue) CLASS MainDialog
// Change event - Occurs when the user changes the cell's content.
oDCOCX_Exontrol1:Refresh()
RETURN NIL
local var_Column as IColumn
local var_ConditionalFormat as IConditionalFormat
local var_Editor as IEditor
local var_Items,var_Items1 as IItems
local h as USUAL
oDCOCX_Exontrol1:BeginUpdate()
var_ConditionalFormat := oDCOCX_Exontrol1:ConditionalFormats:Add("(%0 >= 0)",nil)
var_ConditionalFormat:Expression := "(0=type(%CD0)) and (%0 >= 0)"
var_ConditionalFormat:Bold := true
var_ConditionalFormat:ForeColor := RGB(255,0,0)
OutputDebugString(String2Psz( "ConditionalFormat.Valid" ))
OutputDebugString(String2Psz( AsString(var_ConditionalFormat:Valid) ))
var_Column := IColumn{oDCOCX_Exontrol1:Columns:Add("Numbers")}
var_Editor := var_Column:Editor
var_Editor:Numeric := exInteger
var_Editor:EditType := SpinType
var_Column:SortType := SortNumeric
var_Items := oDCOCX_Exontrol1:Items
var_Items:AddItem(100)
var_Items:AddItem(-25)
var_Items:AddItem(31)
var_Items:AddItem(-48)
var_Items1 := oDCOCX_Exontrol1:Items
h := var_Items1:AddItem("sum(all,dir,dbl(%0))")
var_Items1:[SelectableItem,h] := false
var_Items1:[SortableItem,h] := false
var_Items1:[ItemBackColor,h] := RGB(240,240,240)
var_Items1:[CellData,h,0] := "total"
var_Items1:[CellValueFormat,h,0] := exTotalField | exHTML
var_Items1:[FormatCell,h,0] := "'Total: <b><fgcolor=0000FF>'+(value format ``)"
oDCOCX_Exontrol1:EndUpdate()
|
|
1115
|
How can I prevent applying ConditionalFormats on a specified cell, for instance I am displaying a Total field, and I will like to have formatted in a different way (method 1)
METHOD OCX_Exontrol1Change(Item,ColIndex,NewValue) CLASS MainDialog
// Change event - Occurs when the user changes the cell's content.
oDCOCX_Exontrol1:Refresh()
RETURN NIL
local var_Column as IColumn
local var_ConditionalFormat as IConditionalFormat
local var_Editor as IEditor
local var_Items,var_Items1 as IItems
local h as USUAL
oDCOCX_Exontrol1:BeginUpdate()
var_ConditionalFormat := oDCOCX_Exontrol1:ConditionalFormats:Add("%0 >= 0",nil)
var_ConditionalFormat:Bold := true
var_ConditionalFormat:ForeColor := RGB(255,0,0)
var_ConditionalFormat:ApplyTo := exFormatToColumns
var_Column := IColumn{oDCOCX_Exontrol1:Columns:Add("Numbers")}
var_Editor := var_Column:Editor
var_Editor:Numeric := exInteger
var_Editor:EditType := SpinType
var_Column:SortType := SortNumeric
IColumn{oDCOCX_Exontrol1:Columns:Add("Total")}:Visible := false
var_Items := oDCOCX_Exontrol1:Items
var_Items:[LockedItemCount,exBottom] := 1
h := var_Items:[LockedItem,exBottom,0]
var_Items:[ItemDivider,h] := 1
var_Items:[ItemDividerLine,h] := EmptyLine
var_Items:[ItemBackColor,h] := RGB(240,240,240)
var_Items:[CellValue,h,1] := "sum(all,dir,dbl(%0))"
var_Items:[CellValueFormat,h,1] := exTotalField | exHTML
var_Items:[CellHAlignment,h,1] := RightAlignment
var_Items:[FormatCell,h,1] := "'Total: <b><fgcolor=0000FF>'+(value format ``)"
var_Items1 := oDCOCX_Exontrol1:Items
var_Items1:AddItem(100)
var_Items1:AddItem(-25)
var_Items1:AddItem(31)
var_Items1:AddItem(-48)
oDCOCX_Exontrol1:EndUpdate()
|
|
1114
|
ADODB Requery sample
METHOD OCX_Exontrol1ButtonClick(Item,ColIndex,Key) CLASS MainDialog
// ButtonClick event - Occurs when user clicks on the cell's button.
local cmd as _Command
// Generate Source for 'Microsoft ActiveX Data Objects 6.1 Library(msado15.dll)' server from Tools\Automation Server...
cmd := _Command{"ADODB.Command"}
cmd:ActiveConnection := _Connection{oDCOCX_Exontrol1_Recordset{:DataSource}:ActiveConnection}
cmd:CommandText := "INSERT INTO Orders (EmployeeID) VALUES(12345)"
cmd:CommandType := 1
cmd:Execute(nil,nil,0)
_Recordset{oDCOCX_Exontrol1:DataSource}:Requery(0)
RETURN NIL
METHOD OCX_Exontrol1Error(Error,Description) CLASS MainDialog
// Error event - Fired when an internal error occurs.
OutputDebugString(String2Psz( AsString(Description) ))
RETURN NIL
local var_Items as IItems
local h as USUAL
local rs as _Recordset
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:HeaderAppearance := Etched
oDCOCX_Exontrol1:ColumnAutoResize := false
rs := _Recordset{"ADODB.Recordset"}
rs:Open("Select * From Orders","Provider=Microsoft.ACE.OLEDB.12.0;Data Source=C:\Program Files\Exontrol\ExGrid\Sample\Access\misc.accdb",1,3,0)
oDCOCX_Exontrol1:DataSource := _Recordset{rs}
oDCOCX_Exontrol1:ConditionalFormats:Add("%1=12345",nil):BackColor := RGB(240,240,240)
var_Items := oDCOCX_Exontrol1:Items
var_Items:[LockedItemCount,exTop] := 1
h := var_Items:[LockedItem,exTop,0]
var_Items:[ItemDivider,h] := 0
var_Items:[CellHasButton,h,0] := true
var_Items:[CellValue,h,0] := "Requery (add a new record, using ADODB.Command)"
var_Items:[CellHAlignment,h,0] := CenterAlignment
oDCOCX_Exontrol1:EndUpdate()
|
|
1113
|
I am using DetectAddNew property, but no new items is added when AddNew is performed
METHOD OCX_Exontrol1ButtonClick(Item,ColIndex,Key) CLASS MainDialog
// ButtonClick event - Occurs when user clicks on the cell's button.
local var_Recordset as _Recordset
// Generate Source for 'Microsoft ActiveX Data Objects 6.1 Library(msado15.dll)' server from Tools\Automation Server...
var_Recordset := _Recordset{oDCOCX_Exontrol1:DataSource}
var_Recordset:AddNew("EmployeeID",123)
var_Recordset:Update(nil,nil)
RETURN NIL
METHOD OCX_Exontrol1Error(Error,Description) CLASS MainDialog
// Error event - Fired when an internal error occurs.
OutputDebugString(String2Psz( AsString(Description) ))
RETURN NIL
local var_Items as IItems
local h as USUAL
local rs as _Recordset
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:HeaderAppearance := Etched
oDCOCX_Exontrol1:ColumnAutoResize := false
rs := _Recordset{"ADODB.Recordset"}
rs:Open("Orders","Provider=Microsoft.ACE.OLEDB.12.0;Data Source=C:\Program Files\Exontrol\ExGrid\Sample\Access\misc.accdb",1,3,0)
oDCOCX_Exontrol1:DataSource := _Recordset{rs}
var_Items := oDCOCX_Exontrol1:Items
var_Items:[LockedItemCount,exTop] := 1
h := var_Items:[LockedItem,exTop,0]
var_Items:[ItemDivider,h] := 0
var_Items:[CellHasButton,h,0] := true
var_Items:[CellValue,h,0] := "AddNew"
var_Items:[CellHAlignment,h,0] := CenterAlignment
oDCOCX_Exontrol1:DetectAddNew := true
oDCOCX_Exontrol1:DetectDelete := true
oDCOCX_Exontrol1:EndUpdate()
|
|
1112
|
I am skinning the control's header-bar, but the background of the header-bar is shown on each item in the filter-bar drop down panel. What can I do
local var_Appearance as IAppearance
local var_Column as IColumn
local var_Items as IItems
oDCOCX_Exontrol1:BeginUpdate()
var_Appearance := oDCOCX_Exontrol1:VisualAppearance
var_Appearance:Add(1,"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")
var_Appearance:Add(2,"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")
oDCOCX_Exontrol1:BackColorHeader := 0x1000000
oDCOCX_Exontrol1:ForeColorHeader := RGB(128,128,128)
oDCOCX_Exontrol1:[Background,exHeaderFilterBarButton] := 0x2000000
oDCOCX_Exontrol1:[Background,exBackColorFilter] := RGB(255,255,255)
oDCOCX_Exontrol1:[Background,exForeColorFilter] := RGB(0,0,1)
oDCOCX_Exontrol1:[Background,exSelBackColorFilter] := 0x1ff8000
oDCOCX_Exontrol1:[Background,exSelForeColorFilter] := RGB(240,240,240)
oDCOCX_Exontrol1:[Background,exCursorHoverColumn] := -1
oDCOCX_Exontrol1:HeaderHeight := 24
oDCOCX_Exontrol1:BackColorLevelHeader := oDCOCX_Exontrol1:BackColor
var_Column := IColumn{oDCOCX_Exontrol1:Columns:Add("Filter")}
var_Column:DisplayFilterButton := true
var_Column:DisplayFilterPattern := false
var_Column:FilterList := exShowExclude | exShowFocusItem | exShowCheckBox | exSortItemsAsc
var_Column:[Def,exHeaderPaddingLeft] := 2
var_Column:[Def,exHeaderPaddingRight] := 2
var_Items := oDCOCX_Exontrol1:Items
var_Items:AddItem("A")
var_Items:AddItem("B")
var_Items:AddItem("C")
var_Items:AddItem("D")
oDCOCX_Exontrol1:EndUpdate()
|
|
1111
|
How can I change the font for entire column (method 3)
METHOD OCX_Exontrol1AddItem(Item) CLASS MainDialog
// AddItem event - Occurs after a new Item has been inserted to Items collection.
local var_Items as IItems
var_Items := oDCOCX_Exontrol1:Items
// Generate Source for 'OLE Automation(stdole2.tlb)' server from Tools\Automation Server... with the PREFIX std
var_Items:[CellFont,Item,1] := oDCOCX_Exontrol1:Columns:[Item,1]:Data
var_Items:[CellBold,Item,1] := true
var_Items:[CellForeColor,Item,1] := RGB(255,0,0)
RETURN NIL
local var_Column as IColumn
local var_Items as IItems
local f as stdFont
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:HeaderHeight := 24
oDCOCX_Exontrol1:HeaderAppearance := Etched
oDCOCX_Exontrol1:Columns:Add("C1")
var_Column := IColumn{oDCOCX_Exontrol1:Columns:Add("C2")}
var_Column:HTMLCaption := "<b><font Tahoma;14>C2"
f := stdFont{"StdFont"}
f:Name := "Tahoma"
f:Size := 11
var_Column:Data := f
var_Items := oDCOCX_Exontrol1:Items
var_Items:[CellValue,var_Items:AddItem(10),1] := 11
var_Items:[CellValue,var_Items:AddItem(12),1] := 13
oDCOCX_Exontrol1:EndUpdate()
|
|
1110
|
How can I change the font for entire column (method 2)
METHOD OCX_Exontrol1AddItem(Item) CLASS MainDialog
// AddItem event - Occurs after a new Item has been inserted to Items collection.
local var_Items as IItems
local f as stdFont
var_Items := oDCOCX_Exontrol1:Items
// Generate Source for 'OLE Automation(stdole2.tlb)' server from Tools\Automation Server... with the PREFIX std
f := stdFont{"StdFont"}
f:Name := "Tahoma"
f:Size := 11
var_Items:[CellFont,Item,1] := f
var_Items:[CellBold,Item,1] := true
var_Items:[CellForeColor,Item,1] := RGB(255,0,0)
RETURN NIL
local var_Items as IItems
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:HeaderHeight := 24
oDCOCX_Exontrol1:HeaderAppearance := Etched
oDCOCX_Exontrol1:Columns:Add("C1")
IColumn{oDCOCX_Exontrol1:Columns:Add("C2")}:HTMLCaption := "<b><font Tahoma;14>C2"
var_Items := oDCOCX_Exontrol1:Items
var_Items:[CellValue,var_Items:AddItem(10),1] := 11
var_Items:[CellValue,var_Items:AddItem(12),1] := 13
oDCOCX_Exontrol1:EndUpdate()
|
|
1109
|
How can I change the font for entire column (method 1)
local var_ConditionalFormat as IConditionalFormat
local var_Items as IItems
local f as stdFont
oDCOCX_Exontrol1:BeginUpdate()
var_ConditionalFormat := oDCOCX_Exontrol1:ConditionalFormats:Add("1",nil)
var_ConditionalFormat:Bold := true
var_ConditionalFormat:ForeColor := RGB(255,0,0)
// Generate Source for 'OLE Automation(stdole2.tlb)' server from Tools\Automation Server... with the PREFIX std
f := stdFont{"StdFont"}
f:Name := "Tahoma"
f:Size := 11
var_ConditionalFormat:Font := f
var_ConditionalFormat:ApplyTo := 0x1 |
oDCOCX_Exontrol1:HeaderHeight := 24
oDCOCX_Exontrol1:HeaderAppearance := Etched
oDCOCX_Exontrol1:Columns:Add("C1")
IColumn{oDCOCX_Exontrol1:Columns:Add("C2")}:HTMLCaption := "<b><font Tahoma;14>C2"
var_Items := oDCOCX_Exontrol1:Items
var_Items:[CellValue,var_Items:AddItem(10),1] := 11
var_Items:[CellValue,var_Items:AddItem(12),1] := 13
oDCOCX_Exontrol1:EndUpdate()
|
|
1108
|
I am using ExComboBox as an user editor, how can I display a different column
METHOD OCX_Exontrol1UserEditorClose(Object,Item,ColIndex) CLASS MainDialog
// UserEditorClose event - Fired the user editor is about to be opened.
// Items.CellValue(Item,ColIndex) = Object.Select("OrderID")
RETURN NIL
METHOD OCX_Exontrol1UserEditorOleEvent(Object,Ev,CloseEditor,Item,ColIndex) CLASS MainDialog
// UserEditorOleEvent event - Occurs when an user editor fires an event.
OutputDebugString(String2Psz( AsString(Ev) ))
RETURN NIL
METHOD OCX_Exontrol1UserEditorOpen(Object,Item,ColIndex) CLASS MainDialog
// UserEditorOpen event - Occurs when an user editor is about to be opened.
// Object.Select("OrderID") = Me.Items.CellValue(Item,ColIndex)
RETURN NIL
local var_Column,var_Column1 as IColumn
local var_ComboBox as IComboBox
local var_Editor as IEditor
local var_Items as IItems
local h as USUAL
local rs as _Recordset
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:SortOnClick := exNoSort
var_Editor := IColumn{oDCOCX_Exontrol1:Columns:Add("Exontrol.ComboBox")}:Editor
var_Editor:EditType := UserEditorType
var_Editor:UserEditor("Exontrol.ComboBox","")
// Generate Source for 'ExComboBox 1.0 Control Library(ExComboBox.dll)' server from Tools\Automation Server...
var_ComboBox := IComboBox{var_Editor:UserEditorObject}
var_ComboBox:BeginUpdate()
var_ComboBox:Style := 2
var_ComboBox:ColumnAutoResize := false
// Generate Source for 'Microsoft ActiveX Data Objects 6.1 Library(msado15.dll)' server from Tools\Automation Server...
rs := _Recordset{"ADOR.Recordset"}
rs:Open("Orders","Provider=Microsoft.ACE.OLEDB.12.0;Data Source=C:\Program Files\Exontrol\ExGrid\Sample\Access\misc.accdb",3,3,0)
var_ComboBox:DataSource := _Recordset{rs}
var_ComboBox:Alignment := 0
var_ComboBox:IntegralHeight := true
var_ComboBox:MinHeightList := 128
var_ComboBox:MinWidthList := 648
var_ComboBox:HeaderHeight := 36
var_ComboBox:AllowSizeGrip := true
var_ComboBox:SingleEdit := true
var_ComboBox:LabelColumnIndex := 7
var_ComboBox:SearchColumnIndex := 0
var_Column := var_ComboBox:Columns:[Item,0]
var_Column:HeaderBold := true
var_Column:HTMLCaption := "OrderID<br><fgcolor=808080>(search)"
var_Column1 := var_ComboBox:Columns:[Item,7]
var_Column1:HeaderBold := true
var_Column1:HTMLCaption := "ShipName<br><fgcolor=808080>(display)"
var_Column1:Width := 128
var_ComboBox:UseTabKey := false
var_ComboBox:EndUpdate()
oDCOCX_Exontrol1:DrawGridLines := exRowLines
oDCOCX_Exontrol1:TreeColumnIndex := -1
oDCOCX_Exontrol1:DefaultItemHeight := 21
var_Items := oDCOCX_Exontrol1:Items
h := var_Items:AddItem("shows always the drop-down editor")
var_Items:[CellHAlignment,h,0] := CenterAlignment
var_Items:[ItemDivider,h] := 0
var_Items:[ItemDividerLineAlignment,h] := DividerCenter
var_Items:[SelectableItem,h] := false
var_Items:[EnableItem,h] := false
var_Items:[CellEditorVisible,var_Items:AddItem(10248),0] := exEditorVisible
var_Items:[CellEditorVisible,var_Items:AddItem(10249),0] := exEditorVisible
var_Items:[CellEditorVisible,var_Items:AddItem(10250),0] := exEditorVisible
h := var_Items:AddItem("shows the drop-down editor when user clicks it")
var_Items:[CellHAlignment,h,0] := CenterAlignment
var_Items:[ItemDivider,h] := 0
var_Items:[ItemDividerLineAlignment,h] := DividerCenter
var_Items:[SelectableItem,h] := false
var_Items:[EnableItem,h] := false
var_Items:AddItem(10248)
var_Items:AddItem(10249)
var_Items:AddItem(10250)
oDCOCX_Exontrol1:EndUpdate()
|
|
1107
|
The ItemHeight property is not working (method 2)
local var_Items as IItems
local h as USUAL
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:ColumnAutoResize := false
oDCOCX_Exontrol1:ScrollBySingleLine := true
IColumn{oDCOCX_Exontrol1:Columns:Add("Column")}:Width := 128
var_Items := oDCOCX_Exontrol1:Items
var_Items:[CellSingleLine,var_Items:AddItem("This is a bit of text that should break the line"),0] := exCaptionWordWrap
h := var_Items:AddItem("")
var_Items:[ItemDivider,h] := 0
var_Items:[SelectableItem,h] := false
var_Items:[ItemDividerLineAlignment,h] := DividerCenter
var_Items:[ItemHeight,h] := 3
var_Items:[CellSingleLine,var_Items:AddItem("This is a bit of text that should break the line"),0] := exCaptionWordWrap
oDCOCX_Exontrol1:EndUpdate()
|
|
1106
|
The ItemHeight property is not working (method 1)
local var_Column as IColumn
local var_Items as IItems
local h as USUAL
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:ColumnAutoResize := false
oDCOCX_Exontrol1:ScrollBySingleLine := true
var_Column := IColumn{oDCOCX_Exontrol1:Columns:Add("Column")}
var_Column:Width := 128
var_Column:[Def,exCellSingleLine] := 0
var_Items := oDCOCX_Exontrol1:Items
var_Items:AddItem("This is a bit of text that should break the line")
h := var_Items:AddItem("")
var_Items:[ItemDivider,h] := 0
var_Items:[SelectableItem,h] := false
var_Items:[ItemDividerLineAlignment,h] := DividerCenter
var_Items:[ItemMinHeight,h] := 3
var_Items:[ItemMaxHeight,h] := 3
var_Items:AddItem("This is a bit of text that should break the line")
oDCOCX_Exontrol1:EndUpdate()
|
|
1105
|
How do I add a total field locked at the bottom of the control
METHOD OCX_Exontrol1AddGroupItem(Item) CLASS MainDialog
// AddGroupItem event - Occurs after a new Group Item has been inserted to Items collection.
local var_Items as IItems
var_Items := oDCOCX_Exontrol1:Items
var_Items:[ItemDividerLine,Item] := EmptyLine
var_Items:[FormatCell,Item,var_Items:[GroupItem,Item]] := "value + ` Min: <b>` + %13 + `</b> Max: <b>` + %14 + `</b> Sum: <b>` + %15 + `</b>, of Freight column`"
var_Items:[CellValue,Item,"Min"] := "min(current,all,dbl(%6))"
var_Items:[CellValueFormat,Item,"Min"] := exTotalField
var_Items:[CellValue,Item,"Max"] := "max(current,all,dbl(%6))"
var_Items:[CellValueFormat,Item,"Max"] := exTotalField
var_Items:[CellValue,Item,"Sum"] := "sum(current,all,dbl(%6))"
var_Items:[CellValueFormat,Item,"Sum"] := exTotalField
var_Items:[ItemBackColor,Item] := RGB(240,240,240)
RETURN NIL
METHOD OCX_Exontrol1Change(Item,ColIndex,NewValue) CLASS MainDialog
// Change event - Occurs when the user changes the cell's content.
oDCOCX_Exontrol1:Refresh()
RETURN NIL
local var_Column,var_Column1,var_Column2 as IColumn
local var_Columns as IColumns
local var_Items as IItems
local hL as USUAL
local rs as _Recordset
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:HasLines := exNoLine
oDCOCX_Exontrol1:[Description,exColumnsFloatBar] := "Show/Hide"
oDCOCX_Exontrol1:ColumnsFloatBarSortOrder := SortAscending
oDCOCX_Exontrol1:ColumnsFloatBarVisible := exColumnsFloatBarVisibleIncludeCheckColumns
oDCOCX_Exontrol1:ColumnAutoResize := false
oDCOCX_Exontrol1:BackColorSortBar := RGB(240,240,240)
// Generate Source for 'Microsoft ActiveX Data Objects 6.1 Library(msado15.dll)' server from Tools\Automation Server...
rs := _Recordset{"ADOR.Recordset"}
rs:Open("Orders","Provider=Microsoft.ACE.OLEDB.12.0;Data Source=C:\Program Files\Exontrol\ExGrid\Sample\Access\misc.accdb",3,3,0)
oDCOCX_Exontrol1:DataSource := _Recordset{rs}
oDCOCX_Exontrol1:SingleSort := false
oDCOCX_Exontrol1:SortBarVisible := true
oDCOCX_Exontrol1:AllowGroupBy := true
oDCOCX_Exontrol1:SortBarCaption := "Drag a <b>column</b> header here to group by that column."
var_Columns := oDCOCX_Exontrol1:Columns
var_Column := IColumn{var_Columns:Add("Min")}
var_Column:Visible := false
var_Column:AllowDragging := false
var_Column := IColumn{var_Columns:Add("Max")}
var_Column:Visible := false
var_Column:Visible := false
var_Column:AllowDragging := false
var_Column1 := IColumn{var_Columns:Add("Sum")}
var_Column1:Visible := false
var_Column1:Visible := false
var_Column1:AllowDragging := false
var_Column2 := oDCOCX_Exontrol1:Columns:[Item,"Freight"]
var_Column2:FormatColumn := "currency(value)"
var_Column2:[Def,exCellBackColor] := 12895487
var_Column2:[Def,exHeaderBackColor] := var_Column2:[Def,exCellBackColor]
var_Column2:HeaderBold := true
var_Column2:AllowGroupBy := false
var_Column2:Alignment := RightAlignment
oDCOCX_Exontrol1:ScrollBySingleLine := false
var_Items := oDCOCX_Exontrol1:Items
var_Items:[LockedItemCount,exBottom] := 2
hL := var_Items:[LockedItem,exBottom,0]
var_Items:[ItemDivider,hL] := 0
var_Items:[ItemHeight,hL] := 3
var_Items:[ItemDividerLineAlignment,hL] := DividerTop
var_Items:[ItemDividerLine,hL] := DoubleLine
hL := var_Items:[LockedItem,exBottom,1]
var_Items:[CellValue,hL,6] := "sum(all,rec,dbl(%6))"
var_Items:[CellValueFormat,hL,6] := exTotalField
var_Items:[ItemHeight,hL] := 24
var_Items:[ItemBold,hL] := true
oDCOCX_Exontrol1:Columns:[Item,"EmployeeID"]:SortOrder := true
oDCOCX_Exontrol1:EndUpdate()
|
|
1104
|
How can I add a total field, when I use grouping
METHOD OCX_Exontrol1AddGroupItem(Item) CLASS MainDialog
// AddGroupItem event - Occurs after a new Group Item has been inserted to Items collection.
local var_Items as IItems
var_Items := oDCOCX_Exontrol1:Items
var_Items:[ItemDividerLine,Item] := EmptyLine
var_Items:[FormatCell,Item,var_Items:[GroupItem,Item]] := "value + ` Min: <b>` + %13 + `</b> Max: <b>` + %14 + `</b> Sum: <b>` + %15 + `</b>, of Freight column`"
var_Items:[CellValue,Item,"Min"] := "min(current,all,dbl(%6))"
var_Items:[CellValueFormat,Item,"Min"] := exTotalField
var_Items:[CellValue,Item,"Max"] := "max(current,all,dbl(%6))"
var_Items:[CellValueFormat,Item,"Max"] := exTotalField
var_Items:[CellValue,Item,"Sum"] := "sum(current,all,dbl(%6))"
var_Items:[CellValueFormat,Item,"Sum"] := exTotalField
var_Items:[ItemBackColor,Item] := RGB(240,240,240)
RETURN NIL
METHOD OCX_Exontrol1Change(Item,ColIndex,NewValue) CLASS MainDialog
// Change event - Occurs when the user changes the cell's content.
oDCOCX_Exontrol1:Refresh()
RETURN NIL
local var_Column as IColumn
local var_Columns as IColumns
local var_Items as IItems
local hL as USUAL
local rs as _Recordset
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:HasLines := exNoLine
oDCOCX_Exontrol1:ColumnAutoResize := false
oDCOCX_Exontrol1:BackColorSortBar := RGB(240,240,240)
// Generate Source for 'Microsoft ActiveX Data Objects 6.1 Library(msado15.dll)' server from Tools\Automation Server...
rs := _Recordset{"ADOR.Recordset"}
rs:Open("Orders","Provider=Microsoft.ACE.OLEDB.12.0;Data Source=C:\Program Files\Exontrol\ExGrid\Sample\Access\misc.accdb",3,3,0)
oDCOCX_Exontrol1:DataSource := _Recordset{rs}
oDCOCX_Exontrol1:SingleSort := false
oDCOCX_Exontrol1:SortBarVisible := true
oDCOCX_Exontrol1:AllowGroupBy := true
oDCOCX_Exontrol1:Columns:[Item,1]:SortOrder := true
var_Columns := oDCOCX_Exontrol1:Columns
IColumn{var_Columns:Add("Min")}:Visible := false
IColumn{var_Columns:Add("Max")}:Visible := false
IColumn{var_Columns:Add("Sum")}:Visible := false
var_Column := oDCOCX_Exontrol1:Columns:[Item,"Freight"]
var_Column:[Def,exCellBackColor] := 12895487
var_Column:[Def,exHeaderBackColor] := var_Column:[Def,exCellBackColor]
var_Column:HeaderBold := true
var_Column:AllowGroupBy := false
oDCOCX_Exontrol1:ScrollBySingleLine := false
var_Items := oDCOCX_Exontrol1:Items
var_Items:[LockedItemCount,exBottom] := 1
hL := var_Items:[LockedItem,exBottom,0]
var_Items:[ItemDivider,hL] := 0
var_Items:[ItemHeight,hL] := 24
var_Items:[ItemDividerLineAlignment,hL] := DividerTop
var_Items:[ItemDividerLine,hL] := DoubleLine
var_Items:[CellValue,hL,0] := "sum(all,rec,dbl(%6))"
var_Items:[CellValueFormat,hL,0] := exTotalField | exHTML
var_Items:[CellHAlignment,hL,0] := RightAlignment
var_Items:[FormatCell,hL,0] := "'Freight: <bgcolor=FFC4C4> '+(value format ``) + ` `"
oDCOCX_Exontrol1:EndUpdate()
|
|
1103
|
How do I use the ColumnsFloatBarVisible on exColumnsFloatBarVisibleIncludeCheckColumns
local var_Columns as IColumns
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:ColumnAutoResize := false
oDCOCX_Exontrol1:HeaderAppearance := Etched
var_Columns := oDCOCX_Exontrol1:Columns
var_Columns:Add("City")
IColumn{var_Columns:Add("Start")}:Visible := false
IColumn{var_Columns:Add("End")}:Visible := false
oDCOCX_Exontrol1:[Description,exColumnsFloatBar] := "Show/Hide"
oDCOCX_Exontrol1:ColumnsFloatBarSortOrder := SortAscending
oDCOCX_Exontrol1:ColumnsFloatBarVisible := exColumnsFloatBarVisibleIncludeCheckColumns
oDCOCX_Exontrol1:EndUpdate()
|
|
1102
|
How do I use the ColumnsFloatBarVisible on exColumnsFloatBarVisibleIncludeHiddenColumn
local var_Columns as IColumns
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:ColumnAutoResize := false
oDCOCX_Exontrol1:HeaderAppearance := Etched
var_Columns := oDCOCX_Exontrol1:Columns
var_Columns:Add("City")
IColumn{var_Columns:Add("Start")}:Visible := false
IColumn{var_Columns:Add("End")}:Visible := false
oDCOCX_Exontrol1:[Description,exColumnsFloatBar] := "Show"
oDCOCX_Exontrol1:ColumnsFloatBarVisible := exColumnsFloatBarVisibleIncludeHiddenColumns
oDCOCX_Exontrol1:ColumnsFloatBarSortOrder := SortAscending
oDCOCX_Exontrol1:EndUpdate()
|
|
1101
|
How do I use the ColumnsFloatBarVisible on exColumnsFloatBarVisibleIncludeGroupByColumns
local var_Columns as IColumns
oDCOCX_Exontrol1:BeginUpdate()
oDCOCX_Exontrol1:ColumnAutoResize := false
oDCOCX_Exontrol1:HeaderAppearance := Etched
var_Columns := oDCOCX_Exontrol1:Columns
var_Columns:Add("City")
var_Columns:Add("Start")
var_Columns:Add("End")
oDCOCX_Exontrol1:AllowGroupBy := true
oDCOCX_Exontrol1:SortBarVisible := true
oDCOCX_Exontrol1:SortBarCaption := "Drag a <b>column</b> header here to group by that column."
oDCOCX_Exontrol1:BackColorSortBar := RGB(250,250,250)
oDCOCX_Exontrol1:[Description,exColumnsFloatBar] := "Group-By"
oDCOCX_Exontrol1:ColumnsFloatBarVisible := exColumnsFloatBarVisibleIncludeGroupByColumns
oDCOCX_Exontrol1:ColumnsFloatBarSortOrder := SortAscending
oDCOCX_Exontrol1:Columns:[Item,"City"]:SortOrder := SortAscending
oDCOCX_Exontrol1:EndUpdate()
|
